198

uu

Adjusting the Seats

u

Head Restraints

Co
ntrols

Head Restraints

Your vehicle is equipped with head restraints in all seating positions.

Head restraints are most effective for
protection against whiplash and other rear-
impact crash injuries when the center of the
back of the occupant’s head rests against the
center of the restraint. The tops of the
occupant’s ears should be level with the
center height of the restraint.

■

Adjusting the Front and Second Row Outer Head Restraint
Positions

1

Head Restraints

In order for the head restraint system to work
properly:

•

Do not hang any items on the head restraints, or
from the restraint legs.

•

Do not place any objects between an occupant and
the seat-back.

•

Install each restraint in its proper location.

3

WARNING

Improperly positioning head restraints
reduces their effectiveness and increases
the likelihood of serious injury in a crash.

Make sure head restraints are in place and
positioned properly before driving.

Position head in the center
of the head restraint.

18 ACURA MDX-31TZ56400.book  198 ページ  ２０１７年８月２３日　水曜日　午後４時１分

199

uu

Adjusting the Seats

u

Head Restraints

Continued

Co
ntrols

To raise the head restraint: Pull it upward.
To lower the head restraint: Push it down
while pressing the release button.

18 ACURA MDX-31TZ56400.book  199 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Adjusting the Seats

u

Head Restraints

200

Co
ntrols

A passenger sitting in the second row center
seating position should adjust the height of
their head restraint to an appropriate position
before the vehicle begins moving.
To raise the head restraint:
Pull it upward.
To lower the head restraint:
Push it down while pressing the release
button.

Head restraints can be removed for cleaning or repair.

To remove a head restraint:
Pull the restraint up as far as it will go. Then push the release button, and pull the
restraint up and out.

To reinstall a head restraint:
Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

■

Changing the Second Row Center Seat Head Restraint
Position

*

■

Removing and Reinstalling the Head Restraints

1

Removing and Reinstalling the Head Restraints

3

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

Front and second row head restraints

* Not available on all models

18 ACURA MDX-31TZ56400.book  200 ページ  ２０１７年８月２３日　水曜日　午後４時１分

201

uu

Adjusting the Seats

u

Head Restraints

Co
ntrols

A passenger in the third row seating position
should put the head restraint in the upright
position before the vehicle begins moving.

To fold down the head restraint:
Pull the handle.

To put the head restraint back in the
upright position:
Pull up the head restraint and push rearward
until it latches.

■

Folding Down the Third Row Head Restraint

Handle

18 ACURA MDX-31TZ56400.book  201 ページ  ２０１７年８月２３日　水曜日　午後４時１分

202

uu

Adjusting the Seats

u

Maintain a Proper Sitting Position

Co
ntrols

Maintain a Proper Sitting Position

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor until the vehicle is safely parked and the engine is
off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.

In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

1

Maintain a Proper Sitting Position

3

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

18 ACURA MDX-31TZ56400.book  202 ページ  ２０１７年８月２３日　水曜日　午後４時１分

203

uu

Adjusting the Seats

u

Third Row Seats

Co
ntrols

Third Row Seats

Separately fold down the left and right halves of the third row seat to make room
for cargo.

■

To fold down the seat

1. Pull the handle on the seat-back fully.

u

The head restraint tilts downward.

2. Push the seat-back forward while pulling

the handle.

■

To return the seat to the original position

1. Pull the seat-back up with the handle pulled.
2. Push the head restraint up to its original position.

■

Folding Down the Third Row Seat

1

Folding Down the Third Row Seat

Make sure all items in the cargo area or items
extending to the third row seats are properly
secured. Loose items can fly forward if you have
to brake hard.

Handle

1

To return the seat to the original position

Make sure the seat-back and head restraints are
securely latched back into place before driving.

18 ACURA MDX-31TZ56400.book  203 ページ  ２０１７年８月２３日　水曜日　午後４時１分

204

uu

Adjusting the Seats

u

Armrest

Co
ntrols

Armrest

The console lid can be used as an armrest.

To adjust:
Slide the armrest to a desired position.

■

Using the Front Seat Armrest

18 ACURA MDX-31TZ56400.book  204 ページ  ２０１７年８月２３日　水曜日　午後４時１分

205

uu

Adjusting the Seats

u

Armrest

Co
ntrols

Pull down the armrest in the center backrest.

The console lid can be used as an armrest.

To adjust:
Slide the armrest to a desired position.

■

Using the Rear Seat Armrest

Models with bench seat

Models with captain seat

18 ACURA MDX-31TZ56400.book  205 ページ  ２０１７年８月２３日　水曜日　午後４時１分

206

Co
ntrols

Interior Lights/Interior Convenience Items

Interior Lights

■

ON

The interior lights come on regardless of
whether the tailgate and doors are open or
closed.

■

Door activated

The interior lights come on in the following
situations:
• When the tailgate or any of the doors are

opened.

• You unlock the driver’s door.
• When the power mode is set to VEHICLE

OFF (LOCK).

■

OFF

The interior lights remain off regardless of
whether the tailgate or any doors are open or
closed.

■

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after about 30 seconds in the
following situations:

•

When you unlock the driver’s door but do not open
it.

•

When you set the power mode to VEHICLE OFF
(LOCK) but do not open a door.

You can change the interior lights dimming time.

2 Customized Features P. 126, 358

The interior lights go off immediately in the following
situations:

•

When you lock the driver’s door.

•

When you close the driver’s door in ACCESSORY
mode.

•

When you set the power mode to ON.

To avoid draining the battery, do not leave the
interior light on for an extended length of time when
the engine is off.

If you leave any of the tailgate or doors open in
VEHICLE OFF (LOCK) mode, the interior lights go off
after about 15 minutes.

Door Activated Position

Off

On

18 ACURA MDX-31TZ56400.book  206 ページ  ２０１７年８月２３日　水曜日　午後４時１分

207

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

Co
ntrols

■

Front

The map lights can be turned on and off by
pressing the

 (map light) button.

■

Second and third row

The map lights can be turned on and off by
pressing the

 (map light) button when the

front interior light switch is in the door
activated position.

■

ON

The light comes on when you open the
tailgate, and goes off when closed.

■

OFF

The light stays off with or without opening the
tailgate.

■

Map Lights

1

Map Lights

When the interior light switch is in the door activated
position and any door is open, the map light will not
go off when you press the

 button.

Front

Second and third row

■

Cargo Area Lights

Off

On

18 ACURA MDX-31TZ56400.book  207 ページ  ２０１７年８月２３日　水曜日　午後４時１分

208

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Interior Convenience Items

Press the button to open the glove box. You
can lock the glove box with the built-in key.

■

Removable shelf

The shelf in the glove box is detachable. To
remove it, disengage the tabs.

The removed shelf can be stored upside down
in the glove box.

■

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Glove Box

To Lock

Shelf

Tabs

18 ACURA MDX-31TZ56400.book  208 ページ  ２０１７年８月２３日　水曜日　午後４時１分

209

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Co
ntrols

Pull the passenger’s side handle to open the
console compartment.

Pull the driver’s side handle to open the utility
tray in the console lid.

■

Console Tray

Slide or lift the tray when you use the console
compartment.

u

To lift this tray, slide it rearward, then
pull it up.

■

Front and Rear

*

 Console Compartment

* Not available on all models

18 ACURA MDX-31TZ56400.book  209 ページ  ２０１７年８月２３日　水曜日　午後４時１分

210

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Press the raised detent to open the lid. To
close the lid, push it down until it latches.

Pull the handle to open the cargo floor lid.

■

Center Pocket

Press

■

Under-floor Storage Area

18 ACURA MDX-31TZ56400.book  210 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

211

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Front seat beverage holders

Are located in the console between the front
seats.

■

Door side beverage holders

Are located on the both of the front and rear
door side pockets.

■

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

Front:

Rear:

18 ACURA MDX-31TZ56400.book  211 ページ  ２０１７年８月２３日　水曜日　午後４時１分

212

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Second row seat beverage holders

Fold the armrest down to use the rear seat
beverage holders.

Are located in the console between the
second row seats.

■

Third row seat beverage holders

Models with bench seat

Models with captain seat

18 ACURA MDX-31TZ56400.book  212 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

213

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The accessory power sockets can be used when the power mode is in ACCESSORY
or ON.

■

Accessory power socket (center pocket)

Open the lid and the cover to use it.

■

Accessory power socket (front console
compartment)

*

Pull the handle and open the cover to use it.

■

Accessory Power Sockets

1

Accessory Power Sockets

NOTICE

Do not insert an automotive type cigarette lighter
element. This can overheat the power socket.

The accessory power sockets are designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent battery drain, only use the power socket
with the engine running.

* Not available on all models

18 ACURA MDX-31TZ56400.book  213 ページ  ２０１７年８月２３日　水曜日　午後４時１分
