Kia Sedona (2008 year). Manual - part 513

Fig. 27: Identifying Secondary Seat Components
Courtesy of KIA MOTORS AMERICA, INC.

THIRD SEAT



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 17

© 2006 Mitchell Repair Information Company, LLC.

Fig. 28: Identifying Third Seat Components
Courtesy of KIA MOTORS AMERICA, INC.

REPLACEMENT

SECONDARY SEAT

REMOVAL

1. Slide the seat to the rearward.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 18

© 2006 Mitchell Repair Information Company, LLC.

2. Back seat folding.

Fig. 29: Folding Back Seat
Courtesy of KIA MOTORS AMERICA, INC.

3. Remove the seat assembly (B) after pressing the lever (A).

Fig. 30: Removing Seat Assembly
Courtesy of KIA MOTORS AMERICA, INC.

INSTALLATION

1. Back seat folding.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 19

© 2006 Mitchell Repair Information Company, LLC.

Fig. 31: Folding Back Seat
Courtesy of KIA MOTORS AMERICA, INC.

2. Slide the seat to the rearward.

Fig. 32: Sliding Seat To Rearward
Courtesy of KIA MOTORS AMERICA, INC.

3. Lift the back side of the seat.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Seat - Sedona



Microsoft



Monday, May 24, 2010 3:50:58 PM

Page 20

© 2006 Mitchell Repair Information Company, LLC.
