214

Features

Audio System

About Your Audio System

The audio system features AM/FM radio and the SiriusXM® Radio service. It can also
play audio CDs, WMA/MP3/AAC files, USB flash drives, and iPod, iPhone and
Bluetooth® devices.

You can operate the audio system from the remote controls on the steering wheel,
or the icons on the On Demand Multi-Use Display

TM

.

1

About Your Audio System

SiriusXM® Radio is available on a subscription basis
only. For more information on SiriusXM® Radio,
contact a dealer.

2 General Information on the Audio System

P. 274

SiriusXM® Radio is available in the United States and
Canada, except Hawaii, Alaska, and Puerto Rico.

SiriusXM® is a registered trademark of SiriusXM®
Radio, Inc.

Video CDs, DVDs, and 3-inch (8-cm) mini CDs are not
supported.

iPod, iPhone and iTunes are trademarks of Apple Inc.

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

When the screen is viewed through polarized
sunglasses, a rainbow pattern may appear on the
screen due to optical characteristics of the screen. If
this is disturbing, please operate the screen without
polarized sunglasses.

Remote Controls

iPod

USB Flash Drive

19 ACURA TLX-31TZ36400.book  214 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

215

uu

Audio System

u

USB Port

Features

USB Port

1. Open the center pocket and tray.

2 Center Pocket P. 194

2. Open the cover.
3. Install the device USB connector or the USB

flash drive to the USB port.

u

The USB port (2.5A) is for charging
devices, playing audio files and
connecting compatible phones with
Apple CarPlay or Android Auto.

1

USB Port

•

Do not leave the iPod or USB flash drive in the
vehicle. Direct sunlight and high temperatures may
damage it.

•

We recommend using an extension cable with the
USB port.

•

Do not connect the iPod or USB flash drive using a
hub.

•

Do not use a device such as a card reader or hard
disk drive, as the device or your files may be
damaged.

•

We recommend backing up your data before using
the device in your vehicle.

•

Displayed messages may vary depending on the
device model and software version.

If the audio system does not recognize the iPod, try
reconnecting it a few times or reboot the device. To
reboot, follow the manufacturer’s instructions
provided with the iPod or visit the following website:

•

U.S.: www.apple.com/ipod.

•

Canada: www.apple.com/ca/ipod.

The USB port can supply up to 2.5A of power. It does
not output 2.5A unless requested by the device.
For amperage details, read the operating manual of
the device that needs to be charged.
Set the power mode to ACCESSORY or ON first.

Under certain conditions, a device connected to the
port may generate noise in the radio you are listening
to.

USB charge

19 ACURA TLX-31TZ36400.book  215 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

216

uu

Audio System

u

Auxiliary Input Jack

Features

Auxiliary Input Jack

Use the jack to connect standard audio
devices.

1. Open the AUX cover.
2. Connect a standard audio device to the

input jack using a 1/8 inch (3.5 mm) stereo
miniplug.

u

The audio system automatically switches
to the AUX mode.

Audio System Theft Protection

The audio system is disabled when it is disconnected from the power source, such as
when the battery is disconnected or goes dead. In certain conditions, the system
may display a code entry screen. If this occurs, reactivate the audio system.

■

Reactivating the audio system

1. Set the power mode to ON.
2. Turn on the audio system.
3. Press and hold the audio system power button for more than two seconds.

u

The audio system is reactivated when the audio control unit establishes a
connection with the vehicle control unit. If the control unit fails to recognize
the audio unit, you must go to a dealer and have the audio unit checked.

1

Auxiliary Input Jack

You can return to the AUX mode by selecting Source
on the On Demand Multi-Use Display

TM

.

19 ACURA TLX-31TZ36400.book  216 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

217

uu

Audio System

u

Audio Remote Controls

Continued

Features

Audio Remote Controls

Allow you to operate the audio system while driving. The information is shown on
the multi-information display.

SOURCE Button
Cycles through the audio modes as follows:
FM AM SiriusXM® CD USB/iPod/Apple
CarPlay/Android Auto Bluetooth®
Audio Pandora®

*

AUX

Left Selector Wheel
Roll Up: To increase the volume.
Roll Down: To decrease the volume.
Push: To mute. Push again to unmute.
• When listening to the radio

Move to the right: To select the next preset radio station.
Move to the left: To select the previous preset radio station.
Move to the right and hold: To select the next strong station.
To select the next channel. (SiriusXM® only)
Move to the left and hold: To select the previous strong station.
To select the previous channel. (SiriusXM® only)

1

Audio Remote Controls

Some mode appears only when an appropriate
device or medium is used.

Left Selector Wheel

SOURCE Button

* Not available on all models

19 ACURA TLX-31TZ36400.book  217 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

218

uu

Audio System

u

Audio Remote Controls

Features

• When listening to a CD, iPod, USB flash drive, or Bluetooth® Audio

Move to the right: To skip to the next song.
Move to the left: To go back to the beginning of the current or previous song.
Move to the right and hold: To go to the next folder. (Bluetooth® Audio only)
Move to the left and hold: To go to the previous folder. (Bluetooth® Audio
only)

• When listening to a CD or USB flash drive

Move to the right and hold: To skip to the next folder.
Move to the left and hold: To go back to the previous folder.

• When listening to Pandora®

*

Move to the right: To skip to the next track.
Move to the right and hold: To select the next station.
Move to the left and hold: To select the previous station.

* Not available on all models

19 ACURA TLX-31TZ36400.book  218 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

219

Features

Audio System Basic Operation

To use the audio system, the power mode must be in ACCESSORY or ON.

Use the interface dial or ENTER/MENU button
to access phone, information or smartphone
functions.

Interface dial (ENTER/MENU button):
Rotate left or right to scroll through the
available choices. Press to set your selection.
Move right, left, up or down to select a
secondary menu.
Press to switch the display to the Information
Menu screen while the trip computer screen
or clock/wallpaper screen is displayed.

BACK button: Press to go back to the
previous display.

 (Day/Night) button: Press to change

the information screen brightness.
Press

 once and make an adjustment

using the interface dial.

u

Each time you press

, the mode

switches between the daytime mode,
nighttime mode and off mode.

1

Audio System Basic Operation

These indications are used to show how to operate
the interface dial.

Rotate

 to select.

Press

to

enter.

Move

,  ,

 or   to select a secondary menu.

Audio function items

2 Station List P. 231
2 Save Preset P. 231, 235
2 Radio Text P. 232
2 Music Search P. 245, 248, 253
2 Scan P. 232, 243, 246, 254
2 Random/Repeat P. 246, 249, 254

When you unlock the doors with your remote, the
driver’s ID (Driver 1 or Driver 2) is detected, and the
audio system settings and preset memory are turned
to the respective mode automatically when you set
the power mode to ON.

 (Day/Night)

Button

BACK Button

Interface Dial (ENTER/
MENU Button)

19 ACURA TLX-31TZ36400.book  219 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

220

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Features

On Demand Multi-Use Display

TM

Use the On Demand Multi-Use Display

TM

 to operate the audio system.

Select Source, then select an item on the source list to switch the audio source.

Select Audio Menu to display the menu items.

■

Selecting an Audio Source

1

On Demand Multi-Use Display

TM

Icons that appear on the screen vary by the source
selected.

Select

 or

 to go back to the previous screen.

Use the

/

 icons to turn the page.

X

1

Selecting an Audio Source

You can change the order of source list displayed.

1. Select Audio Menu, then Edit Source Order.
2. Select

or .

You can also change the source order by pressing
and holding the source on the source list for two
seconds.

■

Displaying the Menu Items

Select Source.

Source List

Select Audio Menu.

Menu Items

19 ACURA TLX-31TZ36400.book  220 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

221

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

Continued

Features

The following items are available:
• Edit Source Order: Displays the Edit Source Order screen.

2 Selecting an Audio Source P. 220

• Sound Settings: Displays the Sound Settings screen.

2 Adjusting the Sound P. 228

• Radio Text (FM mode): Displays the text information broadcast by the current

RDS station.

2 Radio text P. 232

• SportsFlash (SiriusXM® mode): Displays the SportsFlash

TM

 list. If the favorite sport

team is not registered, the setup screen of SportsFlash

TM

 is displayed.

2 Live Sports Alert P. 239
2 Customized Features P. 292

• Traffic & Weather Now (SiriusXM® mode): Displays to the Traffic & Weather

Now screen.

2 Traffic and Weather Information P. 241

• View Channel Schedule (SiriusXM® mode): Displays the SiriusXM® channel

schedule.

• Audio Settings: Displays the Audio Settings screen.

2 Customized Features P. 292

• Screen Settings: Displays the Screen Settings screen.

2 Changing the Screen Settings P. 222

19 ACURA TLX-31TZ36400.book  221 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

uu

Audio System Basic Operation

u

On Demand Multi-Use Display

TM

222

Features

1. Select Audio Menu, then select Screen

Settings.

2. Use

(

+,

(

- or other icons to adjust the

setting.

■

Changing the Screen Settings

1

Changing the Screen Settings

The following are adjustable screen settings:

•

Sync Display Brightness
Selects whether the screen brightness synchronizes
with the instruments panel brightness.

•

Brightness

•

Contrast

•

Black Level

•

Beep
Mutes a beep that sounds every time you touch the
screen.

•

Keyboard
Changes the on-screen keyboard from the
alphabetical order to the qwerty type.

Instead of using

(

+,

(

- or icons, you can also touch

the point where your desired setting is.

19 ACURA TLX-31TZ36400.book  222 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

223

uu

Audio System Basic Operation

u

Information Screen

Continued

Features

Information Screen

Displays the HFL information, clock/wallpaper, trip computer, Apple CarPlay and
Android Auto. From this screen, you can go to various setup options.

Press the PHONE, INFO and SMARTPHONE buttons to go to the corresponding
display.

■

Switching the Display

SMARTPHONE Button

PHONE Button

INFO Button

Phone

Info

Smartphone

19 ACURA TLX-31TZ36400.book  223 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

224

uu

Audio System Basic Operation

u

Information Screen

Features

■

Phone

Shows the HFL information.

2 Bluetooth® HandsFreeLink® P. 317

■

Info

Shows the Trip Computer or Clock/Wallpaper. Press

 to display the

Information Menu screen.

Trip computer:
Current Drive
Shows the range and instant and average fuel economy of the current trip, as well
as the average fuel economy from your last trip.

History of Trip A
Shows the range, average fuel economy and distances traveled for the current trip,
as well as the average fuel economy and distances traveled during the last three
driving cycles.
Each time you reset the trip meter A, the information on the display updates. The
history of the previous three driving cycles is kept.

Deleting the history manually
1. Press

on

the

History of Trip A screen to select Delete History.

2. A confirmation message appears on the screen. Rotate

 to select Yes, then

press .

Clock/Wallpaper:
Shows a clock screen or an image you import.

19 ACURA TLX-31TZ36400.book  224 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

225

uu

Audio System Basic Operation

u

Information Screen

Continued

Features

■

Smartphone

Displays the Apple CarPlay or Android Auto.

2 Apple CarPlay P. 258
2 Android Auto P. 262

19 ACURA TLX-31TZ36400.book  225 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

uu

Audio System Basic Operation

u

Information Screen

226

Features

You can change, store, and delete the wallpaper on the information screen.

■

Import wallpaper

You can import up to three images, one at a time, for wallpaper from a USB flash
drive.

1. Connect the USB flash drive to the USB

port.

2 USB Port P. 215

2. Press the SETTINGS button.
3. Rotate

 to select Clock Settings, then

press .

u

Repeat the procedure to select Clock/
Wallpaper Type.

4. Move

 to select Wallpaper tab.

u

The screen will change to the wallpaper
list.

5. Rotate

 to select Options…, then press

.

u

Repeat the procedure to select, Add
New Wallpaper.

6. Rotate

 to select a desired picture.

u

The preview is displayed on the left side
on the screen.

7. Rotate

 to select Start Import, then

press

 to save the data.

u

The display will return to the wallpaper
list.

■

Wallpaper Setup

1

Wallpaper Setup

•

When importing wallpaper files, the image must be
in the USB flash drive’s root directory.
Images in a folder cannot be imported.

•

The file name must be fewer than 255 characters.

•

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

•

The individual file size limit is 2 MB.

•

The maximum image size is 1,680 x 936 pixels.

•

If the USB flash drive does not have any pictures,
the No files detected message appears.

19 ACURA TLX-31TZ36400.book  226 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

227

uu

Audio System Basic Operation

u

Information Screen

Features

■

Select wallpaper

1. Press the SETTINGS button.
2. Rotate

 to select Clock Settings, then press

.

u

Repeat the procedure to select Clock/Wallpaper Type.

3. Move

to

select

Wallpaper.

u

The screen changes to the wallpaper list.

4. Rotate

 to select a desired wallpaper, then press

.

u

The preview is displayed on the left side on the screen.

u

The pop-up menu appears on the screen.

5. Rotate

 to select Set, then press

.

u

The display will return to the Clock Settings screen.

■

Delete wallpaper

1. Press the SETTINGS button.
2. Rotate

 to select Clock Settings, then press

.

u

Repeat the procedure to select Clock/Wallpaper Type.

3. Move

to

select

Wallpaper.

u

The screen changes to the wallpaper list.

4. Rotate

 to select a wallpaper that you want to delete, then press

.

u

The preview is displayed on the left side on the screen.

u

The pop-up menu appears on the screen.

5. Rotate

 to select Delete, then press

.

u

The confirmation message will appear.

6. Rotate

 to select Yes, then press

 to delete completely.

u

The display will return to the wallpaper list.

19 ACURA TLX-31TZ36400.book  227 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

228

uu

Audio System Basic Operation

u

Adjusting the Sound

Features

Adjusting the Sound

1. Select Audio Menu, then select Sound

Settings.

2. Select the Bass, Treble, Fader, Balance,

Subwoofer or SVC (Speed-sensitive
Volume Compensation).

3. Use

(

+,

(

- or other icons to adjust the

setting.

1

Adjusting the Sound

The SVC has four modes: Off, Low, Mid, and High.
SVC adjusts the volume level based on the vehicle
speed. As you go faster, audio volume increases. As
you slow down, audio volume decreases.

Instead of using

(

+,

(

- or icons, you can also touch

the point where your desired setting is.

19 ACURA TLX-31TZ36400.book  228 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

229

uu

Audio System Basic Operation

u

Display Setup

Features

Display Setup

You can change the brightness of the information screen and On Demand Multi-Use
Display

TM

.

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Rotate

to

select

Brightness, then press

.

4. Rotate

 to adjust the setting.

5. Press .

u

The display will return to the System
Settings screen.

1. Select Audio Menu, then select Screen

Settings.

2. Use

(

+,

(

- to adjust the setting.

■

Changing the Screen Brightness

1

Changing the Screen Brightness

You can change the Contrast and Black Level
settings in the same manner.

Information Screen

On Demand Multi-Use Display

TM

19 ACURA TLX-31TZ36400.book  229 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分
