Chevrolet Silverado / GMC Sierra. Manual - part 1171
NO
Normally Open
OBD
On Board Diagnostic
OSS
Output (Shaft) Speed Sensor
PC
Pressure Control
PCM
Powertrain Control Module
PWM
Pulse Width Modulation
RPM
Revolutions Per Minute
SS
Shift Solenoid
TAP
Transmission Adaptive Pressure
TCC
Torque Converter Clutch
TCM
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Transmission Control Module
TFP
Transmission Fluid Pressure
TFT
Transmission Fluid Temperature
TP
Throttle Position
TV
Throttle Valve
VSS
Vehicle Speed Sensor
WOT
Wide Open Throttle
4WD
Four-Wheel Drive
TRANSMISSION IDENTIFICATION INFORMATION
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 534: Toledo Build
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
1
8 = 2008
2
Model
3
Hydra-Matic 4L60-E
4
Julian Date or Day of the Year
5
Shift Built, See Shift Build Chart
6
Serial Number
7
Case/Pan Frame Rail Location
7
Case/Pan Frame Rail Location
8
Optional Transmission ID Location, Tag is Used as a Back-up if Unable
to Etch Case/Pan Area and to Bar Code Scan
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 535: Ramos Arizpe, Mexico Build
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
1
8 = 2008
2
Model
3
Hydra-Matic 4L60-E
4
Plant of Manufacture, 4 is Ramos
5
Julian Date or Day of the Year
6
Shift Built, See Shift Build Chart
7
Transmission Serial Number
8
Optional Transmission ID Tag Location, Tag is Used as a Back-up if
Unable to Etch Case/Pan Area and to Bar Code Scan
9
Case/Pan Frame Rail Area
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
