Polaris TRACTOR Sportsman 570 6X6 (2018 year). Manual - part 27

111

MAINTENANCE

Tires

Operating your vehicle with worn tires, improperly inflated tires, non-standard

tires or improperly installed tires will affect vehicle handling and could cause an

accident. Always follow all tire maintenance procedures as outlined in this

manual and on the labels on the vehicle. Always use original equipment size

and type when replacing tires.

Refer to the specifications section beginning on page 140 for

recommended tire type, size and pressure.

Tire Tread Depth

Always replace tires

when tread depth is

worn to 3 mm or less.

Front Wheel Hub Tightening

Front wheel bearing tightness and spindle nut retention are critical

component operations. All service must be performed by your

POLARIS dealer or other authorized service person.

Wheel Nut Torque Specifications

Check the wheel nut torques occasionally and when they've been

loosened for maintenance service.

Nut Type

Nut Torque

Lug Nut

41 Nm

PLUS 1/4 TURN

2-Piece Flange Nut

37 Nm

3 mm

112

MAINTENANCE

Tires

Wheel Removal/Installation

1. Position the vehicle on a level surface.
2. Place the transmission in PARK.
3. Loosen the wheel nuts slightly.
4. Elevate the end of the vehicle. See

page 85.

5. Remove the wheel nuts.
6. Remove the wheel.
7. Place the wheel on the hub.
8. Install the wheel nuts finger tight.
9. Lower the vehicle to the ground.
10. Torque the wheel nuts to

specification. See torque chart on

page 111.

113

MAINTENANCE

Air Filter

Always clean and replace the air and breather filters at the intervals

outlined in the Periodic Maintenance Chart beginning on page 85.
1. Position the vehicle on a

level surface.

2. Place the transmission in

PARK.

3. Remove the seat.
4. Release the air box cover

clips, and remove the air

box cover.

5. Loosen the clamp and

remove the filter.

6. Remove the fabric type

pre-filter from the main

filter. Wash the pre-filter

in soapy water, then rinse

and let dry.

7. Reinstall the pre-filter

over the main filter. Install

a new main filter if

needed.

8. Reinstall the filter into the

air box and tighten the

clamp. Do not overtighten the clamp, as filter damage could occur.

9. Reinstall the air box cover and the seat.

Breather Line

Pre-Filter

Main Filter

Breather

Valve

114

MAINTENANCE

Breather Filter/Hose

The breather valve is on the hose that runs between the engine and air

box. See illustration on page 113.
1. Remove the left side panel. See page 109.
2. Remove the hose clamps from the valve and pull the valve out of

the hoses.

3. Inspect the valve for debris. Blow gently through the valve to check

for clogging. Replace a damaged or clogged valve.

4. Check the hoses for cracks, deterioration, abrasion, or leaks.

Replace as needed.

5. Reinstall the valve and hose clamps.

NOTICE: Operation of your vehicle without a breather filter can cause engine

damage. Always reinstall the breather valve after removing it for

service.
