ENTERING THE CAR’S POSITION
• If the display highlights ‘INDEX’, the computer needs you to
If the car battery has been disconnected, or if the car has been
confirm the name (if there are two towns of the same name
transported to a new location on another vehicle (by trailer or
within the area covered by the navigation CD, for example). If
train, for example), the navigation will require up to 15 minutes to
this is the case, select INDEX and then highlight and select the
identify the new position. Entering the car’s position manually as
correct name from the list.
follows, reduces this delay:
• If the display highlights ‘ENTER’, simply press the menu select
control to enter the name.
From the main menu, scroll down to the next screen and highlight
and select ‘SETTINGS’.
From the SETTINGS menu, highlight and select ‘POSITION
POSITION VEHICLE
VEHICLE’.
NOTE: If the correct CD is in the navigation computer, the country is
CROSSING JUNCTION
automatically entered. If you have travelled to a new country, a new CD
is needed.
NOW
H2864
CITY?
Repeat the above procedure to enter the name of the road where
ABCDEFGHIJKLMNO
you are currently situated. The navigation computer asks you to
PQRSTUVW YZ
enter a ‘JUNCTION’. This is the name of the road that you will
next come to. Select ‘JUNCTION’, then enter the name using the
typewriter (if required), or select the correct road name if a list of
INDEX
names is displayed. ‘CROSSING JUNCTION NOW’ appears in
H2863
the display, requesting you to press the select menu control as you
cross the junction.
Highlight and select ‘CITY?’, then use the typewriter menu to
enter the town or city name. Once the name is entered, the bar at
Provided that the information entered into the computer is
the bottom of the display highlights ‘INDEX’ or ‘ENTER’,
correct, the navigation system only requires approximately 1
depending on the following:
minute to position the car and provide instructions on how to
reach your destination (if a destination has been entered).
178
Satellite Navigation System Settings
USER PREFERENCES
Changing the language setting
From the main menu, scroll down to the next screen to highlight
and select ‘SETTINGS’. From the SETTINGS menu, highlight
LANGUAGE
and select the setting which needs adjustment.
ENGLISH
Changing the volume setting for audible instructions
FRAN AIS
DEUTSCH
VOLUME
H2925
This setting changes the language of all menu and audible
instructions. Highlight and select ‘LANGUAGE’ to display all
3
available languages. Highlight and select the chosen language to
enter the new setting, or highlight and select the escape icon to
H2873
return to the Settings menu.
Highlight and select ‘VOLUME’. The display shows a slide scale
bar with an arrow indicating the current volume level. Use the
Changing the units of measurement
menu select control to move the arrow to the left or right, to
decrease or increase the volume level. To help you set the required
UNITS
volume, the navigation computer ‘voice’ is heard at the changed
volume as each adjustment is made. Press the menu select control
KM
to enter the new setting.
MLS
H2926
Highlight and select ‘UNITS’, then highlight and select either
‘KM’ to select metric, or ‘MLS’ to select imperial measurement. If
no change is required, highlight and select the escape icon to
return to the Settings menu.
179
Security Code
Security Code
SECURITY CODE INFORMATION
ENTERING THE SECURITY CODE
To reduce the risk of theft, your audio unit was programmed with
If power to the audio unit has been interrupted (car battery
a four-digit security code before the car left the factory. Once
disconnected, for example), the code MUST be entered before the
activated, this code prevents the unit from functioning if it is
unit can be operated. Enter the code as follows:
illegally removed from the car.
CD32 audio
In addition, each unit is further protected by a time delay penalty
• Switch on the radio (‘CODE’ appears in the display, followed
system. If an incorrect code is entered:
by ‘0000’).
• CD32 audio: A one hour time delay is imposed after the third
• Press pre-set button 1 the required number of times to enter the
and all subsequent code entry attempts.
first digit of the code.
• Harmony & Symphony audio: A one minute time delay is
• Press pre-set button 2 the required number of times to enter the
imposed after the first code entry attempt. Thereafter, the time
second digit of the code.
delay doubles (2 min, 4 min, 8 min, etc.) with each failed
• Repeat this process using pre-set buttons 3 and 4 to enter the
attempt.
third and fourth digits of the code.
Your car was supplied with a Security Information card. This card
• When the correct code is displayed, press the
control to
contains a record of the four digit security code, as well as the
store the code.
audio unit's unique serial number. The serial number is also
stamped into the metal side of the audio unit and, in the event of
NOTE: If three incorrect codes hare been entered, the first one hour time
theft, would confirm proof of ownership.
delay period commences. During the delay period, ‘WAIT 1 H’ appears
in the display - DO NOT switch off. At the end of the delay period,
It is VERY IMPORTANT that you keep a safe record of the
‘CODE’ reappears in the display and you can then enter the correct code.
security code and heed the following advice:
• NEVER keep a record of the security code in the car.
• If you lose your code number, contact an MG Rover dealer,
who will be able to obtain this information for you.
180
Security Code
Harmony and Symphony audio
• Switch on the radio (‘CODE’ appears in the display). Press pre-
set button 1.
• Press either the up or down tuning button until the first digit
of the security code appears in the display. Press pre-set 1 to
store the first digit in the unit's memory.
• Use either tuning button to select the second digit of the code
(until the correct digit appears in the display). Press pre-set 1 to
store the second digit.
• Select the third digit, again using the tuning buttons (until the
correct digit is displayed). Press pre-set 1 to store the third digit.
• Select the final digit (the display now shows the full four digit
3
code). Press pre-set 1 to store the final digit.
If the correct code has been selected the radio will commence
operating immediately.
NOTE: If an incorrect code has been entered, the first time delay period
commences. During the delay period, ‘CODE WAIT’ appears in the
display - DO NOT switch off. At the end of the delay period, ‘CODE’
reappears in the display and you can then enter the correct code. Remember;
the time delay period doubles each time an incorrect code is entered.
181
Maintenance
184
Maintenance
188
Bonnet Opening
189
Engine Compartment
192
Engine
194
Cooling System
196
Brakes
198
Power Steering
200
Battery
203
Washers
204
Wipers
4
206
Tyres
209
Cleaning & Vehicle Care
212
Identification Numbers
214
Parts & Accessories
Maintenance
Maintenance
Maintenance
For example, a car subjected predominantly to short journey
ROUTINE SERVICING
motoring, will consume more fuel, resulting in a more rapid
The safety, reliability and performance of your car will depend
deterioration of the engine oil. In this case, the service distance
partly on how well it is maintained.
indicator will reduce more rapidly, reaching zero after the car has
Maintenance is the owner's responsibility and you must ensure that
travelled as few as 19,000 or 20,000 km. Conversely, the driver of
owner maintenance operations, oil services, inspections and brake
a car used mainly for long motorway journeys, driving carefully
fluid and coolant changes are carried out when required and
and within the speed limit, may well find that the service distance
according to the manufacturer's recommendations.
indicator does not ‘zero’ until the car has exceeded 24,150 km.
Oil services and inspections
NOTE: If a service is not carried out (or the dealer fails to reset the
The service interval display in the instrument panel shows the next
display), the distance indicator, having reached zero, will then start to
service type (Oil Service or Inspection) and the distance remaining
accumulate, but with minus values, indicating the distance by which a
before the next service is due. This display appears for 4 seconds
service is overdue.
every time the starter switch is initially turned to the second
Service history
position.
This handbook includes a Service History section, which enables
The distance display commences at 24,150 km and progressively
a record to be kept of all the oil services and inspections that are
reduces in increments of 50 km as the car is driven, until zero is
carried out on the car. This section of the book also provides a
reached. The relevant service should be carried out after 12
facility for the dealer to record brake fluid and coolant changes, as
months or as soon as the distance display shows zero (whichever is
well as the fitting of replacement airbag modules and seat belt pre-
the sooner). After the completion of each service, the servicing
tensioners.
dealer will reset the distance display to 24,150 km.
Ensure your dealer signs and stamps the book after each oil service
NOTE: Because the service interval display reduces in increments of
and inspection.
50 km, it is possible to undertake a short journey without triggering any
movement from the display.
While the oil services and inspections have nominal distance and
time-related intervals of 24,150 km or 12 months, by measuring
fuel consumption the car’s monitoring system is also able to assess
the owner’s driving style and the type of motoring to which the
car is subjected. These additional factors will affect the point at
which the service should be carried out.
184
Maintenance
Brake fluid replacement
EMISSION CONTROL
The brake fluid requires replacement every two years, irrespective
Your car is fitted with emission and evaporative control equipment
of the distance the car has travelled. Normally, the brake fluid
designed to meet specific territorial and legal requirements. You
change indicator on the instrument panel will commence
should be aware that unauthorised replacement, modification or
illuminating (for four seconds every time the starter switch is
tampering with this equipment by an owner or motor vehicle
initially turned to the second position) as soon as each two year
repairer could be unlawful and subject to legal penalties.
period has elapsed (see ‘Service interval display (3)’, page 75).
In addition, engine settings must not be tampered with. These
However, if an impending oil service or inspection falls due within
have been established to ensure that your car complies with
a period of up to 180 days prior to the brake fluid change
stringent exhaust emission regulations. Incorrect engine settings
becoming due, then the indicator will illuminate earlier. This will
may adversely affect exhaust emissions, engine performance and
enable the dealer to combine the brake fluid change with the oil
fuel consumption, as well as causing high temperatures, which
service or inspection, thereby avoiding the need for an additional
could result in damage to the catalytic converters and engine.
dealer visit.
NOTE: Brake fluid replacement will be an additional cost.
Coolant replacement
The engine coolant (anti-freeze and water solution) needs to be
replaced every four years regardless of the distance the car has
4
travelled. Your dealer will replace the coolant at the scheduled oil
service or inspection nearest to the conclusion of each four year
period, to avoid the need for an additional dealer visit.
NOTE: Coolant replacement will be an additional cost.
185
Maintenance
OWNER MAINTENANCE
SPECIAL OPERATING CONDITIONS
In addition to the routine services and inspections referred to
If your car is frequently used in dusty conditions, or operated in
previously, a number of simple checks must be carried out more
extreme climates where sub-zero or very high ambient
frequently. You can carry out these checks yourself and advice is
temperatures are normal, more frequent attention may need to be
given on the pages that follow.
paid to servicing requirements. Contact an MG Rover dealer for
advice.
Any significant or sudden drop in fluid levels, or uneven tyre
wear, should be reported to a dealer without delay.
Daily checks
• Operation of lights, horn, direction indicators, wipers, washers
and warning lights.
• Operation of seat belts and brakes.
• Look for fluid deposits underneath the car that might indicate
a leak.
Weekly checks
• Engine oil level.
NOTE: The engine oil level should be checked more frequently if the
car is driven for prolonged periods at high speeds.
• Coolant level.
• Brake fluid level.
• Power steering fluid level.
• Screen washer fluid level.
• Tyre pressures and condition.
• Operate air conditioning*.
186
Maintenance
SAFETY IN THE GARAGE
Poisonous fluids
Cooling fans may commence operating after the engine is
It is illegal to pollute drains, water courses or soil. Use authorised
switched off, and continue operating for a number of minutes.
waste disposal sites to dispose of used oil and toxic chemicals.
Keep clear of all fans while working in the engine compartment.
Fluids used in motor vehicles are poisonous and should not be
If you need to carry out maintenance, observe the following safety
consumed or brought into contact with open wounds. These
precautions at all times:
include: battery acid, anti-freeze, brake and power steering fluid,
• Keep your hands and clothing away from drive belts and
petrol, diesel, engine oil and windscreen washer additives.
pulleys.
For your own safety, ALWAYS read and obey all instructions
• If the car has been driven recently, DO NOT TOUCH
printed on labels and containers.
exhaust and cooling system components until the engine has
cooled.
Used engine oil
Prolonged contact with engine oil may cause serious skin
• DO NOT TOUCH electrical leads or components while the
disorders, including dermatitis and cancer of the skin. Wash
engine is running, or with the starter switch turned on.
thoroughly after contact.
• NEVER leave the engine running in an unventilated area -
exhaust gases are poisonous and extremely dangerous.
• DO NOT work underneath the car with a wheel changing jack
4
as the only means of support.
• Ensure sparks and naked lights are kept away from the engine
compartment.
• Wear protective clothing, including, where practicable, gloves
made from an impervious material.
• Remove metal wrist bands and jewellery before working in the
engine compartment.
• DO NOT allow tools or metal parts of the car to make contact
with the battery leads or terminals.
187
Bonnet Opening
Bonnet Opening
BONNET OPENING
1. From inside the car, pull the bonnet release handle.
2. Release the bonnet safety catch. Dependent on the model,
DO NOT drive with the bonnet retained by the safety catch
one of two different release mechanisms will be fitted:
alone.
A. Push the lever mounted on the bonnet locking platform
towards the rear of the car.
B. Lift the lever, which protrudes through the front grille.
3. Raise the bonnet.
Closing the bonnet
Lower the bonnet. When the bonnet is approximately 150 mm
from its closed position, push down evenly using the palms of both
hands on the leading edge of the bonnet on either side of the
1
radiator grille.
After closing the bonnet, check that the lock is fully engaged by
attempting to lift the front edge of the bonnet. This should be free
from all movement.
A
B
HB0232a
188
Engine Compartment
Engine Compartment
1.8 PETROL ENGINES (including turbo)
1. Power steering reservoir (black cap)
2. Brake reservoir (black cap)
3. Cooling system reservoir
4. Engine oil filler (yellow cap)
5. Engine oil dipstick (yellow)
1
2
3
6. Washer reservoir (blue cap)
4
6
5
4
H2831a
While working in the engine compartment, always observe the safety precautions listed
under ‘SAFETY IN THE GARAGE’, page 187.
189
Engine Compartment
2.0 & 2.5 PETROL ENGINE
1. Engine oil dipstick (yellow)
2. Brake reservoir (black cap)
3. Engine oil filler (yellow cap)
4. Cooling system reservoir
5. Power steering reservoir (black cap)
1
2
3
6. Washer reservoir (blue cap)
6
5
4
H2837a
While working in the engine compartment, always observe the safety precautions listed
under ‘SAFETY IN THE GARAGE’, page 187.
190
Engine Compartment
2.0 DIESEL ENGINE
1. Engine oil filler (yellow cap)
2. Brake reservoir (black cap)
3. Engine oil dipstick (yellow)
4. Cooling system reservoir
5. Power steering reservoir (black cap)
1
2
3
6. Washer reservoir (blue cap)
4
6
5
4
H2838a
While working in the engine compartment, always observe the safety precautions listed
under ‘SAFETY IN THE GARAGE’, page 187.
191
Engine
Engine
ENGINE OIL
Driving the car with the engine oil level ABOVE the upper
mark, or BELOW the lower mark on the dipstick, will
damage the engine.
Check the oil level weekly, or whenever you fill up with fuel.
Ideally the oil level should be checked with the engine cold and
the car resting on level ground. However, if the car is in use and
the engine is already warm, wait for at least two minutes after
switching off before checking the level.
NOTE: Check the engine oil more frequently if the car is driven at high
speeds for prolonged periods.
Oil level check & top-up
H2673
Petrol engines
Take care to avoid spilling engine oil onto a hot engine - a fire
may result!
1. Withdraw the dipstick and wipe the blade clean.
2. Slowly insert the dipstick and withdraw again to check the
level, which should NEVER be allowed to fall below the
lower mark on the dipstick.
3. To top-up, remove the oil filler cap and add oil to maintain a
level between the upper and lower marks on the dipstick. As
a general guide, if the level on the dipstick is:
• nearer to the upper mark than the lower, add no oil.
• nearer to the lower mark than the upper, add half a litre
of oil.
• at or below the lower mark, add one litre of oil.
4. Wait for five minutes and then recheck the level, adding more
H2672
oil if necessary - DO NOT OVERFILL!
Diesel engines
5. Finally, ensure the dipstick and filler cap are replaced.
192
Engine
Oil specification
Model/engine
Approved viscosity
Minimum oil specification
‘75’ 1.8 petrol models †
10W/40
ACEA A1
ACEA A2
-
‘75’ 1.8 petrol turbo models
10W/40
ACEA A3
‘75’ 2.0 petrol models
10W/40
ACEA A2
-
‘75’ 2.5 petrol models
10W/40
ACEA A2
-
75’ 2.0 diesel models † †
10W/40 or 15W/40
ACEA A3 & B3
‘ZT’ 160 models
10W/40
ACEA A2
-
‘ZT’ 190 models
10W/40
ACEA A3
† For 1.8 (non-turbo) petrol engines, ACEA A1 or A2 oils can be used - the A1 specification may improve fuel economy.
† † Oils for 2.0 litre diesel engines must meet both ACEA A3 and ACEA B3 specifications.
To ensure optimum engine life and performance, oils used for
Oils manufactured to the specifications shown in the table are
4
topping-up and refilling the engine must match the minimum
suitable for use in temperatures between -20°C to 30°C (if climatic
ACEA specifications shown in the table. Oils of a higher numerical
temperature falls outside these limits, seek advice from your
specification can also be used (e.g. ACEA A3 oils can be used in
dealer).
place of ACEA A2 oils for ‘ZT’ 160 models), but oils of a lower
NOTE: Mixing oil additives with the engine oil is not recommended and
numerical value must NEVER be used!
could damage the engine.
193
