Fig. 314: Identifying Hood Hinge Normal And Service Position Bolt Holes
Courtesy of GENERAL MOTORS CORP.
1. Raise the hood to the service position, perform the following:
1. Remove the hood hinge bolts (1).
2. Raise the hood until vertical.
3. Install the hood hinge bolts until snug in the service position (2).
2. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection
and Connection (w/Single Battery) or Battery Negative Cable Disconnection and
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and
Connection (w/Dual Batteries) .
3. Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill) or
Cooling System Draining and Filling (Static Fill) .
4. Remove the fuel pipes/hoses. Refer to Fuel Hose/Pipes Replacement - Engine
Compartment .
5. Remove the lower fan shroud. Refer to Engine Coolant Fan Lower Shroud
Replacement (Mechanical) .
6. Remove the drive belt. Refer to Drive Belt Replacement.
7. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 315: Identifying Oil Pan Skid Plate
Courtesy of GENERAL MOTORS CORP.
8. If equipped, remove the oil pan skid plate bolts and plate.
9. If equipped, remove the engine shield. Refer to Engine Shield Replacement .
10. Remove the starter. Refer to Starter Motor Replacement (4.3L) .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 316: Transmission Cover
Courtesy of GENERAL MOTORS CORP.
11. Remove the transmission cover.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 317: Positive Battery Cable Clip Bolt
Courtesy of GENERAL MOTORS CORP.
12. Remove the positive battery cable clip bolt (2).
13. Remove the catalytic converter. Refer to Catalytic Converter Replacement (4.3L) .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
