0K130 175 011A
Hanger, ttansaxle

Used to disassemble transaxle.

0K130 170 012
Remover, bearing

Used to remove bearing outer race.

0K201 170 AA0
Support, engine

Used to remove transaxle.

0K201 190 016
Leak checker

Used to disassemble/assemble 3-4 clutch.

0K130 322 020
Attachment

Used to measure bearing preload.

0K201 170 AA1
Installer, oil seal

Used to install oil seal.

0K201 190 AA1
Compressor set, return spring

Used disassemble/assemble clutch
assembly.

0K130 191 034
Holder, idler gear shaft

Used to adjust bearing preload.

0K201 190 017
Installer, oil seal

Used to remove oil seal

0K201 190 019
Holder, turbine shaft

Used to remove/install turbine shaft.

0K201 175 AA0
Selector set, shim

Used to adjust preload.

0K130 171 013
Puller, bearing

Used to remove differential bearing.

0K130 322 020
Preload, adapter

Used to measure preload.

0K2CA 190 AA2
Servo Piston Liffer

Used to press servo piston lifter.

0K2CA 190 AA1
Spring retainer assembly

Used to remove/install spring retainer
assembly.

SPEICIAL SERVICE TOOLS

Tool(Number & Name)

Illustrator

Use

0K201 170 AA0
Support, engine

Used to support engine.

0K130 990 007
Engine stand

Used to disassemble and assemble
transaxle.

0K201 323 321
Holder, Primary shaft

Used to hold primary shaft.

0K201 170 AA1
Installer, oil seal

Used to install oil seal.

0K670 990 AA0
Puller set, bearing

Used to remove bearing.

0K201 172 008
Removing plate

Used to remove gears.

0K130 171 013
Puller, bearing

Used to remove bearing

0K130 283 021
Puller, ball joint

Used to remove tie-rod end.

0K130 175 011A
Hanger, transaxle

Used to disassemble and assemble
transaxle.

0K130 170 012
Remover, bearing

Used to remove bearing

0K130 175 008
Puller, fan pulley boss

Used to remove gears.

0K900 175 AA1
Installer set, bearing

Used to install bearing.

0K130 178 A13
Body(Part 0K900 175 AA1)

Used to install gear and bearing inner race.

0K201 171 A01
Attachment A(Part of 0K900
175 AA1)

Used to install bearing inner race and gear.
