Ventilation and A/C system
58
Head and foot
It is design for transition stage such as at
outer low temperature with no sunlight.
When temperature control switch is set
between cool (blue) and hot (red), hot air
is directed to lower space of vehicle and
cool air and natural air is directed to
upper room.
A
C switch:On or off
Internal and external circulation control
lever: (
)
Airflow distribution switch:(
)
Temperature control switch:Between blue
(cool) and red (hot)
Blower motor switch:Random
Ventilation
Conditioned air from outside is directed
into vehicle by center ventilation opening
and side ventilation openings.
A/C switch: Off
Internal and external circulation control
lever:(
)
Airflow distribution switch:
(
)or(
)
Temperature control switch: Blue
Blower motor switch: Random
Compulsive heating
A/C switch: Off
Internal and external circulation control
lever:(
)
Airflow distribution switch:(
)
Temperature control switch: Turn
clockwise fully
Blower motor switch: full speed
Notice
Do not apply compulsive heating for a
long term in case air in vehicle will get
foul and fog comes on window. Turn off
internal circulation switch if there is fog
on window or moisture in vehicle.
"compulsive heating "is designed only
for quick warming up ,then return to
"normal heating".
