Fig. 65: Identifying Hog-Ring Clips And Seat Back Cover
Courtesy of KIA MOTORS AMERICA, INC.

8. Installation is the reverse of removal.

SEAT CUSHION COVER REPLACEMENT

1. Remove the seat assembly. See THIRD SEAT.

2. Remove the recliner cover. See RECLINER COVER REPLACEMENT.

3. Loosen the mounting bolts, then remove the seat back assembly (A).

Fig. 66: Identifying Seat Back Assembly With Mounting Bolts Location
Courtesy of KIA MOTORS AMERICA, INC.

4. Disconnect the protector (A) from the back frame.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 37

© 2006 Mitchell Repair Information Company, LLC.

Fig. 67: Identifying Protector
Courtesy of KIA MOTORS AMERICA, INC.

5. Disconnect the seat pad (B) from the back frame (A).

Fig. 68: Identifying Seat Pad And Back Frame
Courtesy of KIA MOTORS AMERICA, INC.

6. After removing the hog-ring clips (A) on the front of seat back remove the seat back cover (B).



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 38

© 2006 Mitchell Repair Information Company, LLC.

Fig. 69: Identifying Hog-Ring Clips And Seat Back Cover
Courtesy of KIA MOTORS AMERICA, INC.

7. Installation is the reverse of removal.

SEAT FRAME ASSEMBLY REPLACEMENT

1. Remove the cushion cover (A). See SEAT CUSHION COVER REPLACEMENT.

Fig. 70: Identifying Seat Pad And Back Frame
Courtesy of KIA MOTORS AMERICA, INC.

2. Installation is the reverse of removal.

SEAT BACK FRAME REPLACEMENT

1. Remove seat back cover (A). See RECLINER COVER REPLACEMENT.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 39

© 2006 Mitchell Repair Information Company, LLC.

Fig. 71: Identifying Frame
Courtesy of KIA MOTORS AMERICA, INC.

2. Installation is the reverse of removal.

SEAT BELT

REPLACEMENT

FRONT SEAT BELT REPLACEMENT

1. Remove the following items fist.



Front seat assembly. See FRONT SEAT.



Front and rear door scuff trim. See REPLACEMENT .

2. After raise the lower anchor cover (A), loosen the lower anchor mounting bolt (B).

CAUTION:



When installing the belt, make sure not to damage the pretensioner.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 40

© 2006 Mitchell Repair Information Company, LLC.
