ENGINE 2.28 Assembly, Cont. 7. Lubricate and install new mechanical seal using 8. Lubricate seal guide and drive or press a new 9. Lubricate all crankshaft bearings with Premium 10. Apply 1/3 oz. (10 cc) cross shaft break-in lube to oil pump gears. 11. DO NOT insert any grease in the grease zerk located on the PTO end of the crankcase(440 Pro X 12. Install seals on crankshaft with spring facing inward (toward crankshaft). 13. Clean and de-grease lower crankcase and install crankshaft assembly, aligning seals and snap ring 14. Apply a thin coating of 3-Bond 1215 sealant to lower crankcase mating surface. 15. Install upper crankcase on lower crankcase. 16. Apply Loctite 242 to threads of bolts and install. Torque bolts in three steps to specification outlined Oil Pump Cross Shaft 9 5 1 4 8 12 10 6 2 3 7 11 15 14 13 PTO End MAG End |
