Chery Tiggo. Manual - part 73
NUMBER
ITEM
FAILURE MODE
CORRECTION
10
Fuel Injector
• Unstable idle.
• Lack of engine power.
• Poor acceleration.
• Engine will not start.
• Plugged injector.
Replace
11
TPS
• Poor acceleration.
• The MIL light will turn on.
Replace
12
EVAP
• The engine base fuel closed-loop control self-learning will be
shut off.
• The engine idle air control self-learning will be shut off.
• Unstable idle or high idle.
Replace
13
Fuel Pump
• Noisy fuel pump operation.
• Poor acceleration.
• Engine will not start.
Replace
14
MAP
• Poor acceleration.
• Unstable idle.
• Rough engine operation.
Replace
15
IAT
• Intake air temperature will be equal to the coolant
temperature.
Replace
16
Cooling Fan
• High engine temperature.
• Poor air conditioner performance.
Replace
17
Accelerator
Sensor
• Misfire
• Poor driving capability.
• Rough engine operation.
Replace
Specifications
Torque Specifications
DESCRIPTION
TORQUE (N·m)
Engine Coolant Temperature (ECT) Sensor
20
Knock Sensor
20
Oxygen Sensors
45
Crankshaft Position (CKP) Sensor
10
Camshaft Position (CMP) Sensor
7
Air Flow Sensor Bolts
5
Engine Control Module (ECM) Bolts
10
Accelerator Pedal Position (APP) Sensor
11
Electronic Throttle Control Actuator
10
Vehicle Speed Sensor
10
Manifold Absolute Pressure (MAP) Sensor
6
GENERAL INFORMATION
03
