Fig. 20: Identifying ICM Relay Box Fig. 21: Identifying ICM Relay Connectors Terminals INSPECTION FRONT BLOWER Check for continuity between the terminals. 1. There should be continuity between the No. 1 in the ICM-A and No. 10 in the ICM-B terminals when power and ground are connected to the No. 7 in the ICM-A and No. 13 terminals in the ICM-B terminals. 2. There should be no continuity between the No. 1 in the ICM-A and No. 10 terminals in the ICM-B terminals when power is disconnected. REAR BLOWER Check for continuity between the terminals. 1. There should be continuity between the No. 4 in the ICM-A and No. 12 in the ICM-B terminals when power and ground are connected to the No. 2 in the ICM-A and No. 14 terminals in the ICM-B terminals.
