4. Remove the screws, then remove the center belt guide (A).

Fig. 78: Identifying Center Belt Guide And Screws
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Separate the seat-back covers/pads (A) and seat-back frame (B).

Fig. 79: Identifying Seat-Back Covers, Pads And Seat-Back Frame
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Pull back the edge of the seat-back cover (A) all the way around, and release the clips (B), then

remove the seat-back cover.



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Seats - RL



me



Friday, June 05, 2009 3:27:17 PM

Page 46

© 2005 Mitchell Repair Information Company, LLC.

Fig. 80: Identifying Seat-Back Cover And Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Install the cover in the reverse order of removal, and note these items:



To prevent wrinkles when installing a seat-back cover, make sure the material is stretched
evenly over the pad before securing the hook strips, and clips.



Replace any clips you removed with new ones. Install them with commercially available
upholstery ring pliers.

REAR SEAT CUSHION COVER REPLACEMENT

1. Remove the rear seat cushion (see REAR SEAT REMOVAL/INSTALLATION ).

2. Release all the clips (A) from under the seat cushion, and fold back the seat cushion cover.

Fig. 81: Identifying Rear Seat Cushion Cover Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Pull back the edge of the seat cushion coverall the way around, and release the clips (A), then remove

the seat cushion cover.



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Seats - RL



me



Friday, June 05, 2009 3:27:17 PM

Page 47

© 2005 Mitchell Repair Information Company, LLC.

Fig. 82: Identifying Rear Seat Cushion Cover Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Install the cover in the reverse order of removal, and note these items:



To prevent wrinkles, make sure the material is stretched evenly over the pad before securing the
clips.



Replace any clips (A) you removed with new ones. Install them with commercially available
upholstery ring pliers (B).

Fig. 83: Installing Upholstery Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

REAR SEAT ARMREST COVER REPLACEMENT

1. Remove the seat-back (see REAR SEAT REMOVAL/INSTALLATION ).

2. Remove the armrest from the seat-back (see REAR SEAT ARMREST REPLACEMENT ).

3. Remove the armrest beverage holder from the armrest (see REAR SEAT ARMREST BEVERAGE

HOLDER REPLACEMENT ).

4. Remove the E clips (A), then remove the brackets (B) from both sides of the armrest (C).

NOTE:

Take care not to tear the seams or damage the seat covers.



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Seats - RL



me



Friday, June 05, 2009 3:27:17 PM

Page 48

© 2005 Mitchell Repair Information Company, LLC.

Fig. 84: Identifying Rear Seat Armrest Cover, Bushing And E-Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. If necessary, remove the bushings (D) from the brackets.

6. Release the hooks (A).

Fig. 85: Identifying Rear Seat Armrest Cover Hooks
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Pull back the armrest cover (A) all the way around, and release the Velcro fasteners (B), then separate

the armrest cover and pad (C).

Fig. 86: Identifying Armrest Cover, Velcro Fasteners And Armrest Cover And Pad
Courtesy of AMERICAN HONDA MOTOR CO., INC.
