Connect test light between the terminal E(Y/G)
of the DRL harness E-18 and ground.
Is test light ON?
Yes
Go to next step
No
Repair open or short in the wire "Y/G" or replace.
7
Lock the parking brake and set the shift lever in
"N " position.
Start engine.
Connect test light between the terminal F(W) of
the DRL harness E-18 and ground.
Is test light ON?
Yes
Go to next step
No
Repair open or short in the wire "W" or replace.
8
Turn the ignition to OFF and connect the DRL
module.
Check for continuity between the terminal J(Y)
and ground when
1) the engine operates (alternator operates
normally),
2) the ignition switch is ON,
3) the parking brake release, and
4) the headlight switch is OFF.
Is battery voltage present?
Yes
Go to next step
No
Inspect DRL module.
9
Connect for continuity between the terminal
N(R/L) and ground when
1) the engine operates (alternator operates
normally),
2) the ignition switch is ON,
3) the parking brake release, and
4) the headlight switch is OFF.
Is battery voltage present?
Yes
Check for a poor connection at DRL module.
No
Inspect DRL module.
Circuit testing (DRL module)
Check for voltage or continuity with connected. Repair or replace as necessary.
Terminal
Function
Test condition
Specification
A
Ignition switch input.
Ignition switch ON
12V
Ignition switch OFF
0V
B
Light switch input.
Headlight switch OFF
0V
Headlight switch PARK or HEAD
12V
D
Battery voltage.
Constant
12V
E
Brake fluid LOW input.
Below LOW
0V
Above LOW
12V
F
Charging system input.
Abnormal operation
0V
Normal operation
12V
J
DRL relay control.
DRL condition
0V
Ignition switch ON
12V
L
Parking brake input.
Parking brake is unlocked
0V
Parking brake is locked
12V
M
Ground
Constant
GND
N
Tail, position, and license light control.
DRL condition
12V
None DRL condition
0V
DRL relay
1. Disconnect the DRL relay.
