3. Use a 13# sleeve to remove the bolt of battery support fixed mount.
4. Disassembly of cooling system. 4.1 Hoist the vehicle, place away a coolant collector, unscrew bleeder bolt of the water tank to discharge the coolant.
4.2 Use the snap ring pliers to loosen the clamp on connecting pipe of water tank.
4.3 Use the snap ring pliers to loosen the connecting water pipe of A/C heating water tank.
4.4 Use the snap ring pliers to loosen other connecting water pipes.
5. Disassembly and installation of water pump assembly:
5.1 Remove upper and lower covers of timing gear (refer to disassembly and installation of gear and belt of timing gear). 5.2 Use a caliper to take off the clamps on the three discharging tubes and then pull out the rubber hoses.
|
