Model MA TOW Tractor. Manual - part 88
Chapter 4: Illustrated Parts List
Jan. 1997
Section 4-3
p. 1
III.
NUMERICAL INDEX
A.
DISCUSSION
The Numerical Index provides a ready reference listing of all parts referred to in the Illustrated
Parts List, and the figure and index number under which each part is listed. In addition, space is
provided in the Numerical Index for locally established part numbers to be entered by the end
user.
The part numbers listed in the numerical index is the Tug part number when one has been
assigned. Where no Tug number has been assigned, the vendor part number is listed in the
index.
B.
INDEX
Tug Part End User Part Figure & Index Section 4-2 Page
Number Number Number Number
#10-24ncx1/2"
7-8
p31
#10-24ncx5/16"
7-3
p31
#10-32nf
62-28
p215
#10-32nf
63-
p221
#10-32nf
6-
p29
#10-32nf
7-17
p31
#10-32nf
7-18
p31
#10-32nf
2-17
p9
#10-32nf
26-33
p95
#10-32nfx1"
6-12
p29
#10-32nfx1"
2-16
p9
#10-32nfx2-1/2"
62-27
p215
#10-32nfx3/4"
63-13
p221
#12
4-28
p21
#16
26-26
p93
#28
30-13
p109
#28
32-20
p115
#28
32A-11
p117
#28
4-31
p21
#32
31-18
p113
#36
---
p87
#40
22-8
p75
#40
23-2
p77
#6
39-4
p139
#6
25a-7
p91
