Fig. 349: View Of Radiator Outlet Hose
Courtesy of GENERAL MOTORS CORP.
33. Install the radiator outlet hose to the water pump.
34. Install the radiator outlet hose to the surge tank.
35. Position the radiator outlet hose clamps.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 350: View Of Radiator Inlet Hose, Clamps & Thermostat Housing
Courtesy of GENERAL MOTORS CORP.
36. Install the radiator inlet hose to the thermostat housing.
37. Position the radiator inlet hose clamp.
38. Install the drive belt. Refer to Drive Belt Replacement.
39. Install the lower fan shroud. Refer to Engine Coolant Fan Lower Shroud Replacement
(Mechanical) .
40. Install the fuel pipes/hoses. Refer to Fuel Hose/Pipes Replacement - Engine
Compartment .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 351: Identifying Hood Hinge Normal And Service Position Bolt Holes
Courtesy of GENERAL MOTORS CORP.
41. Remove the hood hinge bolt from the service position (2).
42. Lower the hood to the normal position.
43. Install the hood hinge bolts.
Tighten: Tighten the bolts to 25 N.m (18 lb ft).
44. Raise the vehicle.
