Kia Carens. Manual - part 240

3. Remove adhesive from behind mirror glass and remove mirror glass.

Gloves and safety glasses should be worn when removing broken mirror glass

Installation

Outside rearview mirror assembly

1. Position outside rearview mirror assembly on door.

2. Install three retaining bolts.

3. Connect harness connector.

4. Install garnish.

5. Connect negative battery cable.

Installation

Outside rearview mirror glass

1. Install mirror glass with appropriate adhesive.

2. Heat frame and mirror glass using a heat gun.

3. Fasten mirror glass in mirror frame.

Body (Interior and Exterior)

Sunroof

Body (Interior and Exterior)

  2001 > 1.8L DOHC >



Sunroof system
