Polaris Ace RZR 570, RZR 570 EPS (2018 year). Manual - part 7

29

FEATURES AND CONTROLS

Seat Belts

This POLARIS vehicle is equipped with seat belts for all riders. Always
make sure the seat belts are secured for the operator and passenger
before riding. The driver’s seat belt is equipped with a seat belt
interlock. Vehicle speed will be limited to 15 MPH (24 km/h) if the seat
belt is not secured.

3-Point Seat Belt

To wear the 3-point seat belt properly, follow this procedure:

1. Pull the seat belt latch downward and across your chest toward the

buckle at the inner edge of the seat. The belt should fit snugly across
your hips and diagonally across your chest. Make sure the belt is not
twisted.

2. Push the latch plate into the buckle until it clicks. Pull up on the

strap to tighten.

3. Press the red release latch on the buckle to release the seat belt.

Seat Belt Height Adjuster (if equipped)

A breakthrough in comfort, the seat belt height
adjuster reduces neck rub and works as a
shock absorber for your shoulder. The height
adjuster consists of an adjuster (1) and a rail
(2). (3) designates the adjustment zone.

HOW TO ADJUST THE HEIGHT OF YOUR SEAT
BELT FOR DESIRED COMFORT AND PROPER
FIT

continued on next page

1

2

3

Proper location

of shoulder belt

Wrong

Wrong

30

FEATURES AND CONTROLS

Seat Belts

Seat Belt Height Adjuster (if equipped)

STEP 1

Stretch the seat belt height adjuster toward the
front of the vehicle.

STEP 2

While continuing to stretch the seat belt
height adjuster, slide the adjuster up or down,
rocking it side to side if necessary, until you
reach the desired height. This may require
both hands. Do not attempt to adjust while
vehicle is in motion.

NOTE: Adjustment becomes easier with
repeated use.

CLEANING INSTRUCTIONS: The seat belt height adjuster can be
cleaned with water.

STEP 1

STEP 2

31

FEATURES AND CONTROLS

Seat Belts

Seat Belt Inspection

Inspect all seat belts for proper operation before each use of the vehicle.

1. Push the latch plate into the buckle until it clicks. The latch plate

must slide smoothly into the buckle. A click indicates that it's
securely latched.

2. Push the red release latch in the middle of the buckle to make sure it

releases freely.

3. Pull each seat belt completely out and inspect the full length for any

damage, including cuts, wear, fraying or stiffness. If any damage is
found, or if the seat belt does not operate properly, have the seat belt
system checked and/or replaced. Your authorized POLARIS dealer
can assist.

4. To clean dirt or debris from

the seat belts, sponge the
straps with mild soap and
water. Do not use bleach,
dye or household
detergents.Use a garden
hose to flush out the
retractor and latch housings
regularly.

Retractor

Housing

Latch Housings

32

FEATURES AND CONTROLS

Switches

Auxiliary Outlet

The vehicle is equipped with a 12-volt accessory outlet on the dash. Use
the outlet to power an auxiliary light or other optional accessories or
lights. For service, the dash outlet connection is under the dash.

AWD

Switch

12V Accessory

Outlet

Ignition Switch

Light Switch (Base Model)

Instrument Cluster

Light Switch

(LE Model)
