7. Separation of differential assembly and clutch housing Separate differential assembly and clutch housing, and then simply take out the differential assembly as shown in Figure 7. Differential Assembly
Figure 7 8. Disassembly of gearshift fork mechanism Use a hammer and a special tool to knock off all spring pins and then use a snap ring pliers or other special tool to take the split washer off the fork shaft (when taking off the split washer, prevent it from deformation), and then disassemble each part of the gearshift mechanism. Split washer Spring pin
|
