MINI Paceman (2016 year). Manual - part 9





-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Wheels and tires
Minimum tread depth
WARNING
Damaged tires can lose tire inflation pres-
sure, which can lead to loss of vehicle control.
There is risk of an accident. If tire damage is
suspected while driving, immediately reduce
speed and stop. Have wheels and tires
checked. For this purpose, drive carefully to the
nearest dealer’s service center or another
qualified service center or repair shop. Have
vehicle towed or transported as needed.
Wear indicators in the tread base are distrib-
WARNING
uted around the circumference of the tire and
Damaged tires can lose tire inflation pres-
are marked on the tire sidewall with TWI, Tread
sure, which can lead to loss of vehicle control.
Wear Indicator. When the tire tread has been
There is risk of an accident. Do not repair dam-
worn down to the wear indicators, a tread has
aged tires, but have them replaced.
reached a depth of 0.063 in/1.6 mm.
Tire age
Tire damage
Recommendation
General information
For several reasons, among other things be-
Inspect your tires often for damage, foreign ob-
cause of beginning brittleness, the manufac-
jects lodged in the tread, and tread wear.
turer of your MINI recommends mounting new
tires at the latest after six years, regardless of
Information
the actual wear.
Driving over rough or damaged road surfaces,
as well as debris, curbs and other obstacles can
Manufacture date
cause serious damage to wheels, tires and sus-
The date of manufacture of the tires is specified
pension parts. This is more likely to occur with
in the tire label:
low-profile tires, which provide less cushioning
DOT … 2015: the tire was manufactured in
between the wheel and the road. Be careful to
week 20 of 2015.
avoid road hazards and reduce your speed, es-
pecially if your vehicle is equipped with low-
profile tires.
Changing wheels and
Indications of tire damage or other vehicle mal-
functions:
tires
Unusual vibrations during driving.
Mounting
Unusual handling such as a strong ten-
Have mounting and wheel balancing carried
dency to pull to the left or right.
out by a dealer’s service center or another
Damage can be caused by driving over curbs,
qualified service center or repair shop.
road damage and similar situations.
160

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Wheels and tires
MOBILITY
Wheel and tire combination
Recommended tire brands
Information on the right wheel/tire combina-
tion and wheel rim versions for your vehicle can
be obtained from the dealer’s service center or
another qualified service center or repair shop.
Incorrect wheel and tire combinations impair
the function of a variety of systems such as ABS
or DSC.
To maintain good handling and vehicle re-
sponse, use only tires with a single tread con-
figuration from a single manufacturer.
For each tire size, the manufacturer of your ve-
hicle recommends certain tire brands. These
Following tire damage, have the original wheel
can be identified by a star on the tire sidewall.
and tire combination remounted on the vehicle
as soon as possible.
WARNING
Retreaded tires
Wheels and tires which are not suitable
WARNING
for your vehicle can damage parts of the vehi-
Retreaded tires can have different tire
cle, e.g. due to contact with the body due to
casing structures. With advanced age the serv-
tolerances despite the same official size rating.
ice life can be limited. There is risk of an acci-
There is risk of an accident.
dent. The manufacturer of your vehicle does
not recommend the use of retreaded tires.
Wheels with electronics for TPM Tire
Pressure Monitor
Winter tires
When mounting new tires or changing from
The manufacturer of your vehicle recommends
summer to winter tires or vice versa, only use
winter tires for winter roads or at temperatures
wheels with TPM electronics; otherwise, the
below +45 ℉/+7 ℃.
Tire Pressure Monitor will not be able to detect
Although so-called all-season M+S tires do pro-
a flat tire, refer to page 79. A dealer’s service
vide better winter traction than summer tires,
center will be glad to answer any questions you
they do not provide the same level of perform-
may have.
ance as winter tires.
Maximum speed of winter tires
If the maximum speed of the vehicle is higher
than the permissible speed for the winter tires,
then display a corresponding sign in the field of
vision. The sign is available from the tire dealer
or from a dealer’s service center or another
qualified service center or repair shop.
With mounted winter tires, observe and adhere
to the permissible maximum speed.
161

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Wheels and tires
Run-flat tires
Run-flat tires are tires that support themselves
for a limited period of time, and they may also
When mounting new tires or changing from
come with special rims. The sidewall reinforce-
summer to winter tires or vice versa, use run-
ment ensures that the tire can continue to be
flat tires for your own safety. Also, a compact
used to a limited extent if it has lost pressure
wheel is not available in case of a flat tire. A
and even if it has become completely depres-
dealer’s service center will be glad to answer
surized.
any questions you may have.
For continued driving in the event of a flat tire,
Rotating wheels between axles
refer to page 78.
Different wear patterns occur on the front and
rear axles, depending on the individual condi-
tions of use.
Correcting a flat tire
To ensure even wear on the tires, the wheels
can be rotated between the axles. A dealer’s
Safety measures
service center will be glad to answer any ques-
Park the vehicle as far as possible from
tions you may have.
passing traffic and on solid ground. Switch
After changing the tires, check the tire inflation
on the hazard warning system.
pressure and correct it if necessary.
Let the steering wheel lock engage with the
wheels in the straight-ahead position, set
Storage
the parking brake, and engage first gear or
Store wheels and tires in a cool, dry place with
reverse, or engage selector lever position P.
as little exposure to light as possible.
Have all vehicle occupants get out of the
Always protect tires against all contact with oil,
vehicle and ensure that they remain out-
grease and fuels.
side the immediate area in a safe place,
such as behind a guardrail.
Do not exceed the maximum tire inflation pres-
sure indicated on the side wall of the tire.
If a warning triangle or portable hazard
warning lamp is required, set it up on the
roadside at an appropriate distance from
the rear of the vehicle. Comply with all
Run-flat tires
safety guidelines and regulations.
The procedure to correct a flat tire depends on
Label
the equipment in the vehicle:
Run-flat tires, refer to page 162.
MINI Mobility System, refer to page 162.
MINI Mobility System
Information
Follow the instructions on using the Mobi-
The symbol identifying run-flat tires is a circle
lity System found on the compressor and
with the letters RSC on the sidewall.
sealant bottle.
162

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Wheels and tires
MOBILITY
Use of the Mobility System may be ineffec-
8
Pressure gauge for displaying the tire infla-
tive if tire damage is greater than approx.
tion pressure
1/8 in/4 mm in size.
9
Release button for reducing the tire infla-
Contact a dealer’s service center or another
tion pressure
qualified service center or repair shop if the
tire cannot be made drivable.
The connector, cable, and connecting hose are
stowed in the compressor housing.
If possible, do not remove foreign bodies
that have penetrated the tire.
Using the Mobility System
Pull the speed limit sticker off the sealant
To repair a flat tire with the Mobility System,
bottle and apply it to the steering wheel.
proceed as follows:
Sealant and compressor
Filling the tire with sealant
Distributing the sealant
Correcting the tire inflation pressure
Filling the tire with sealant
1. Shake the sealant bottle.
2. Pull the connection hose 6 fully out of the
compressor housing and screw it onto the
sealant bottle connection. Ensure that the
connection hose is not kinked.
1
Sealant bottle and speed limit sticker
3. Insert the sealant bottle into the compres-
2
Filling hose
sor housing in a vertical position.
Note the use-by date on the sealant bottle.
4. Unscrew the dust cap off of the valve of the
not working wheel and screw the filling
hose 2 of the sealant bottle onto the valve.
3
Holder for the sealant bottle
4
Compressor
5. Ensure that the compressor is switched off.
5
Connector and cable for the lighter socket/
6. Insert connector 5 into the lighter socket/
socket in passenger compartment
101.
socket in the passenger compartment, refer
6
Connection hose for connecting the com-
to page 101.
pressor and sealant bottle or the compres-
7. When the engine is running:
sor and wheel
7
On/off switch
163

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Wheels and tires
Switch on the compressor and let it run for
Distributing the sealant
approx. 3 to 8 minutes to fill sealant into
Drive approx. 3.1 miles/5 km to evenly distrib-
the tire and achieve a tire inflation pressure
ute the sealant.
of approx. 1.8 bar/26 psi.
Do not exceed a speed of 50 mph/80 km/h. If
While sealant is being filled, the inflation
possible, do not drop below a speed of
pressure may intermittently rise to approx.
10 mph/20 km/h.
5 bar/73 psi. Do not switch off the com-
pressor in this phase.
Correcting the tire inflation pressure
8. Switch off the compressor.
1. After driving approx. 3.1 miles/5 km, or
CAUTION
about 10 minutes, stop in a suitable loca-
tion.
The compressor can overheat during ex-
tended operation. There is risk of property
2. Screw the connection hose 6 of the com-
damage. Do not run the compressor for more
pressor directly onto the tire valve.
than 10 min.
3. Insert the connector 5 into the power
socket in the passenger compartment.
If an air pressure of 1.8 bar/26 psi is not
reached:
4. Correct the tire inflation pressure to
1.8 bar/26 psi. When the engine is running:
1. Unscrew the filling hose 2 from the wheel
To increase the inflation pressure:
and drive forward and back approx.
switch on the compressor. To check the
33 ft/10 m to evenly distribute the sealant
currently set inflation pressure, switch
in the tire.
off the compressor.
2. Inflate the tire again using the compressor.
To reduce the inflation pressure: press
If the inflation pressure of 1.8 bar/26 psi is still
the release button 9.
not reached, the tire is too heavily damaged.
CAUTION
Contact a dealer’s service center or another
qualified service center or repair shop.
The compressor can overheat during ex-
tended operation. There is risk of property
Stowing the Mobility System
damage. Do not run the compressor for more
than 10 min.
1. Unscrew the filling hose 2 of the sealant
bottle from the wheel.
If the inflation pressure is not maintained, take
2. Unscrew the compressor connection hose 6
the vehicle on another drive, distributing the
from the sealant bottle.
sealant, refer to page 164. Then repeat steps
1 to 4 once.
3. Connect the filling hose 2 of the sealant
bottle with the free connector on the seal-
If the inflation pressure of 1.8 bar/26 psi is still
ant bottle.
not reached, the tire is too heavily damaged.
Contact a dealer’s service center or another
This prevents left-over sealant from escap-
qualified service center or repair shop.
ing from the bottle.
4. Wrap the empty sealant bottle in suitable
Continuing the trip
material to avoid dirtying the cargo area.
Do not exceed the maximum permissible speed
5. Stow the Mobility System back in the vehi-
of 50 mph/80 km/h.
cle.
Replace the not working tire as soon as possi-
ble and have the wheel balanced.
164

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Wheels and tires
MOBILITY
Have the Mobility System refilled.
Snow chains
The manufacturer of your vehicle recommends
use of fine-link snow chains. Certain types of
fine-link snow chains have been tested by the
manufacturer of the vehicle and recommended
as road-safe and suitable.
Information regarding suitable snow chains is
available from a dealer’s service center or an-
other qualified service center or repair shop.
Use only in pairs on the front wheels, equipped
with tires of the following size:
195/60 R 16 M+S
With ALL4 all-wheel drive: only mount snow
chains on the front wheels.
Observe the manufacturer's instructions when
mounting snow chains. Do not exceed a speed
of 30 mph or 50 km/h when using snow chains.
Do not initialize the Flat Tire Monitor if snow
chains are mounted; otherwise, the instrument
might issue an incorrect reading.
Do not initialize the Tire Pressure Monitor if
snow chains are mounted; otherwise, the in-
strument might issue an incorrect reading.
When driving with snow chains, it may be use-
ful to temporarily deactivate DSC or activate
DTC, refer to page 84.
165

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Engine compartment
Engine compartment
necessarily available in your car, e. g., due to
Vehicle features and op-
the selected options or country versions. This
tions
also applies to safety-related functions and sys-
tems.
This chapter describes all standard, country-
specific and optional features offered with the
When using the features and systems described
series. It also describes features that are not
here, adhere to local regulations.
Important features in the engine compartment
1
Vehicle identification number
5
Coolant expansion tank
170
2
Battery, under the cover
182
6
Engine compartment fuse box
183
3
Dip stick for engine oil
168
7
Reservoir for washer fluid for the headlight
and window washer system
57
4
Engine oil filler neck
168
166

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Engine compartment
MOBILITY
3. Press the release handle and open the
Hood
hood.
Information
WARNING
Improperly executed work in the engine
compartment can damage vehicle components
and impair vehicle functions. There is a risk of
personal and property damage. The manufac-
turer of your vehicle recommends that, in the
effort to avoid such risks, work in the engine
compartment be performed by a dealer’s serv-
ice center or another qualified service center or
WARNING
repair shop.
There are protruding parts, e.g. lock
hook, on the inside of the hood. There is risk of
CAUTION
injuries. If the hood is open, pay attention to
Folded-away wipers can be jammed
protruding parts and keep these areas clear.
when the hood is opened. There is risk of prop-
erty damage. Make sure that the wipers with
Closing the hood
the wiper blades mounted are folded down
onto the windshield before opening the
hood.
Unlocking and opening the hood
1. Pull the lever.
Close the hood from a height of ap-
prox. 16 in/40 cm with momentum. It must be
clearly heard to engage.
WARNING
An incorrectly locked hood can open
2. Lift the hood all the way.
while driving and restrict visibility. There is risk
of an accident. Stop immediately and correctly
close the hood.
WARNING
Body parts can be jammed on opening
and closing the hood. There is risk of injuries.
Make sure that the area of movement of the
hood is clear during opening and closing.
167

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Engine oil
Engine oil
The oil level must be between the two
Engine oil
marks on the dip stick.
Vehicle features and options
This chapter describes all standard, country-
specific and optional features offered with the
series. It also describes features that are not
necessarily available in your car, e. g., due to
the selected options or country versions. This
also applies to safety-related functions and sys-
tems.
When using the features and systems described
here, adhere to local regulations.
The oil quantity between the two marks on the
dip stick equals approx. 1 US quart/1 liter.
General information
Do not exceed the high mark of the dip stick.
Engine oil consumption depends on the driving
style and the conditions of use. A highly sporty
Adding engine oil
driving style, for example, results in considera-
bly higher engine oil consumption.
Filler neck
Therefore, regularly check the engine oil level
after refueling.
Checking the oil level with a dip stick
1. Park the vehicle on level ground when the
engine is at operating temperature, i.e., af-
ter driving continuously for at least
6 2 miles/10 km.
2. Switch the engine off.
Add a maximum quantity of 1 US quart/1 liter
3. After approx. 5 minutes, pull out the dip
of oil only after the corresponding message ap-
stick and wipe it off with a lint-free cloth,
pears on the Control Display or, in diesel en-
paper towel, etc.
gines, after the oil level is just above the low
4. Carefully insert the dip stick all the way into
mark of the dip stick, refer to page 168.
the measuring tube and pull it out again.
CAUTION
A too low engine oil level causes engine
damage. There is risk of property damage.
Add engine oil within the next
30 miles/50 km.
168

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Engine oil
MOBILITY
CAUTION
Gasoline engine
Too much engine oil can damage the en-
BMW Longlife-01
gine or the catalytic converter. There is risk of
property damage. Do not add too much engine
BMW Longlife-01 FE
oil. Have excess engine oil suctioned off by a
dealer’s service center or another qualified
Further information regarding suitable engine
service center or repair shop.
oil ratings and viscosities can be obtained from
a dealer’s service center or another qualified
WARNING
service center or repair shop.
Operating materials, e.g. oils, greases,
coolants, fuels, can contain harmful ingredi-
Alternative engine oil types
ents. There is risk of injuries or danger to life.
If an engine oil suitable for continuous use is
Observe the instructions on the containers.
not available, up to 1 US quart/liter of an en-
Avoid the contact of articles of clothing, skin or
gine oil with the following oil rating can be
eyes with operating materials. Do not refill op-
added:
erating materials into different bottles. Store
operating materials out of reach of children.
Gasoline engine
API SL or superior oil rating
Engine oil types to add
Engine oil change
Information
The vehicle manufacturer recommends that
CAUTION
you let the dealer’s service center or another
Oil additives can damage the engine.
qualified service center or repair shop change
There is risk of property damage. Do not use oil
the engine oil.
additives.
CAUTION
Incorrect engine oil can cause malfunc-
tions in the engine or damage it. There is risk of
property damage. When selecting an engine
oil, make sure that the engine oil has the cor-
rect viscosity grade.
The engine oil quality is critical for the life of the
engine.
Viscosity grades
When selecting an engine oil, ensure that the
engine oil belongs to one of the viscosity
grades SAE 0W-40, SAE 0W-30, SAE 5W-40, and
SAE 5W-30.
Suitable engine oil types
Add engine oils that meet the following oil rat-
ing standards:
169

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Coolant
Coolant
Vehicle features and op-
Coolant temperature
tions
If the coolant and therefore the engine over-
heat, a warning lamp lights up, refer to
This chapter describes all standard, country-
page 194.
specific and optional features offered with the
series. It also describes features that are not
necessarily available in your car, e. g., due to
the selected options or country versions. This
Coolant level
also applies to safety-related functions and sys-
tems.
Checking
When using the features and systems described
1. Do not open the hood until the engine has
here, adhere to local regulations.
cooled down.
2. Turn the expansion tank cap counterclock-
wise slightly to allow any accumulated
General information
pressure to escape; then continue turning
to open.
WARNING
3. The coolant level is correct if it is between
With the engine hot and the cooling sys-
the markings. The markings are located on
tem open, coolant can escape and lead to
the side of the coolant reservoir.
burns. There is risk of injuries. Only open the
cooling system with the engine cooled down.
WARNING
Additives are harmful and incorrect addi-
tives can damage the engine. There is risk of in-
juries and risk of property damage. Avoid the
contact of articles of clothing, skin or eyes with
additives. Do not swallow any additives. Use
suitable additives only.
Coolant consists of water and additives.
Refilling
Not all commercially available additives are
1. Do not open the hood until the engine has
suitable for the vehicle. Information regarding
cooled down.
suitable additives is available from a dealer’s
2. Turn the expansion tank cap counterclock-
service center or another qualified service cen-
wise slightly to allow any accumulated
ter or repair shop.
pressure to escape, then continue turning
to open.
3. If the coolant level is low, slowly add cool-
ant up to the specified level; do not overfill.
170

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Coolant
MOBILITY
4. Twist the cap closed.
5. Have the cause of the coolant loss elimi-
nated as soon as possible.
Disposal
Comply with the appropriate environ-
mental protection regulations when dis-
posing of coolant additives.
171

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Maintenance
Maintenance
The system makes it possible to adapt the
Vehicle features and op-
amount of maintenance you need to your user
tions
profile.
This chapter describes all standard, country-
Detailed information on service requirements
specific and optional features offered with the
can be displayed in the tachometer, refer to
series. It also describes features that are not
page 66.
necessarily available in your car, e. g., due to
the selected options or country versions. This
Service data in the remote control
also applies to safety-related functions and sys-
Information on the required maintenance is
tems.
continuously stored in the remote control. The
When using the features and systems described
dealer’s service center can read this data out
here, adhere to local regulations.
and suggest an optimized maintenance scope
for your vehicle.
Therefore, hand the service advisor the remote
MINI maintenance system
control with which the vehicle was driven most
recently.
Make sure the date is set correctly; otherwise,
the effectiveness of CBS Condition Based Serv-
ice is not ensured.
Storage periods
Storage periods during which the vehicle bat-
tery was disconnected are not taken into ac-
count.
The MINI maintenance system provides infor-
If this occurs, have a dealer's service center or
mation on required maintenance measures and
another qualified service center or repair shop
thus provides support in maintaining road
update the time-dependent maintenance pro-
safety and the operational reliability of the ve-
cedures, such as checking brake fluid and, if
hicle.
necessary, changing the engine oil and the mi-
crofilter/activated-charcoal filter.
Condition Based Service
Service and Warranty In-
CBS
formation Booklet for
Sensors and special algorithms take into ac-
US models and Warranty
count the various driving conditions of your
MINI. Based on this, Condition Based Service
and Service Guide Book-
determines the current and future mainte-
let for Canadian models
nance requirements.
Please consult your Service and Warranty Infor-
mation Booklet for US models and Warranty
172

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
MOBILITY
and Service Guide Booklet for Canadian models
Emissions
for additional information on service require-
The warning lamps light up. The vehicle
ments.
is producing higher emissions. Further
The manufacturer of your vehicle recommends
driving at a moderate pace is possible.
that maintenance and repair be performed by a
Have the vehicle checked as soon as possible.
dealer’s service center or another qualified
service center or repair shop. Records of regu-
Under certain circumstances, one of the lamps
lar maintenance and repair work should be re-
flashes or lights up continuously. This indicates
tained.
that there is excessive misfiring or a malfunc-
tion in the engine. In this situation, decrease
the vehicle speed and immediately drive to a
dealer’s service center or another qualified
Socket for OBD Onboard
service center or repair shop. Serious engine
Diagnosis
misfiring within a brief period can seriously
damage emission control components, in par-
CAUTION
ticular the catalytic converter. In addition, the
The socket for Onboard Diagnosis is an
mechanical engine components may become
intricate component intended to be used in
damaged.
conjunction with specialized equipment to
check the vehicle’s primary emissions system.
If the fuel filler cap is not properly tight-
Improper use of the socket for Onboard Diag-
ened, the OBD system may conclude
nosis, or contact with the socket for Onboard
that fuel vapor is escaping; this will
Diagnosis for other than its intended purpose,
cause a display to light up. If the filler cap is
can cause vehicle malfunctions and creates
then tightened, the display should go out in a
risks of personal and property damage. Given
few days.
the foregoing, the manufacture of your vehicle
strongly recommends that access to the socket
for Onboard Diagnosis be limited to a dealer's
service center or another qualified service cen-
ter or repair shop or other persons that have
the specialized training and equipment for pur-
poses of properly utilizing the socket for On-
board Diagnosis.
Primary components in the vehicle emissions
can be checked via the OBD socket using a de-
vice.
173

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Replacing components
Replacing components
3. Take the wiper blade out of the catch
Vehicle features and op-
mechanism toward the front.
tions
4. Press the new wiper blade into the fixation
This chapter describes all standard, country-
until it engages audibly.
specific and optional features offered with the
5. Fold down the wiper arm.
series. It also describes features that are not
CAUTION
necessarily available in your car, e. g., due to
the selected options or country versions. This
Folded-away wipers can be jammed
also applies to safety-related functions and sys-
when the hood is opened. There is risk of prop-
tems.
erty damage. Make sure that the wipers with
the wiper blades mounted are folded down
When using the features and systems described
onto the windshield before opening the
here, adhere to local regulations.
hood.
Changing the rear wiper blade
Wiper blade replacement
MINI Countryman:
General information
CAUTION
If the wiper arm falls onto the windshield
without the wiper blades installed, the wind-
shield can be damaged. There is risk of prop-
erty damage. Secure the wiper arm when re-
placing the wiper blades and do not fold down
the wipers without the wiper blades installed.
MINI Paceman:
Replacing the front wiper blades
1. Fold up and hold the wiper arm.
2. Squeeze the locking spring, arrows 1, and
fold out the wiper blade, arrow 2.
1. Fold up and hold the wiper arm.
2. Turn the wiper blade all the way back, ar-
row.
174

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Replacing components
MOBILITY
3. Press the wiper blade against the stop to
clean cloth or something similar, or hold the
push it out of the fixation.
bulb by its base.
4. Press the new wiper blade into the fixation
Caring for the headlights, refer to page 191.
until it engages audibly.
For bulb replacement procedures that are not
5. Fold down the wiper arm.
described here, contact a dealer’s service cen-
ter or another qualified service center or repair
shop.
Lamp and bulb replace-
For checking and adjusting headlamp aim, con-
ment
tact a dealer’s service center or another quali-
fied service center or repair shop.
Information
Light-emitting diodes LEDs
Lamps and bulbs
In some equipment, the light source is provided
Lamps and bulbs make an essential contribu-
by light-emitting diodes behind a cover.
tion to vehicle safety. Therefore, exercise cau-
These light-emitting diodes, which operate us-
tion when handling lights and bulbs.
ing a concept similar to that applied in conven-
The vehicle manufacturer recommends that
tional lasers, are designated as Class 1 light-
you have the necessary work performed by a
emitting diodes.
dealer’s service center or another qualified
WARNING
service center or repair shop if you are unfami-
Too intensive brightness can irritate or
liar with it or it is not described here.
damage the retina of the eye. There is risk of
A spare lamp box is available from a dealer’s
injuries. Do not look directly into the headlights
service center or another qualified service cen-
or other light sources for an extended period of
ter or repair shop.
time. Do not remove the LED covers.
WARNING
Bulbs can get hot during operation. Con-
Headlight glass
tact with the bulbs can cause burns. There is
Condensation can form on the inside of the ex-
risk of injuries. Only change bulbs after they
ternal lights in cool or humid weather. When
have cooled off.
you drive with the lights switched on, the con-
densation evaporates after a short time. The
WARNING
headlight glass does not need to be changed.
Work on switched-on lighting systems
If despite driving with the lights switched on,
can cause short circuits. There is risk of injuries
increasing humidity forms, e. g. water droplets
or risk of property damage. When working on
in the lamp, the manufacturer of your vehicle
the lighting system, switch off the lamps in
recommends having it checked by a dealer’s
question. If necessary, heed the bulb manufac-
service center or another qualified service cen-
turer's instructions.
ter or repair shop.
CAUTION
Bi-xenon headlights
Contaminated bulbs reduce their service
These bulbs have a very long life and the likeli-
life. There is risk of property damage. Do not
hood of failure is very low, provided that they
hold new bulbs with your bare hands. Use a
are not switched on and off excessively. If a
bulb should nevertheless fail, you can continue
175

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Replacing components
driving cautiously with the front fog lights, pro-
Lower LED front lights
vided this is permitted by local laws.
DANGER
There can be high voltage in the lighting
system. There is danger to life. The manufac-
turer of your vehicle recommends that the
work on the lighting system including bulb re-
placement be performed by a dealer’s service
center or another qualified service center or re-
pair shop.
1
Parking lights / daytime running lights
Front lights, bulb replacement
2
Fog lights
Overview
Halogen low beams and high-beams
Headlights
H13 bulb, 60/55 watt
Access to the bulbs through the engine
compartment
Follow the general instructions on lamps and
bulbs, refer to page 175.
Low beam/high-beam bulbs can be changed
from the engine compartment.
1
Low beams/high-beams
2
Turn signal
Lower front lights
To remove the cover:
1. Press the tab.
2. Fold away the cover and take it out of the
holder.
Proceed in reverse order to attach the cover.
1
Parking lights
2
Daytime running lights or fog lights
176















Content      ..     7      8      9      10     ..
