CFMoto motorcycle CF650NK. Service Manual - part 5

WARNING

Coolant

Coolant absorbs excessive heat from the engine and transfers it to the air at the radiator. If the co-

olant level becomes low, the engine overheats and may suffer server damage, Check the coolant

 level each day before riding the motorcycle, and in accordance with the periodic maintenance chart

 and



replenish



coolant



if



the



level



is



low

.

Change



the



coolant



in



accordance



with



the



periodic



Maintenance



Chart

.

Information for Coolant

To protect the cooling system(consisting of the aluminum engine and radiator)from rust and corro-

sion, the use of corrosion



and



rust



inhibitor



chemicals



in



the



coolant



is



essential

 .

if



coolant



containing corrosion and rust inhibitor chemicals is not used

.

Over a period of time

,

the cooling

system accumulates rust and scales in the water jacket and radiator

.

This will clog up the coolant

passages, and considerably reduce the efficiency of the cooling system.

Use coolant containing corrosion inhibitors made specifically for

 engines and radiators in accordance with the instructions of rule.

Chemicals are harmful to the human body.

-59-

WARNING

Distilled water must be used with the antifreeze

 (

if



the



coolant



comes



to



low

).

If hard water is used in the system, it causes scales accumulation in the water hose, and

 considerably reduces the efficiency of the cooling system.

If the lowest temperature encountered falls below the freezing point of water, use

 permanent antifreeze in the coolant in protect the cooling system against and radiator
 freeze-up, as well as from rust and corrosion.

WARNING

Permanent types of antifreeze on the market have anti-corrosion and anti-rust prope-
rties. When it is diluted excessively, it loses its anti-corrosion property. Dilute a perm-
anent type of antifreeze in accordance with the instructions of the manufacturer.

WARNING

When fill the coolant in the cooling system, it's colored agree and contains ethylene
 glycol. It is mixed at 50% and has the freezing point of -35℃.

-60-

Coolant Level Inspection

Situate the bike so that it is perpendicular to the ground.

Check the coolant level if it is between the F (Full) and L (Low) level lines.

WARNING

Check the level when the engine is cold (room of atmospheric temperature).

A

B

C

F (FULL) level line      L (Low) level line     Right side cover

If the amount of coolant is insufficient, remove the right side cover and add coolant into the

 reservoir



tank

.

-61-

Coolant Filling

Remove the right side cover.

Disconnect the connector of turn light.

Remove the cap from the reserve tank and



add coolant through the filler opening to between F

and



L

B

A

Reservoir tank cap         Right side cover

Install reserve tank cap.

Connect the connector of turn light.

Install right side cover

.

WARNING

In an emergency you can add water alone to coolant reserve tank, however it must

 be returned to the correct mixture ratio by the addition of antifreeze concentrate as
 soon as possible

-62-

WARNING

If coolant must be added often, or the reserve tank completely runs dry, there is

 probably leakage in the system. Have the cooling system inspected by your

authorized dealer.

Coolant Change

Have the coolant changed by an authorized dealer.

Spark Plug

The standard spark plug is shown in the table.

The spark plugs should be replace in accordance with the Periodic

 Maintenance Chart.

Spark plug removal should be done by an authorized dealer.

Spark Plug type

：

CR8EI

Plug Gap：0.7～0.9mm

Tightening Torque

：

15N.m

A

Plug Gap

-63-

Air System

Fuel & Exhaust Detecting System

Fuel & Exhaust System is detected by



Oxygen



Sensor

.

there is a



Oxygen



Sensor installed on



exhaust



pipe

.

It detects Air & Fuel combustion condition by measuring oxygen density and trans-

ferring



it



to



electrical



signal



to



ECU

.

When ECU judges combustion not completely, ECU will give

 signals to TPS and Intake air temp. sensor to adjust fuel injection. By this way, the ratio of air agai-

nst fuel can be optimized and make combustion completely.

A

Oxygen Sensor

-64-

Air Suction Valves

The air suction valve is essentially a check valve which allows fresh air to flow only from the air cle-

aner into the exhaust port. Any air that has passed the air suction valve is prevented from returning.

 Inspect the air suction valves in accordance with the Periodic Maintenance Chart. Also ,inspect the

 air suction valves whenever stable idling cannot be obtained ,engine power is greatly reduced ,or

 there are abnormal engine noises.

Air suction valve removal and inspection should be done by an authorized dealer

.

Valve Clearance

Valve and valve seat are wearing during using, upsetting valve timing.

-65-

CAUTION

If valve and valve seat is left unadjusted, wear will eventually cause the valves

 to remain partly open or without clearance, which lower performance or making
 noise and may cause serious engine damage. Valve clearance for each valve
 should be checked and adjusted in accordance with the Periodic Maintenance

Chart. Inspection and adjustment should be done by an authorized dealer.

Air Filter

A clogged air filter restricts the engine

'

s air intake, increasing fuel consumption, reducing engine

power, and causing spark plug fouling.

The air filter element must be cleaned in accordance with the periodic Maintenance Chart. In dusty ,

rainy, or muddy condition, the air filter element should be serviced more frequently than the recom-

mended interval by an authorized dealer.

Oil Draining

Oil Draining hose located on the rear right side and at the



top of shock where is to see if any oil or



water has run down from the air filter housing

.

If there are any oil in the reservoir, remove oil draining hose to drain the oil.

-66-

B

A

Drain Hose



Plug

WARNING

Be sure to install the drain hose after draining. Oil on
tires will make them slippery and can cause an accident
 and injury.

Throttle Control System

Check the throttle grip play in accordance with the periodic Maintenance Chart ,and adjust it if nec-
essary.

Throttle Grip

The throttle drip controls the butterfly valves in the throttle body ,if the throttle grip ahs excessive

 play due to either cable stretch or maladjustment, it will cause a delay in throttle response, espec-

ially at low engine speed. Also, the throttle valve may not open fully at full throttle. On the other hand,

 if the throttle grip has not play ,the throttle will be hard to control, and the idle speed will be erratic.

Inspection

●Check that the throttle grip play is neatly.

●Adjust throttle grip if there is improper play.

-67-

B

A

Throttle Grip



Throttle Grip Play

Throttle Grip Play：2~3mm

B

C

A

Locknut       Adjuster      Throttle Cable

Adjustment

Loosen the locknut at the upper end of the throttle

 cable and turn the throttle cable adjusting nut in

completely so as  the give the throttle grip plenty

 of play.

-68-

Turn out the decelerator cable adjust nut t until there is no play when the throttle grip is completely

 closed.

   Tighten the locknut.

Turn out the accelerator cable adjusting nut until a play of ~3mm



is



obtained



at



the



throttle grip.

Tighten the locknut.

F



D

E

CAUTION

Locknut         Adjuster         Decelerator Cable

Operation with improperly adjusted,
incorrectly routed, or damaged cables
could result in an unsafe riding condition.

Idle Speed

The idle speed of your vehicle has been done before out of factory, there is no need to do any adju-

stment by yourself , otherwise will effect vehicle

'

s performance. If there is any parts which will effect

idle speed need to be replaced ,



contact



with



authorized



local dealer



and



use



PDA



to



diagnose



and



have



calibration

.

-69-

CAUTION

Operation with an improperly adjusted could result in an unsafe riding condition.

Idle Speed：1300±130rpm

Clutch

Due to friction plate wear and clutch cable stretch over a long period of use, the clutch operation

 should be checked each day before riding the motorcycle, and in accordance with the Maintenance

Chart.

CAUTION

To avoid a serious burn, never touch a hot engine or exhaust pipe during adjustment .

Inspection

Check that the clutch lever operates properly and that the inner cable slider smoothly .if there is

 any irregularity

,

have the clutch cable checked by an authorized dealer

.

Check the clutch lever play.

Clutch Lever play：2~3mm

If the play is incorrect, adjust the lever

play as following

Adjustment

-70-

B

C

D

A

Clutch handle
 Locknut

Adjuster

Clutch Lever Play

Loosen the locknut, and turn the

adjuster so that the clutch lever will

have the proper play

WARNING

Be sure the upper end of the clutch outer
cable is fully seated in its fitting, or it could
slip into place later, creating enough cable

 play to prevent clutch disengagement,

resulting in a hazardous riding condition.

If it cannot be done when upper end of the clutch cable at the limitation ,adjust the nuts at the lower

end of the clutch cable.

B

C

A

Adjuster           Locknut       Clutch cable

NOTE

After the adjustment is made ,start the engine

 and check that the clutch does not slip and that
 it releases properly.

-71-

Drive Chain

The drive chain slack and lubrication must be checked each day before riding, motorcycle and in

 accordance with the Periodic Maintenance Chart for safety and to prevent excessive wear. If the

chain becomes badly worn or maladjusted-wither too loose or too tight- the chain could jump off or

 break.

WARNING

A chain that breaks or jumps off the sprockets could snag on the engine sprocket or lock

 the rear wheel, severely damaging the motorcycle and causing it to go out of control

Chain Slack Inspection

Set the motorcycle up on its side stand

Rotate the rear wheel to find the position where the



chain



is tightest

,

and measure the maximum



chain slack by bulling up and pushing down the chain midway between the engine sprocket and



rear wheel sprocket

.

If the drive chain is too tight or too loose ,adjust it so that the chain slack will be within the standard

 value

Standard Value：30~40mm

-72-

A

Chain Slack

Adjustment

●Loosen the left and right chain adjuster locknuts.

●Remove the cotter pin, and loosen the rear axle



nut

.

●If the chain is to loose ,turn the left and right chain

Adjust



nuts clockwise



and evenly.

●If the chain is too



tight

,

turn the left and right chain



Adjust nuts anticlockwise, and evenly.

●Turn both chain adjusting nuts evenly until to drive

Chain has the correct amount of slack.

●Keep rear wheel shaft move same on left and right fork.

B

C

D

A

Cotter pin               Axle locknut
Adjuster                 Chain locknut

-73-

WARNING

Rear wheel shaft should be installed at same level on left and right rear fork.

Misalignment of the wheel will result in abnormal wear, and may result in unsafe riding
 condition

WARNING

Tighten both chain adjuster locknuts.

Tighten the rear axle nut to the specified torque



Tightening Torque

：

108N.m

NOTE

If there is no torque wrench, contact with a authorized local dealer.

Rotate the wheel, measure the chain slack again at the tightest position and readjust if necessary.

Install a new cotter pin through the rear axle nut and axle and spread its ends.

-74-
