Acura TLX (2019 year). Manual - part 13

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

198

Co
ntrols

■

When charging does not start

Perform one of the solutions in the following table.

Indicator

Cause

Solution

Slow Blink

There is an obstacle(s) between
the charging area and the
device.

Remove the
obstacle(s).

The device is not within the
charging area.

Move the device to the
center of the charging
area where

 is

located.

Fast Blink

The wireless charger is faulty.

Turn the vehicle off
and back on. If the
indicator still blinks,
contact a dealer.

1

Wireless Charger

*

This system consumes a lot of power. Do not use the
system for a long time when the engine is not
running. This may weaken the battery, making it
difficult to start the engine.

When using the wireless charger, check the user’s
manual that came with the compatible device you
want to charge.

NOTICE

Do not place any magnetic recording media or
precision machines within the charging area while
charging.
The data on your cards such as credit cards can be
lost because of the magnetic effect. Also precision
machines such as watches can go wrong.

“Qi” and

 marks are the registered trademarks

owned by Wireless Power Consortium (WPC).

 mark is the registered trademark owned by Power

Matters Alliance (PMA).

* Not available on all models

19 ACURA TLX-31TZ36400.book  198 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

Continued

199

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

1

Wireless Charger

*

In the following cases, charging may stop or not start:

•

The device is already fully charged.

•

The temperature of the device is extremely high
while charging.

•

You are at a place that emits strong
electromagnetic waves or noises, such as TV
station, electric power plant, or gas station.

A device may not charge if the size or shape of its
chargeable side is not appropriate for use with the
charging area.

Not all devices are compatible with the system.

During the charging phase, it is normal for the
charging area and device to heat up.

Charging may be briefly interrupted when:

•

All the doors or the trunk are closed
- to avoid interference with the proper functioning
of the keyless access system.

•

The position of the device is altered.

•

The radio is scanning for AM stations.

Do not charge more than one device at a time on a
charging area.

* Not available on all models

19 ACURA TLX-31TZ36400.book  199 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

200

Co
ntrols

There are coat hooks on the rear grab handle
of both sides. Pull it down to use it.

There are coat hooks on the door pillar of
both sides.

■

Coat Hooks

1

Coat Hooks

The coat hooks are not designed for large or heavy
items.

19 ACURA TLX-31TZ36400.book  200 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

Continued

201

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Pull the strap and open the lid.

The reverse side of the cargo floor lid is water
resistant. Flip the lid to use the water resistant
side.

■

Under-Floor Storage Area

1

Under-Floor Storage Area

Do not leave water, soil, sand, or perishable foods in
the storage area. Rotting food and dirt on the floor
may cause the breakdown of electrical equipment.

Strap

19 ACURA TLX-31TZ36400.book  201 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

202

Co
ntrols

The power mode must be in ON to use the
heated steering wheel.

Press the button on the left side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you start the engine, even if you turned it
on the last time you drove the vehicle.

■

Heated Steering Wheel

*

1

Heated Steering Wheel

*

Do not use the heated steering wheel continuously
when the engine is off. Under such conditions, the
battery may be weakened, making the engine
difficult to start.

* Not available on all models

19 ACURA TLX-31TZ36400.book  202 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

Continued

203

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
seat heaters and ventilators

*

.

1. Select .
2. Change the setting with one of the

following:
The Low icon: The LO setting (one indicator
on)
The Mid icon: The MID setting (two
indicators on)
The High icon: The HI setting (three
indicators on)
Auto: The system automatically selects the
setting most suitable to the ambient
environment.
Off: Turn off the system.

When the power mode is turned on after it is
turned off, the previous setting of front seat
heaters and ventilators is maintained.

■

Front Seat Heaters and Seat Ventilation

*

1

Front Seat Heaters and Seat Ventilation

*

Do not use the seat heaters and the seat ventilation
even in LO when the engine is off. Under such
conditions, the battery may be weakened, making
the engine difficult to start.

After a certain period of time, the strength setting for
the front seat heaters will automatically be reduced
by one level at a time until the front seat heaters
shuts off. The elapsed time varies according to the
interior environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

Models without seat ventilation

Models with seat ventilation

* Not available on all models

19 ACURA TLX-31TZ36400.book  203 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

204

Co
ntrols

The power mode must be in ON to use the
seat heaters.

There is no heater in the rear center seating
position.
Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

To open the sunglasses holder, press and
release the indent. To close, press it again until
it latches.

You can store eyeglasses and other small
items in this holder.

■

Rear Seat Heaters

*

1

Rear Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

■

Sunglasses Holder

1

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Press

* Not available on all models

19 ACURA TLX-31TZ36400.book  204 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

205

Continued

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the driver’s side or passenger’s side

temperature control switch.

3. Press the

 (On/Off) button to cancel.

1

Using Automatic Climate Control

If any buttons/icons on the touch screen are pressed
while using the climate control system in auto, the
function of the button/icon that was pressed will take
priority.
The AUTO indicator will go off, but functions
unrelated to the button/icon that was pressed will be
controlled automatically.

During idle-stops, air-conditioning is suspended, and
only the blower remains active.
If you do not want air-conditioning suspended, press
the Auto Idle Stop OFF button to cancel idle-stop.

To prevent cold air from blowing in from outside, the
fan may operate at low speed for a while after the
AUTO button has been pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh air mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

Models with Auto Idle Stop

All models

 (On/Off) Button

AUTO Button

On Demand Multi-Use Display

TM

Driver’s Side
Temperature
Control Switch

Passenger’s
Side
Temperature
Control Switch

Passenger’s
Side
Temperature

Driver’s Side
Temperature

19 ACURA TLX-31TZ36400.book  205 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

uu

Climate Control System

u

Using Automatic Climate Control

206

Co
ntrols

In addition to the button/switch controls, you can operate the climate control system
from the On Demand Multi-Use Display

TM

 touch screen.

■

Operating from the On Demand Multi-Use Display

TM

1

Using Automatic Climate Control

Pressing the

 button switches the climate control

system between on and off. When turned on, the
system returns to your last selection.

When you unlock the doors with your remote, the
driver’s ID (Driver 1 or Driver 2) is detected, and the
climate control settings are turned to the respective
mode automatically when you set the power mode to
ON.

While Econ mode is active, the climate control system
may have reduced cooling performance.

On Demand Multi-Use Display

TM

A/C (Air Conditioning) and
SYNC (Synchronization) Icon

Vent Mode Icon

Driver’s Side
Temperature Control
Icon

Recirculation/Fresh Air
mode Icon

Fan Control Icon

Passenger’s Side
Temperature Control
Icon

19 ACURA TLX-31TZ36400.book  206 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

Continued

207

uu

Climate Control System

u

Using Automatic Climate Control

Co
ntrols

1. Select the driver’s or passenger’s side

temperature control icon.

2. Change the temperature setting from the

following:

Temperature bar: Select a point where your
desired temperature setting is.
Farther to the left is for a lower, and to the
right for a higher setting.

(

+/

(

-: To raise or lower the temperature

setting one degree at a time.
While you select and hold

(

+/

(

-, the

temperature decreases or increases.
Max Cool: To rapidly cool down the interior.

u

The AUTO indicator goes off. The setting
returns to the previously selected value
when you select it again.

Max Heat: To rapidly warm up the interior.

u

The AUTO indicator goes off. The setting
returns to the previously selected value
when you select it again.

■

Changing the Interior Temperature Setting

1

Using Automatic Climate Control

If you select the Max Cool or Max Heat during Auto
Idle Stop, the engine restarts automatically.

Models with Auto Idle Stop

The side you selected.

Temperature Bar

19 ACURA TLX-31TZ36400.book  207 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

uu

Climate Control System

u

Using Automatic Climate Control

208

Co
ntrols

■

Switching the vent mode

Select a desired vent mode icon, or Mode
Auto: The system automatically selects the
vent mode most suitable to the ambient
environment.

Vent mode

: Dashboard vents and back of the center

console

: Dashboard and floor vents, and back of

the center console

: Floor vents
: Floor and defroster vents

■

A/C on and off

1. Select A/C.
2. Select On or Off.

1

Switching the vent mode

While the climate control system is in auto, Mode
Auto is highlighted.

19 ACURA TLX-31TZ36400.book  208 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

Continued

209

uu

Climate Control System

u

Using Automatic Climate Control

Co
ntrols

■

SYNC on and off

1. Select SYNC.
2. Select On for synchronization mode, and

Off for dual mode.

u

When in synchronization mode, the
passenger’s side temperature becomes
the same as the driver’s side settings.

3. Adjust the temperature from the driver’s

side.

■

Changing the fan speed

1. Select .

u

When the left or right side of the



is selected, the fan speed level goes up or
down one level at a time.

2. Change the fan speed with one of the

following:
The fan speed level indicators: Select your
desired speed level. The smaller indicator is
for a slower speed, and the larger for a
faster speed.

(

+/

(

-: To go up or down one level at a

time.
Fan Auto: The system automatically selects
the fan speed most suitable to the ambient
environment.

1

SYNC on and off

When the system is not in SYNC mode, the driver’s
side temperature and the front passenger’s side
temperature can be set separately.

You can also turn off SYNC mode by changing the
front passenger’s side temperature.

1

Changing the fan speed

While the climate control system is in auto, Fan Auto
is highlighted.

Fan Speed Level Indicators

19 ACURA TLX-31TZ36400.book  209 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

uu

Climate Control System

u

Using Automatic Climate Control

210

Co
ntrols

Select

 or

 currently shown to

switch between the modes depending on
environmental conditions.

u

Selecting

 or

 currently shown

changes the display to the Fresh Air/
Recirculation display. You can also
switch the mode by selecting

 or

 icon appearing in the display.

 (Recirculation Mode): Recirculates air

from the vehicle’s interior through the system.

 (Fresh Air Mode): Maintains outside

ventilation. Keep the system in fresh air mode
in normal situations.

■

Switching between the Recirculation and Fresh Air Modes

1

Switching between the Recirculation and Fresh Air Modes

While the climate control system is in auto, the
recirculation mode and fresh air mode are
automatically switched depending on environmental
conditions.

19 ACURA TLX-31TZ36400.book  210 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

211

uu

Climate Control System

u

Using Automatic Climate Control

Co
ntrols

Pressing the

 button or selecting the Front

 icon appearing after the vent mode icon is

selected turns the air conditioning system on
and automatically switches the system to fresh
air mode.

Press the

 button or select the Front



icon again to turn off, the system returns to
the previous settings.

■

To rapidly defrost the windows

1. Press the

 button, or select the vent

mode icon and then the Front

icon.

2. Select the recirculation mode.

2 Switching between the Recirculation

and Fresh Air Modes P. 210

■

Defrosting the Windshield and Windows

1

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.
Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

If you press the

 button or select the Front



icon during Auto Idle Stop, the engine restarts
automatically.

Models with Auto Idle Stop

1

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode.
If you keep the system in recirculation mode, the
windows may fog up from humidity. This impedes
visibility.

19 ACURA TLX-31TZ36400.book  211 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

212

uu

Climate Control System

u

Automatic Climate Control Sensors

Co
ntrols

Automatic Climate Control Sensors

The automatic climate control system is
equipped with sensors. Do not cover or spill
any liquid on them.

Sensor

Sensor

19 ACURA TLX-31TZ36400.book  212 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分

213

Features

This chapter describes how to operate technology features.

Audio System

About Your Audio System................ 214
USB Port .......................................... 215
Auxiliary Input Jack .......................... 216
Audio System Theft Protection ......... 216
Audio Remote Controls.................... 217

Audio System Basic Operation ........ 219

On Demand Multi-Use Display

TM

....... 220

Information Screen .......................... 223
Adjusting the Sound ........................ 228
Display Setup ................................... 229
Playing AM/FM Radio ....................... 230

Playing SiriusXM® Radio ................... 233
Playing a CD .................................... 244
Playing an iPod ................................ 247
Playing Pandora® ............................. 250
Playing a USB Flash Drive ................. 252
Playing Bluetooth® Audio................. 255
Siri Eyes Free .................................... 257
Apple CarPlay .................................. 258
Android Auto................................... 262

Audio Error Messages ...................... 267

General Information on the Audio

System ............................................. 274

Customized Features........................ 292
HomeLink® Universal Transceiver ... 314
Bluetooth® HandsFreeLink®............. 317
Compass

*

.......................................... 352

* Not available on all models

19 ACURA TLX-31TZ36400.book  213 ページ  ２０１８年２月１６日　金曜日　午後１２時２２分
