Diagnostic Tools
• Diagnostic Scan Tool X-431
• Digital Multimeter
• Jumper Wire
Diagnostic Trouble Code (DTC) List
Antilock Brake System DTC List
DTC
DTC DEFINITION
C1101
Battery Voltage High (>18 Volt)
C1102
Battery Voltage Low (<18 Volt)
C1200
Left Front Wheel Speed Sensor Circuit Open or Short to Ground
C1201
Range/Performance: Speed Jump Or Damaged Exciter
C1202
No Signal: Air-Gap Error Or Wrong Exciter
C1203
Right Front Wheel Speed Sensor Circuit Open or Short to Ground
C1204
Range/Performance: Speed Jump Or Damaged Exciter
C1205
No Signal: Air-Gap Error Or Wrong Exciter
C1206
Left Rear Wheel Speed Sensor Circuit Open or Short to Ground
C1207
Range/Performance: Speed Jump Or Damaged Exciter
C1208
No Signal: Air-Gap Error Or Wrong Exciter
C1209
Right Rear Wheel Speed Sensor Circuit Open or Short to Ground
C1210
Range/Performance: Speed Jump Or Damaged Exciter
C1211
No Signal: Air-Gap Error Or Wrong Exciter
C1275
G Sensor Open Or Short To Ground
C1274
G Sensor Signal Fixed Signal
C1604
ECU Hardware: ECU Internal Or Valve Failure
C2112
Valve Relay: Valve Relay Or Fuse Failure
C2402
Motor - Electrical: Open Or Short To Battery, Motor Relay, Fuse Or Motor Lock Fail
DIAGNOSIS & TESTING
