1. Wiper blade
Check the wear of wiper blade. If it is excessively worn, wipe out clean to sense the rain amount
accurately.
2. Coupler
Ensure the coupler surface on the windshield is free of bubbles. Verify that the coupler is properly
positioned.
3. Glass
Check the windshield glass surface beyond the sensing range for the excessive wear, scratch or crack.
Although the sensor compensates for wear to a certain level, sensor fails to sense accurately if it exceeds a
certain level. This is confirmed by the self-diagnosis of sensor.
4. Exterior cover
Ensure the exterior cover of the rain sensor is properly installed.
5. Spring clip
Check the spring clip after removal of exterior cover if the rain sensor is disconnected from coupler.
6. Connector
1. Check the terminal inside the connector and wiring for compression, and check the terminal
whether it is inserted and locked correctly.
2. In addition, check the wiring connector and rain sensor connector for assembly and confirm to
prevent poor connection
INSTALLATION
1. Install the rain sensor bracket to the windshield glass using the tape
NOTE:
In case of the windshield with reflection layer which reflects the infrared
rays in sensing field, remove the reflection layer from the rain sensor
mounting position prior to installation.
Bracket and spring slide need for installing the rain sensor, it is covered
by sensor cover.
