Fig. 188: Locating Cylinder Head Bolts (Right)
Courtesy of GENERAL MOTORS CORP.
9. Remove and discard the cylinder head bolts.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 189: Removing/Installing Cylinder Head (Right)
Courtesy of GENERAL MOTORS CORP.
10. Remove the cylinder head.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 190: View Of Cylinder Head Gasket And Alignment Pins - Right
Courtesy of GENERAL MOTORS CORP.
11. Remove and discard the cylinder head gasket.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 191: Cylinder Head Locator Pins
Courtesy of GENERAL MOTORS CORP.
12. Remove the cylinder head locator pins, if necessary.
13. Clean and inspect the cylinder head, if necessary. Refer to Cylinder Head Cleaning and
Inspection.
14. Disassemble the cylinder head, if necessary. Refer to Cylinder Head Disassemble.
Installation Procedure
