C PILLAR TRIM REPLACEMENT

1. Remove the luggage trim. See LUGGAGE SIDE TRIM REPLACEMENT.

2. Remove the C pillar trim (A).

Fig. 55: Identifying C Pillar Trim Fastener Locations
Courtesy of KIA MOTORS AMERICA, INC.

LUGGAGE SIDE TRIM REPLACEMENT

1. Remove the rear door scuff trim. See REPLACEMENT.

2. Remove the fire extinguisher.

3. Remove the transverse trim.

4. Remove the luggage side trim (A).

5. Installation is the reverse of removal.

NOTE:



Put on gloves to protect your hands.



When prying with a flat-tipped screwdriver, wrap it with protective tape to
prevent damage.



Take care not to bend or scratch the trim and panels.

NOTE:



Put on gloves to protect your hands.



When prying with a flat-tipped screwdriver, wrap it with protective tape to
prevent damage.



Take care not to bend or scratch the trim and panels.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Monday, May 24, 2010 4:05:49 PM

Page 39

© 2006 Mitchell Repair Information Company, LLC.

Fig. 56: Identifying Luggage Side Trim Fastener Locations
Courtesy of KIA MOTORS AMERICA, INC.

WINDSHIELD GLASS

COMPONENTS



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Monday, May 24, 2010 4:05:49 PM

Page 40

© 2006 Mitchell Repair Information Company, LLC.

Fig. 57: Identifying Windshield Glass And Windshield Molding
Courtesy of KIA MOTORS AMERICA, INC.

REPLACEMENT

REMOVAL

1. Remove the following items.



Front pillar trim, both sides. See FRONT PILLAR TRIM.



Windshield wiper arms and cowl cover. See WINDSHIELD WIPER .

2. Remove the windshield glass side molding.

NOTE:



Put on gloves to protect your hands.



Use seat covers to avoid damaging any surfaces.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Monday, May 24, 2010 4:05:49 PM

Page 41

© 2006 Mitchell Repair Information Company, LLC.

Fig. 58: Removing Windshield Glass Side Molding
Courtesy of KIA MOTORS AMERICA, INC.

3. Cut out the sealant using the sealant cutting tool (A) (09861-31100).
