Kia Sedona (2008 year). Manual - part 450

Fig. 50: Identifying Cowl Side Trim Fastener Locations
Courtesy of KIA MOTORS AMERICA, INC.

3. Installation is the reverse of removal.

CENTER LOWER PILLAR TRIM REPLACEMENT

1. Remove the front seat belt lower anchor. See SEAT BELT .

2. Remove the front door scuff trim. See REPLACEMENT.

3. Remove the rear door scuff trim. See REPLACEMENT.

4. Remove the center lower pillar trim (A).

NOTE:



Replace any damage clips.

NOTE:



Put on gloves to protect your hands.



When prying with a flat-tipped screwdriver, wrap it with protective tape to
prevent damage.



Take care not to bend or scratch the trim and panels.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Monday, May 24, 2010 4:05:49 PM

Page 35

© 2006 Mitchell Repair Information Company, LLC.

Fig. 51: Identifying Center Lower Pillar Trim
Courtesy of KIA MOTORS AMERICA, INC.

5. Installation is the reverse of removal.

CENTER UPPER PILLAR TRIM REPLACEMENT

1. Remove the center lower pillar trim. See CENTER LOWER PILLAR TRIM REPLACEMENT.

2. Remove the center upper pillar trim (A).

NOTE:



Replace any damage clips.

NOTE:



Put on gloves to protect your hands.



When prying with a flat-tipped screwdriver, wrap it with protective tape to
prevent damage.



Take care not to bend or scratch the trim and panels.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Monday, May 24, 2010 4:05:49 PM

Page 36

© 2006 Mitchell Repair Information Company, LLC.

Fig. 52: Identifying Center Upper Pillar Trim Fastener Locations
Courtesy of KIA MOTORS AMERICA, INC.

3. Installation is the reverse of removal.

REAR PILLAR TRIM REPLACEMENT

1. Remove the luggage trim. See LUGGAGE SIDE TRIM REPLACEMENT.

2. Remove the tailgate lift (A).

3. Remove the rear pillar upper trim (B).

NOTE:



Replace any damage clips.

NOTE:



Put on gloves to protect your hands.



When prying with a flat-tipped screwdriver, wrap it with protective tape to
prevent damage.



Take care not to bend or scratch the trim and panels.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Monday, May 24, 2010 4:05:49 PM

Page 37

© 2006 Mitchell Repair Information Company, LLC.

Fig. 53: Identifying Tailgate Lift Fastener Locations
Courtesy of KIA MOTORS AMERICA, INC.

Fig. 54: Identifying Rear Pillar Upper Trim And Clip
Courtesy of KIA MOTORS AMERICA, INC.

4. Installation is the reverse of removal.

NOTE:



Replace any damage clips.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Monday, May 24, 2010 4:05:49 PM

Page 38

© 2006 Mitchell Repair Information Company, LLC.
