Chevrolet Silverado / GMC Sierra. Manual - part 99
Fig. 318: View Of Battery Cable Bracket Bolts
Courtesy of GENERAL MOTORS CORP.
14. Remove the battery cable bracket bolts.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 319: View Of Oil Level Sensor Electrical Connector, CKP Electrical Connector
& Battery Ground Bolt
Courtesy of GENERAL MOTORS CORP.
15. Disconnect the crankshaft position (CKP) sensor electrical connector (5) and remove the
harness from the retainer clip.
16. Remove the ground bolt (3) holding the negative battery cable (6) and ground cable (4) to
the engine.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 320: Flywheel-To-Torque Converter Bolts
Courtesy of GENERAL MOTORS CORP.
17. If equipped, remove the torque converter bolts.
18. Remove the transmission bolts.
19. Lower the vehicle.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 321: View Of Radiator Inlet Hose, Clamps & Thermostat Housing
Courtesy of GENERAL MOTORS CORP.
20. Reposition the radiator inlet hose clamp.
21. Remove the radiator inlet hose from the thermostat housing.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
