Chevrolet Silverado / GMC Sierra. Manual - part 4
Fig. 2: Upper Engine View 1
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
1
Spark Plug Wire Retainer
2
Spark Plug Wire Harness
3
Oil Pump Drive Shaft Clamp Bolt
4
Oil Pump Drive Shaft
5
Spark Plug Wire Harness
6
Spark Plug Wire Retainer
7
Spark Plug Wire Retainer
8
Spark Plug Wire Retainer
9
Spark Plug
10
Oil Pump Drive Shaft Gasket
11
Spark Plug Wire Retainer
12
Manifold Absolute Pressure Sensor
13
Manifold Absolute Pressure Sensor Seal
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
14
Lower Intake Manifold Bolt
15
Lower Intake Manifold Gasket
16
Intake Manifold Assembly
17
Accelerator Control Cable Bracket Stud
18
Accelerator Control Cable Bracket Bolt
19
Accelerator Control Cable Bracket
20
Accelerator Control Cable Bracket Nut
21
Ignition Coil Bracket
22
Ignition Coil Bracket Bolt
23
Ignition Coil Assembly to Bracket Bolt
24
Ignition Coil Assembly
25
Ignition Coil Module
26
Ignition Coil Module Bolt
27
EVAP Purge Valve Seal
28
EVAP Purge Valve
29
EVAP Purge Valve Hose
30
EVAP Purge Valve Bolt
31
Spark Plug Wire Retainer
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 3: Upper Engine View 2
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
1
Oil Filler Cap
2
Oil Filler Cap Seal
3
Oil Filler Tube
4
Oil Filler Tube Seal
5
Valve Rocker Arm Cover
6
Valve Push Rod
7
Valve Lifter Guide Bolt
8
Valve Stem Oil Seal
9
Valve Spring
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
10
Valve Spring Cap
11
Valve Stem Key
12
Valve Rocker Arm Cover
13
Positive Crankcase Ventilation Tube
14
Valve Rocker Arm Cover Bolt
15
Valve Rocker Arm Cover Bolt Grommet
16
Valve Rocker Arm Cover Gasket
17
Valve Rocker Arm Bolt
18
Valve Rocker Arm
19
Valve Rocker Arm Pivot Support
20
Cylinder Head Bolt
21
Spark Plug Wire Support
22
Spark Plug Wire Support Bolt
23
Cylinder Head Bolt
24
Cylinder Head Bolt
25
Exhaust Manifold Gasket
26
Exhaust Manifold
27
Exhaust Manifold Heat Shield Bolt
28
Spark Plug Wire Shield
29
Exhaust Manifold Bolt
30
Exhaust Manifold Stud
31
Spark Plug Wire Shield
32
Exhaust Manifold Heat Shield
33
Exhaust Manifold Gasket
34
Engine Coolant Temperature Sensor
35
Valve
36
Cylinder Head
37
Valve Lifter Guide
38
Cylinder Head Gasket
39
Cylinder Head Location Pin
40
Valve Lifter
41
Positive Crankcase Ventilation Tube Grommet
42
Positive Crankcase Ventilation Tube
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
