10.4

Chassis

Front Bumper Assembly (Typical)

IQ Console Assembly (Typical)

PANEL

GRILLE W/MESH

NOSEPAN

BUMPER

HEAT FOIL / FABRIC

NOTE: TORQUE FASTENERS HAND TIGHT

FIXED STEERING COVER

CONSOLE

CONSOLE NUT

O-RING

RIDER SELECT STEERING COVERS

IGNITION SWITCH

ROPE GUIDE

STORAGE DOOR

NOTE: TORQUE FASTENERS HAND TIGHT

10.5

Chassis

10

RMK Tunnel

REAR BUMPER

SNOW FLAP

CLOSE OFF

CONTROL ARM SUPPORT

BULKHEAD/TUNNEL ASSEMBLY (1 PIECE)

RIVETS

RIVETS

10.6

Chassis

Fenders and Side Panels

FOAM

RH SIDE PANEL

HEAT SHIELD

LH FENDER

FOAM

LH SIDE PANEL

TRIM

RH FENDER

EXHAUST SEAL

PUSH RIVETS

RIVETS

10.7

Chassis

10

SEAT ASSEMBLIES

IQ Fixed Seat Assembly

IQ Raw Seat Assembly

IQ Removable Seat Assembly

= T

A: 5.5 Ft.Lbs. (7.5 Nm)

SEAT

SEAT BASE

A

2007 VERSION

2007 TAILIGHT

2008 VERSION

= T

A: 5.5 Ft.Lbs. (7.5 Nm)
Plastic crushes at 10 Ft.Lbs. (13 Nm).

SEAT

SEAT BASE

LATCH

A

A
