Front Body Assembly Dimensions

Flush between roof and front windshield at A-1: -4.0 ± 2.0 mm

RT21500710

A

22

A

4

A

8

A

30

A

29

A

3

A

5

A

26

A

23

A

24

A

1

A

19

A

20

A

31

A

12

A

11

A

18

A

17

A

15

A

16

A

14

A

9

A

10

A

13

A

6

A

28

A

7

A

27

A

25

A

2

A

21

RT21500130

-4.0±2.0

FRONT WINDSHIELD

ROOF

50–

12

50

Clearance between trim panel garnish and front door at A-2:
4.5 ± 1.2 mm

Clearance between front door and rear door at A-3: 4.0

 mm

Flush between front door and rear door at A-3: 0

 mm

Clearance between front door and rear door at A-4: 4.0

 mm

Flush between front door and rear door at A-4: 0

 mm

Clearance between front door trim board and rear door trim
board at A-5: 7.8 ± 2.0 mm
Flush between front door trim board and rear door trim board
at A-5: 3.0 ± 2.0 mm

RT21500140

4.5±1.2

FRONT DOOR

TRIM PANEL
GARNISH

4.0 +1.5

-1.0

0 +1.2

-0.5

REAR DOOR

FRONT DOOR

RT21500160

+1.5
 -1.0

+1.2
 -0.5

4.0

+1.0

-0.5

FRONT DOOR

REAR DOOR

0

0

+1.0

RT21500200

+1.0
 -0.5

+1.0
  0

FRONT DOOR TRIM BOARD

REAR DOOR TRIM BOARD

3.0±2.0

7.8±2.0

RT21500210

50–

13

50

Clearance between front door and front door trim board at



A-6: 0

 mm

Clearance between rear apron plate and front door trim
board at A-7: 6.0 ± 1.8 mm

Clearance between front door and fender at A-8: 4.0

 mm

Flush between front door and fender at A-8: 0

 mm

Clearance between fender and hood at A-9: 4.0 ± 1.0 mm
Flush between fender and hood at A-9: 0 ± 1.0 mm

FRONT DOOR

FRONT DOOR TRIM BOARD

0

0

+1.0

RT21500220

+1.0
  0

REAR APRON PLATE

FRONT DOOR TRIM BOARD

6.0±1.8

RT21500230

RT21500100

4.0

-0.5

+1.0

0

-1.0

0

FENDER

FRONT DOOR

+1.0
 -0.5

  0
 -1.0

RT21500400

0±1.0

HOOD

FENDER

4.0±1.0

50–

14

50

Clearance between fender and front wheel flare trim board
at A-10: 0.5 ± 0.5 mm

Clearance between front wheel flare trim board and front
bumper at A-11: 1.0 ± 1.0 mm
Flush between front wheel flare trim board and front bumper
at A-11: 0 ± 1.0 mm

Clearance between fender and front bumper at A-12:



0.5 ± 0.5 mm
Flush between fender and front bumper at A-12: -0.7 ± 1.0 mm

Clearance between fender and headlight at A-13: 2.0 ± 1.0 mm

RT21500390

FENDER

0.5±0.5

FRONT WHEEL
FLARE TRIM BOARD

0±1.0

1.0±1.0

FRONT BUMPER

FRONT WHEEL
FLARE TRIM BOARD

RT21500280

0.5±0.5

-0.7±1.0

FENDER

FRONT BUMPER

RT21500290

2.0±1.0

FENDER

HEADLIGHT

RT21500310
