МЕТРАН-280, МЕТРАН-280-Ех. Руководство - часть 15
60
ПРИЛОЖЕНИЕ Н
(справочное)
Generic Menu коммуникатора HC-275 (английская версия)
Generic
Online Menu
1 Process
Variables
2 Diagnostics
and Service
3 Basic setup
4 Detailed
setup
5 Review
1. Present variable
2. Percent Range
3. Analog Output
1. Test device
2. Loop test
3. Calibration
4. D/A Trim
Self test
1 Apply Values
2 Enter Values
1. Tag
2. PV Snsr Unit
3. Range values
4. Device Info.
5. Xfer. Fnctn
6. PV Damp
1. Model
2. Tag
3. Date
4. Descriptor
5. Message
6. PV snsr s/n
7. Final Asmbly #
8. Revision
1 Univ Rev.
2 Fld Dev Rev
3 Softw Rev
1 Sensors
2 Signal
condition
3 Output
condition
4 Device
information
1. Process variables
2. PV Snsr Unit
3. Sensor Info
1. PV LSL
2. PV USL
3. PV Min Span
1. PV Damp
2. PV URV
3. PV LRV
4. Xfer Fnctn
5. PV % Range
1. Analog
Output
2. HART
Output
1. A/O 1
2. A/O Alarm Type
3. Loop test
4. D/A Trim
5. Scaled D/A Trim
1. Poll Address
2. Number of
Request Preambles
1. Model
2. Tag
3. Date
4. Descriptor
5. Message
6. PV Snsr S/N
7. Final Asmbly Num
8. Revision
1 Univ Rev.
2 Fld Dev Rev
3 Softw Rev
1 Device Setup
2 PV
3 AO
4 LRV
5 URV
