Parker Variable Speed Drive AC30 series. User’s Manual (2017)

Parameter Reference

D-241

Table of Parameters in Alphabetical Order

This table is a list of all the parameters in the AC30V showing the parameter name, number and the section in this appendix in which the parameter
is described.

PNO

Name

Path

0332

100% Mot Current

Motor Load

0464

100% Speed in RPM

Scale Setpoint

0403

100% Stack Current A

Feedbacks

0343

100% Stk Current

Stack Inv Time

0450

Acceleration Boost

Fluxing VHz

0486

Acceleration Time

Ramp

0763

Active 1 - 32

Trips Status

0513

Active 33 - 64

Trips Status

0400

Actual Field Current

Feedbacks

0339

Actual Mot I2T Output

Motor Load

0421

Actual Neg Torque Lim

Torque Limit

1013

actual period

Tasks

1014

actual period[0]

Tasks

1015

actual period[1]

Tasks

1016

actual period[2]

Tasks

0420

Actual Pos Torque Lim

Torque Limit

1520

Actual Rotor T Const

Tr Adaptation

0395

Actual Speed Percent

Feedbacks

0393

Actual Speed RPM

Feedbacks

0394

Actual Speed rps

Feedbacks

0989

Actual State

Device State

0399

Actual Torque

Feedbacks

0199

Address Assignment

Option Ethernet

1716

AFE Brake Mode

AFE

1690

AFE Close Ext PCR

AFE

1717

AFE Correction Angle

AFE

1693

AFE Current Control

AFE

1714

AFE Enable Drive

AFE

1691

AFE Ext PCR Closed

AFE

1704

AFE Id Demand

AFE

1719

afe id output

AFE

1730

AFE Inductance

AFE

1705

AFE Iq Demand

AFE

1720

afe iq output

AFE

1706

AFE Max Current

AFE

1692

AFE PF Angle Demand

AFE

1715

AFE Phase Loss

AFE

1694

AFE PLL Kp

AFE

1695

AFE PLL Ti

AFE

1721

AFE Status

AFE

1718

AFE Sync Angle

AFE

1703

AFE Sync Frequency

AFE

1713

AFE Synchronized

AFE

1712

AFE Synchronizing

AFE

1724

afe torque mode

AFE

1731

AFE Transf Angle Offset

AFE

1711

AFE VDC Demand

AFE

1710

AFE VDC Feed Forward

AFE

1707

AFE VDC Kp

AFE

1697

AFE VDC Min Level

AFE

PNO

Name

Path

1709

AFE VDC Ramp

AFE

1708

AFE VDC Ti

AFE

1804

Alignment Direction

Pos Fbk Alignment

1803

Alignment Elec Pos

Pos Fbk Alignment

1798

Alignment Enable

Pos Fbk Alignment

1806

Alignment Ended

Pos Fbk Alignment

1807

Alignment Error

Pos Fbk Alignment

1799

Alignment Level

Pos Fbk Alignment

1797

Alignment Method

Pos Fbk Alignment

1802

Alignment Offset

Pos Fbk Alignment

1801

Alignment On Motor

Pos Fbk Alignment

1796

Alignment On Power On

Pos Fbk Alignment

1800

Alignment Ramp Time

Pos Fbk Alignment

1805

Alignment State

Pos Fbk Alignment

0040

Anin 01 Break

IO Values

0957

Anin 01 Offset

IO Configure

0958

Anin 01 Scale

IO Configure

0001

Anin 01 Type

IO Configure

0039

Anin 01 Value

IO Values

0959

Anin 02 Offset

IO Configure

0960

Anin 02 Scale

IO Configure

0002

Anin 02 Type

IO Configure

0041

Anin 02 Value

IO Values

1461

Anin 11 Offset

General Purpose IO

1462

Anin 11 Scale

General Purpose IO

1181

Anin 11 Value

General Purpose IO

1463

Anin 12 Offset

General Purpose IO

1464

Anin 12 Scale

General Purpose IO

1182

Anin 12 Value

General Purpose IO

1465

Anin 13 Offset

General Purpose IO

1466

Anin 13 Scale

General Purpose IO

1183

Anin 13 Value

General Purpose IO

1441

Anout 01 ABS

IO Configure

1108

Anout 01 Offset

IO Configure

0686

Anout 01 Scale

IO Configure

0003

Anout 01 Type

IO Configure

0042

Anout 01 Value

IO Values

1468

Anout 02 ABS

IO Configure

1467

Anout 02 Offset

IO Configure

1460

Anout 02 Scale

IO Configure

0004

Anout 02 Type

IO Configure

0043

Anout 02 Value

IO Values

0610

App Control Word

Sequencing

0680

App Reference

Sequencing

1539

Application

Clone

1039

Application Archive

SD Card

0990

Application FE State

Device State

1554

Application Name

App Info

1633

Application User Boost

Fluxing VHz

1549

Application Volts

Fluxing VHz

PNO

Name

Path

1507

AR Active

Auto Restart

1469

AR Enable

Auto Restart

1505

AR Initial Delay

Auto Restart

1736

AR Initial Delay B

Auto Restart

1471

AR Max Restarts

Auto Restart

1470

AR Mode

Auto Restart

1506

AR Repeat Delay

Auto Restart

1737

AR Repeat Delay B

Auto Restart

1508

AR Restart Pending

Auto Restart

1509

AR Restarts Remaining

Auto Restart

1510

AR Time Remaining

Auto Restart

1472

AR Trip Mask

Auto Restart

0796

AR Trip Mask 2

Auto Restart

1735

AR Trip Mask 2 B

Auto Restart

1734

AR Trip Mask B

Auto Restart

0410

Archive Flags

App Info

0275

atn imr loop i gain

Autotune

0276

atn leakage l test curr

Autotune

0277

atn leakage l test freq

Autotune

1405

ATN PMAC Ls Test Freq

Autotune

1388

ATN PMAC Test Disable

Autotune

0695

Attached to Stack

Drive info

0448

Auto Boost

Fluxing VHz

0449

auto boost tc

Fluxing VHz

1779

Auto Hide

Setup Wizard

0930

Auto IP

Ethernet

0375

automatic mode tc

Voltage Control

0255

Autotune Enable

Autotune

0256

Autotune Mode

Autotune

0274

Autotune Ramp Time

Autotune

0257

Autotune Test Disable

Autotune

1093

BACnet Baud Rate

BACnet MSTP

0209

BACnet IP Device ID

BACnet IP

0208

BACnet IP State

BACnet IP

0210

BACnet IP Timeout

BACnet IP

1091

BACnet MAC Address

BACnet MSTP

1096

BACnet Max Info Frames

BACnet MSTP

1095

BACnet Max Master

BACnet MSTP

1092

BACnet MSTP Device ID

BACnet MSTP

1089

BACnet MSTP State

BACnet MSTP

1094

BACnet MSTP Timeout

BACnet MSTP

0457

Base Frequency

Motor Nameplate

0991

Base IO FE State

Device State

0456

Base Voltage

Motor Nameplate

0992

Basic Drive FE State

Device State

1830

Black Box PNOs

Black Box Recorder

1831

Black Box PNOs[0]

Black Box Recorder

1832

Black Box PNOs[1]

Black Box Recorder

1833

Black Box PNOs[2]

Black Box Recorder

1834

Black Box PNOs[3]

Black Box Recorder

D-242

Parameter Reference

PNO

Name

Path

0951

Boot Version

Drive info

0687

Boot Version Number

Drive info

0253

Brake Overrating

Braking

0252

Brake Rated Power

Braking

0251

Brake Resistance

Braking

0254

Braking Active

Braking

0249

Braking Enable

Braking

1251

CANopen Actual Baud

CANopen

0213

CANopen Baud Rate

CANopen

0212

CANopen Node Address

CANopen

0211

CANopen State

CANopen

1034

Card Name

SD Card

1033

Card State

SD Card

1147

channel

Fast Trace Config

1156

channel address

Fast Trace Config

1157

channel address[0]

Fast Trace Config

1158

channel address[1]

Fast Trace Config

1159

channel address[2]

Fast Trace Config

1160

channel address[3]

Fast Trace Config

1161

channel address[4]

Fast Trace Config

1162

channel address[5]

Fast Trace Config

1163

channel address[6]

Fast Trace Config

1164

channel address[7]

Fast Trace Config

1148

channel[0]

Fast Trace Config

1149

channel[1]

Fast Trace Config

1150

channel[2]

Fast Trace Config

1151

channel[3]

Fast Trace Config

1152

channel[4]

Fast Trace Config

1153

channel[5]

Fast Trace Config

1154

channel[6]

Fast Trace Config

1155

channel[7]

Fast Trace Config

1537

Clone Direction

Clone

1534

Clone Filename

Clone

1542

Clone Start

Clone

1543

Clone Status

Clone

0406

CM Temperature

Feedbacks

0217

CNet Consuming Inst

ControlNet

0216

CNet Producing Inst

ControlNet

0627

Comms Control Word

Sequencing

0051

Comms Diagnostic

Comms

0052

Comms Diagnostic Code

Comms

0186

Comms Event Active

Event

0188

Comms Event Clear

Event

0185

Comms Event Code

Event

0187

Comms Event Set

Event

0053

Comms Exception

Comms

0045

Comms Fitted

Comms

0050

Comms Module Serial

Comms

0049

Comms Module Version

Comms

0054

Comms Net Exception

Comms

0995

Comms Option FE State

Device State

1121

Comms Option Pcode

Drive info

1129

Comms Option Serial

Drive info

0681

Comms Reference

Sequencing

0044

Comms Required

Comms

PNO

Name

Path

1853

Comms Reset Allow

Comms

0046

Comms State

Comms

0047

Comms Supervised

Comms

0048

Comms Trip Enable

Comms

0997

Config Fault Area

Device State

1139

Control Board Up Time

Runtime Statistics

1116

Control Module Pcode

Drive info

0977

Control Module Serial

Drive info

1352

Control Screen

Soft Menus

0908

Control Screen Mode

Soft Menus

1353

Control Screen[0]

Control Screen;Soft Menus

1354

Control Screen[1]

Control Screen;Soft Menus

1355

Control Screen[2]

Control Screen;Soft Menus

1356

Control Screen[3]

Control Screen;Soft Menus

1357

Control Screen[4]

Control Screen;Soft Menus

1358

Control Screen[5]

Control Screen;Soft Menus

0512

Control Strategy

Control Mode

1533

Control Type

Control Mode

0644

Control Word

Sequencing

0215

ControlNet MAC ID

ControlNet

0214

ControlNet State

ControlNet

1852

Copy Status

Black Box Recorder

1829

Copy to SD Card

Black Box Recorder

1658

Current Diff Level

Current Sensor Trip

0305

Current Limit

0306

current limit output

Current Limit

0541

current loop i gain

Current Loop

0538

current loop p gain

Current Loop

0546

current loop saturated

Current Loop

1545

Cut Off Frequency

Filter On Torque Dmd

1177

data points captured

Fast Trace Status

0329

DC Current Level

Inj Braking

0331

DC Inj Base Volts

Inj Braking

0326

DC Inj Current Limit

Inj Braking

0324

DC Inj Deflux Time

Inj Braking

0325

DC Inj Frequency

Inj Braking

0330

DC Inj Timeout

Inj Braking

0396

DC Link Volt Filtered

Feedbacks

0392

DC Link Voltage

Feedbacks

0327

DC Pulse Time

Inj Braking

0487

Deceleration Time

Ramp

0414

Deflux Delay

Pattern Generator

1635

Delay To Start

Motor Sequencer

1528

Demanded Terminal Volts

Tr Adaptation

1726

Destination IP Address

Peer to Peer

1727

Destination Port

Peer to Peer

0221

DeviceNet Actual Baud

DeviceNet

0220

DeviceNet Baud Rate

DeviceNet

0219

DeviceNet MAC ID

DeviceNet

0218

DeviceNet State

DeviceNet

0929

DHCP

Ethernet

1269

DHCP State

Ethernet

0005

Digin Value

IO Values

0022

Digout Value

IO Values

0532

direct input filt tc

Spd Direct Input

PNO

Name

Path

0531

Direct Input Neg Lim

Spd Direct Input

0530

Direct Input Pos Lim

Spd Direct Input

0529

Direct Input Ratio

Spd Direct Input

0528

Direct Input Select

Spd Direct Input

0983

Display Timeout

Graphical Keypad

1760

Display Warnings

Trips Status

0223

DNet Consuming Inst

DeviceNet

0222

DNet Producing Inst

DeviceNet

0688

Drive Diagnostic

Drive info

0961

Drive Name

Drive info

0390

Duty Selection

Feedbacks

1021

elapsed time

Tasks

1025

elapsed time max

Tasks

1026

elapsed time max[0]

Tasks

1027

elapsed time max[1]

Tasks

1028

elapsed time max[2]

Tasks

1022

elapsed time[0]

Tasks

1023

elapsed time[1]

Tasks

1024

elapsed time[2]

Tasks

0408

Elec Rotor Speed

Feedbacks

1144

enable

Fast Trace Config

0697

Enable 1 - 32

Trips Status

0730

Enable 33 - 64

Trips Status

1738

Enable Auto Save

Setup Wizard

0548

enable cur test

Stimulus

0540

enable decoupling term

Current Loop

0542

enable integral term

Current Loop

1530

enable kvar compn

Tr Adaptation

0955

Enable Predict Term

Current Loop

1518

Encoder Count

Encoder

1670

Encoder Count

Encoder Slot 1

1677

Encoder Count

Encoder Slot 2

1783

Encoder Count Init

Encoder

1784

Encoder Count Init

Encoder Slot 1

1785

Encoder Count Init

Encoder Slot 2

1517

Encoder Count Reset

Encoder

1669

Encoder Count Reset

Encoder Slot 1

1676

Encoder Count Reset

Encoder Slot 2

1743

Encoder Feedback

Control Mode

1513

Encoder Invert

Encoder

1665

Encoder Invert

Encoder Slot 1

1672

Encoder Invert

Encoder Slot 2

1512

Encoder Lines

Encoder

1664

Encoder Lines

Encoder Slot 1

1671

Encoder Lines

Encoder Slot 2

1515

Encoder Single Ended

Encoder

1516

Encoder Speed

Encoder

1668

Encoder Speed

Encoder Slot 1

1675

Encoder Speed

Encoder Slot 2

1511

Encoder Supply

Encoder

1663

Encoder Supply

Encoder Slot 1

1761

Encoder Supply

Encoder Slot 2

1514

Encoder Type

Encoder

1666

Encoder Type

Encoder Slot 1

1673

Encoder Type

Encoder Slot 2

Parameter Reference

D-243

PNO

Name

Path

0383

Energy kWh

Energy Meter

0379

energy meter enable

Energy Meter

0451

Energy Saving Enable

Fluxing VHz

1526

Energy Saving Lower Lim

Fluxing VHz

0227

ENet Consuming Inst

EtherNet IP

0226

ENet Producing Inst

EtherNet IP

1637

Engineer Password

Graphical Keypad

1750

Error Number

Configure

0322

error scaler

Flycatching

0224

EtherCAT State

EtherCAT

0937

Ethernet Diagnostic

Ethernet

0993

Ethernet FE State

Device State

3131

EtherNet IP Diag

EtherNet IP Adapter

3128

EtherNet IP Enable

EtherNet IP Adapter

0225

EtherNet IP State

EtherNet IP

3130

EtherNet IP State

EtherNet IP Adapter

3129

EtherNet IP Trip

EtherNet IP Adapter

0919

Ethernet State

Ethernet

1548

Factor

Filter On Torque Dmd

0418

Fast Stop Torque Lim

Torque Limit

1188

Favourites

Soft Menus

1189

Favourites[0]

Favourites;Soft Menus

1190

Favourites[1]

Favourites;Soft Menus

1199

Favourites[10]

Favourites;Soft Menus

1200

Favourites[11]

Favourites;Soft Menus

1201

Favourites[12]

Favourites;Soft Menus

1202

Favourites[13]

Favourites;Soft Menus

1203

Favourites[14]

Favourites;Soft Menus

1204

Favourites[15]

Favourites;Soft Menus

1205

Favourites[16]

Favourites;Soft Menus

1206

Favourites[17]

Favourites;Soft Menus

1207

Favourites[18]

Favourites;Soft Menus

1208

Favourites[19]

Favourites;Soft Menus

1191

Favourites[2]

Favourites;Soft Menus

1192

Favourites[3]

Favourites;Soft Menus

1193

Favourites[4]

Favourites;Soft Menus

1194

Favourites[5]

Favourites;Soft Menus

1195

Favourites[6]

Favourites;Soft Menus

1196

Favourites[7]

Favourites;Soft Menus

1197

Favourites[8]

Favourites;Soft Menus

1198

Favourites[9]

Favourites;Soft Menus

1544

Filter Type

Filter On Torque Dmd

0918

Filtered VDC Ripple

VDC Ripple

0328

Final DC Pulse Time

Inj Braking

0509

Final Stop Rate

Ramp

0954

fire mode desel time

Runtime Statistics

1038

Firmware

SD Card

0683

Firmware File Name

SD Card

1100

Firmware Version

Drive info

0696

First Trip

Trips Status

0447

Fixed Boost

Fluxing VHz

0202

Fixed Gateway Address

Option Ethernet

0200

Fixed IP Address

Option Ethernet

0201

Fixed Subnet Mask

Option Ethernet

0323

flying filter tc

Flycatching

0319

flying load level

Flycatching

PNO

Name

Path

0318

Flying Reflux Time

Flycatching

0312

Flying Start Mode

Flycatching

0986

frame size

Drive info

0938

Free Packets

Ethernet

1782

Free Sockets

Ethernet

1754

Free Space (kBytes)

Flash File System

1546

Frequency 1

Filter On Torque Dmd

1547

Frequency 2

Filter On Torque Dmd

1538

Full Restore

Clone

0928

Gateway Address

Ethernet

1142

GKP Password

Graphical Keypad

1755

half buffer full

Fast Trace Config

0407

Heatsink Temperature

Feedbacks

1667

High Input Threshold

Encoder Slot 1

1674

High Input Threshold

Encoder Slot 2

1828

high res i sampling

Feedbacks

0940

High Word First

Modbus

0232

High Word First RTU

Modbus RTU

0235

High Word First TCP

Modbus TCP

1145

hold

Fast Trace Config

1406

HV Power On Count

Runtime Statistics

1252

HV SMPS Up Time

Runtime Statistics

1563

hw underlap comp

Pattern Generator

0539

i gain adjustment

Current Loop

0309

i lim vhz i gain

Cur Lim VHz

0308

i lim vhz p gain

Cur Lim VHz

0397

Feedbacks

1048

IDE Version

App Info

1652

ilim slw on

Cur Lim VHz

0567

imr from feedback

IM Flux

0566

imr p gain

IM Flux

3000

Input Mapping

Fieldbus Mapping

3001

Input Mapping[0]

Fieldbus Mapping

3002

Input Mapping[1]

Fieldbus Mapping

3011

Input Mapping[10]

Fieldbus Mapping

3012

Input Mapping[11]

Fieldbus Mapping

3013

Input Mapping[12]

Fieldbus Mapping

3014

Input Mapping[13]

Fieldbus Mapping

3015

Input Mapping[14]

Fieldbus Mapping

3016

Input Mapping[15]

Fieldbus Mapping

3017

Input Mapping[16]

Fieldbus Mapping

3018

Input Mapping[17]

Fieldbus Mapping

3019

Input Mapping[18]

Fieldbus Mapping

3020

Input Mapping[19]

Fieldbus Mapping

3003

Input Mapping[2]

Fieldbus Mapping

3021

Input Mapping[20]

Fieldbus Mapping

3022

Input Mapping[21]

Fieldbus Mapping

3023

Input Mapping[22]

Fieldbus Mapping

3024

Input Mapping[23]

Fieldbus Mapping

3025

Input Mapping[24]

Fieldbus Mapping

3026

Input Mapping[25]

Fieldbus Mapping

3027

Input Mapping[26]

Fieldbus Mapping

3028

Input Mapping[27]

Fieldbus Mapping

3029

Input Mapping[28]

Fieldbus Mapping

3030

Input Mapping[29]

Fieldbus Mapping

3004

Input Mapping[3]

Fieldbus Mapping

PNO

Name

Path

3031

Input Mapping[30]

Fieldbus Mapping

3032

Input Mapping[31]

Fieldbus Mapping

3005

Input Mapping[4]

Fieldbus Mapping

3006

Input Mapping[5]

Fieldbus Mapping

3007

Input Mapping[6]

Fieldbus Mapping

3008

Input Mapping[7]

Fieldbus Mapping

3009

Input Mapping[8]

Fieldbus Mapping

3010

Input Mapping[9]

Fieldbus Mapping

0353

Inv Time Active

Stack Inv Time

0348

Inv Time Aiming Point

Stack Inv Time

0351

Inv Time Down Rate

Stack Inv Time

0349

Inv Time Output

Stack Inv Time

0350

Inv Time Up Rate

Stack Inv Time

0352

Inv Time Warning

Stack Inv Time

0996

IO Option FE State

Device State

1125

IO Option Pcode

Drive info

1134

IO Option Serial No

Drive info

1254

IO Option SW Version

Drive info

0926

IP Address

Ethernet

0207

IPConfig Enable

Option Ethernet

0398

Feedbacks

1523

iq maximum ratio

Tr Adaptation

1522

iq minimum ratio

Tr Adaptation

0502

Jog Acceleration Time

Ramp

0503

Jog Deceleration Time

Ramp

0501

Jog Setpoint

Ramp

0994

Keypad FE State

Device State

1532

kvar compn i gain

Tr Adaptation

1531

kvar compn p gain

Tr Adaptation

0384

kwmin

Energy Meter

1263

l0 vs imr 0_4

Induction Motor Data

0589

l0 vs imr 0_5

Induction Motor Data

0588

l0 vs imr 0_6

Induction Motor Data

0587

l0 vs imr 0_7

Induction Motor Data

0586

l0 vs imr 0_8

Induction Motor Data

0585

l0 vs imr 0_9

Induction Motor Data

0584

l0 vs imr 1_0

Induction Motor Data

1005

Language

Setup Wizard

0931

Last Auto IP Address

Ethernet

1047

Last Modification

App Info

0570

Leakage Inductance

Induction Motor Data

1840

Limit Log File Size

Data Logger

1561

load at 2x nmplate rpm

Induction Motor Data

1562

load at nameplate rpm

Induction Motor Data

0591

Local

Sequencing

0593

local control word

Sequencing

1255

Local Dir Key Active

Local Control

1728

Local Port

Peer to Peer

1565

Local Power Up Mode

Sequencing

0592

Local Reference

Sequencing

1240

Local Reverse

Local Control

1239

Local Run Key Active

Local Control

1253

Local/Rem Key Active

Local Control

0936

Lock

Ethernet

1835

Log Enable

Data Logger

1837

Log File Name

Data Logger

D-244

Parameter Reference

PNO

Name

Path

1841

Log File Size

Data Logger

1839

Log New File On Reset

Data Logger

1842

Log Parameters

Data Logger

1843

Log Parameters[0]

Data Logger

1844

Log Parameters[1]

Data Logger

1845

Log Parameters[2]

Data Logger

1846

Log Parameters[3]

Data Logger

1847

Log Parameters[4]

Data Logger

1848

Log Parameters[5]

Data Logger

1849

Log Parameters[6]

Data Logger

1850

Log Parameters[7]

Data Logger

1836

Log Period

Data Logger

1838

Log to New File

Data Logger

0344

Long Overload Level

Stack Inv Time

0345

Long Overload Time

Stack Inv Time

1524

loop response n * Tr

Tr Adaptation

0920

MAC Address

Ethernet

1090

macro id

Macro

0568

Magnetising Current

Induction Motor Data

0417

Main Torque Lim

Torque Limit

1636

Manufacturing Flags

Drive info

1632

Mapping Valid

Modbus

1751

Master Encoder

Configure

1745

Master Position Src

Configure

1527

Max Available Volts

Tr Adaptation

1017

max period

Tasks

1018

max period[0]

Tasks

1019

max period[1]

Tasks

1020

max period[2]

Tasks

1459

Max Spd when Autotuned

Autotune

0913

Max VDC Ripple

VDC Ripple

0939

Maximum Connections

Modbus

0376

measured dc link tc

Voltage Control

0317

Min Search Speed

Flycatching

1458

Modbus Conn Timeout

Modbus

0229

Modbus Device Address

Modbus RTU

1567

Modbus Mapping

Modbus

1568

Modbus Mapping[0]

Modbus

1569

Modbus Mapping[1]

Modbus

1578

Modbus Mapping[10]

Modbus

1579

Modbus Mapping[11]

Modbus

1580

Modbus Mapping[12]

Modbus

1581

Modbus Mapping[13]

Modbus

1582

Modbus Mapping[14]

Modbus

1583

Modbus Mapping[15]

Modbus

1570

Modbus Mapping[2]

Modbus

1571

Modbus Mapping[3]

Modbus

1572

Modbus Mapping[4]

Modbus

1573

Modbus Mapping[5]

Modbus

1574

Modbus Mapping[6]

Modbus

1575

Modbus Mapping[7]

Modbus

1576

Modbus Mapping[8]

Modbus

1577

Modbus Mapping[9]

Modbus

1640

Modbus Password

Modbus RTU

0230

Modbus RTU Baud Rate

Modbus RTU

PNO

Name

Path

0228

Modbus RTU State

Modbus RTU

0233

Modbus RTU Timeout

Modbus RTU

1659

Modbus TCP Password

Modbus

0234

Modbus TCP State

Modbus TCP

0236

Modbus TCP Timeout

Modbus TCP

0941

Modbus Timeout

Modbus

0942

Modbus Trip Enable

Modbus

1165

mode

Fast Trace Config

1270

Monitor

Soft Menus

1271

Monitor[0]

Soft Menus

1272

Monitor[1]

Soft Menus

1281

Monitor[10]

Soft Menus

1282

Monitor[11]

Soft Menus

1283

Monitor[12]

Soft Menus

1284

Monitor[13]

Soft Menus

1285

Monitor[14]

Soft Menus

1286

Monitor[15]

Soft Menus

1287

Monitor[16]

Soft Menus

1288

Monitor[17]

Soft Menus

1289

Monitor[18]

Soft Menus

1290

Monitor[19]

Soft Menus

1273

Monitor[2]

Soft Menus

1274

Monitor[3]

Soft Menus

1275

Monitor[4]

Soft Menus

1276

Monitor[5]

Soft Menus

1277

Monitor[6]

Soft Menus

1278

Monitor[7]

Soft Menus

1279

Monitor[8]

Soft Menus

1280

Monitor[9]

Soft Menus

0340

Mot I2T Active

Motor Load

0342

Mot I2T Enable

Motor Load

0338

Mot I2T TC

Motor Load

0341

Mot I2T Warning

Motor Load

0336

Mot Inv Time Active

Motor Load

0334

Mot Inv Time Delay

Motor Load

0337

Mot Inv Time Output %

Motor Load

0333

Mot Inv Time Overload

Motor Load

0335

Mot Inv Time Warning

Motor Load

0374

Motor Base Volts

Voltage Control

0402

Motor Current

Feedbacks

0401

Motor Current Percent

Feedbacks

0583

motor flux 0_1

Induction Motor Data

0582

motor flux 0_2

Induction Motor Data

0581

motor flux 0_3

Induction Motor Data

0580

motor flux 0_4

Induction Motor Data

0579

motor flux 0_5

Induction Motor Data

0578

motor flux 0_6

Induction Motor Data

0577

motor flux 0_7

Induction Motor Data

0576

motor flux 0_8

Induction Motor Data

0575

motor flux 0_9

Induction Motor Data

0574

motor flux 1_0

Induction Motor Data

0458

Motor Poles

Motor Nameplate

0460

Motor Power

Motor Nameplate

1407

Motor Run Time

Runtime Statistics

1732

Motor Start Count

Runtime Statistics

PNO

Name

Path

0405

Motor Terminal Volts

Feedbacks

0511

Motor Type or AFE

Control Mode

0373

motor volts

Voltage Control

1655

mras acc threshold

MRAS

0285

mras active

MRAS

0280

mras adaptive kc

MRAS

0300

mras adaptive loop bwdt

MRAS

0282

mras adaptive td

MRAS

0281

mras adaptive ti

MRAS

0303

mras blend high freq

MRAS

0302

mras blend low freq

MRAS

0278

mras coupling kc

MRAS

0304

mras coupling loop bwdt

MRAS

0279

mras coupling ti

MRAS

0288

mras field angle

MRAS

0289

MRAS Field Frequency

MRAS

0298

mras flux correction kc

MRAS

0297

mras force encoder fbk

MRAS

0293

mras high speed active

MRAS

1654

mras iq corr level

MRAS

1653

mras La corr limit

MRAS

0292

mras low speed active

MRAS

0301

mras ls blend mode

MRAS

0295

mras ls high threshold

MRAS

0294

mras ls low threshold

MRAS

0296

mras ls mag i scale

MRAS

1249

mras motor inertia

MRAS

1657

mras speed loop factor

MRAS

0286

MRAS Speed Percent

MRAS

0287

MRAS Speed RPM

MRAS

1656

mras start up current

MRAS

0291

MRAS Torque

MRAS

0290

MRAS Torque Percent

MRAS

1250

mras viscous friction

MRAS

0284

mras wmr slw lim at 2bs

MRAS

0283

mras wmr slw lim at bs

MRAS

0483

mseq deflux state

Motor Sequencer

0480

mseq main state

Motor Sequencer

0481

mseq post running state

Motor Sequencer

0482

mseq pre running state

Motor Sequencer

0572

Mutual Inductance

Induction Motor Data

1550

Nameplate Mag Current

Autotune

0459

Nameplate Speed

Motor Nameplate

0416

Negative Torque Lim

Torque Limit

1146

no of channels

Fast Trace Config

0976

Nominal Supply

Drive info

0573

nplate rpm when autotn

Induction Motor Data

1256

OEM ID

Drive info

1241

Open Connections

Modbus

0198

Option DHCP Enabled

Option Ethernet

0206

Option FTP Admin Mode

Option Ethernet

0205

Option FTP Enable

Option Ethernet

0197

Option Gateway

Option Ethernet

1180

Option IO Diagnostic

Option IO

1179

Option IO Fitted

Option IO

Parameter Reference

D-245

PNO

Name

Path

1178

Option IO Required

Option IO

0195

Option IP Address

Option Ethernet

0189

Option MAC Address

Option Ethernet

0196

Option Subnet Mask

Option Ethernet

0203

Option Web Enable

Option Ethernet

1540

Other Parameters

Clone

1756

Output A

System Board IO

1757

Output B

System Board IO

1678

Output Enable

System Board IO

3064

Output Mapping

Fieldbus Mapping

3065

Output Mapping[0]

Fieldbus Mapping

3066

Output Mapping[1]

Fieldbus Mapping

3075

Output Mapping[10]

Fieldbus Mapping

3076

Output Mapping[11]

Fieldbus Mapping

3077

Output Mapping[12]

Fieldbus Mapping

3078

Output Mapping[13]

Fieldbus Mapping

3079

Output Mapping[14]

Fieldbus Mapping

3080

Output Mapping[15]

Fieldbus Mapping

3081

Output Mapping[16]

Fieldbus Mapping

3082

Output Mapping[17]

Fieldbus Mapping

3083

Output Mapping[18]

Fieldbus Mapping

3084

Output Mapping[19]

Fieldbus Mapping

3067

Output Mapping[2]

Fieldbus Mapping

3085

Output Mapping[20]

Fieldbus Mapping

3086

Output Mapping[21]

Fieldbus Mapping

3087

Output Mapping[22]

Fieldbus Mapping

3088

Output Mapping[23]

Fieldbus Mapping

3089

Output Mapping[24]

Fieldbus Mapping

3090

Output Mapping[25]

Fieldbus Mapping

3091

Output Mapping[26]

Fieldbus Mapping

3092

Output Mapping[27]

Fieldbus Mapping

3093

Output Mapping[28]

Fieldbus Mapping

3094

Output Mapping[29]

Fieldbus Mapping

3068

Output Mapping[3]

Fieldbus Mapping

3095

Output Mapping[30]

Fieldbus Mapping

3096

Output Mapping[31]

Fieldbus Mapping

3069

Output Mapping[4]

Fieldbus Mapping

3070

Output Mapping[5]

Fieldbus Mapping

3071

Output Mapping[6]

Fieldbus Mapping

3072

Output Mapping[7]

Fieldbus Mapping

3073

Output Mapping[8]

Fieldbus Mapping

3074

Output Mapping[9]

Fieldbus Mapping

1679

Output Source

System Board IO

1680

Output Voltage

System Board IO

1758

Output Z

System Board IO

1029

overrun count

Tasks

1030

overrun count[0]

Tasks

1031

overrun count[1]

Tasks

1032

overrun count[2]

Tasks

0537

p gain adjustment

Current Loop

0231

Parity And Stop Bits

Modbus RTU

1097

Password in Favourite

Graphical Keypad

1098

Password in Local

Graphical Keypad

1725

Peer to Peer Enable

Peer to Peer

1729

Peer to Peer State

Peer to Peer

0560

PMAC Back Emf Const KE

PMAC Motor Data

PNO

Name

Path

1387

PMAC Base Volt

PMAC Motor Data

1808

PMAC Encoder Offset

PMAC Motor Data

0693

PMAC Fly Active

PMAC Flycatching

0692

PMAC Fly Load Level

PMAC Flycatching

0690

PMAC Fly Search Mode

PMAC Flycatching

0691

PMAC Fly Search Time

PMAC Flycatching

0694

PMAC Fly Setpoint

PMAC Flycatching

0689

PMAC Flycatching Enable

PMAC Flycatching

0556

PMAC Max Current

PMAC Motor Data

0555

PMAC Max Speed

PMAC Motor Data

0564

PMAC Motor Inertia

PMAC Motor Data

0559

PMAC Motor Poles

PMAC Motor Data

0557

PMAC Rated Current

PMAC Motor Data

0558

PMAC Rated Torque

PMAC Motor Data

0467

PMAC SVC Auto Values

PMAC SVC

0470

PMAC SVC I Gain Hz

PMAC SVC

0475

pmac svc ke end grd

PMAC SVC

0474

pmac svc ke speed

PMAC SVC

0473

pmac svc ke strt grd

PMAC SVC

0468

PMAC SVC LPF Speed Hz

PMAC SVC

0476

PMAC SVC Open Loop Strt

PMAC SVC

0469

PMAC SVC P Gain

PMAC SVC

0463

pmac svc spd end grd

PMAC SVC

0462

pmac svc spd strt grd

PMAC SVC

0471

pmac svc spd thres

PMAC SVC

0472

pmac svc speed grd

PMAC SVC

0478

PMAC SVC Start Cur

PMAC SVC

0479

PMAC SVC Start Speed

PMAC SVC

0477

PMAC SVC Start Time

PMAC SVC

0565

PMAC Therm Time Const

PMAC Motor Data

0563

PMAC Torque Const KT

PMAC Motor Data

0562

PMAC Winding Inductance

PMAC Motor Data

0561

PMAC Winding Resistance

PMAC Motor Data

1809

PMAC Wiring

PMAC Motor Data

0415

Positive Torque Lim

Torque Limit

0461

Power Factor

Motor Nameplate

0386

Power Factor Angle Est

Energy Meter

0385

Power Factor Est

Energy Meter

0381

Power HP

Energy Meter

0380

Power kW

Energy Meter

1541

Power Parameters

Clone

0543

Power Stack Fitted

Drive info

0987

Power Stack Required

Drive info

0943

Process Active

Modbus

1551

Product Code Flags

Drive info

0238

Profibus Node Address

Profibus

0237

Profibus State

Profibus

0240

PROFINET Device Name

PROFINET IO

0239

PROFINET State

PROFINET IO

1054

Project Author

App Info

1068

Project Description

App Info

1040

Project File Name

App Info

1061

Project Version

App Info

1699

PTP Clock

PTP

1683

PTP Clock Mode

PTP

1684

PTP Clock Type

PTP

PNO

Name

Path

1787

PTP Domain Number

PTP

1661

PTP Enable

PTP

1685

PTP Lock Threshold

PTP

1688

PTP Locked

PTP

1681

PTP Log Sync Interval

PTP

1687

PTP Offset

PTP

1686

PTP Priority2

PTP

1689

PTP State

PTP

0391

PWM ISR Overhead

Pattern Generator

1648

Pwrl Accel Rate

Power Loss Ride Thru

1651

Pwrl Active

Power Loss Ride Thru

1647

Pwrl Control Band

Power Loss Ride Thru

1649

Pwrl Decel Rate

Power Loss Ride Thru

1645

Pwrl Enable

Power Loss Ride Thru

1650

Pwrl Time Limit

Power Loss Ride Thru

1646

Pwrl Trip Threshold

Power Loss Ride Thru

0508

Quickstop Ramp Time

Ramp

0507

Quickstop Time Limit

Ramp

0497

Ramp Hold

Ramp

0499

Ramp Spd Setpoint Input

Ramp

0500

Ramp Speed Output

Ramp

0510

ramp time step

Ramp

0485

Ramp Type

Ramp

0498

Ramping Active

Ramp

1682

Random Pattern AFE

Pattern Generator

0413

Random Pattern IM

Pattern Generator

1268

Random Pattern PMAC

Pattern Generator

0455

Rated Motor Current

Motor Nameplate

1247

Ratio Load Mot Inert

Spd Loop Settings

0388

raw kvar

Energy Meter

0387

raw kw

Energy Meter

0382

Reactive Power

Energy Meter

0055

Read Mapping

Read Process

0056

Read Mapping[0]

Read Process

0057

Read Mapping[1]

Read Process

0066

Read Mapping[10]

Read Process

0067

Read Mapping[11]

Read Process

0068

Read Mapping[12]

Read Process

0069

Read Mapping[13]

Read Process

0070

Read Mapping[14]

Read Process

0071

Read Mapping[15]

Read Process

0072

Read Mapping[16]

Read Process

0073

Read Mapping[17]

Read Process

0074

Read Mapping[18]

Read Process

0075

Read Mapping[19]

Read Process

0058

Read Mapping[2]

Read Process

0076

Read Mapping[20]

Read Process

0077

Read Mapping[21]

Read Process

0078

Read Mapping[22]

Read Process

0079

Read Mapping[23]

Read Process

0080

Read Mapping[24]

Read Process

0081

Read Mapping[25]

Read Process

0082

Read Mapping[26]

Read Process

0083

Read Mapping[27]

Read Process

0084

Read Mapping[28]

Read Process

0085

Read Mapping[29]

Read Process

D-246

Parameter Reference

PNO

Name

Path

0059

Read Mapping[3]

Read Process

0086

Read Mapping[30]

Read Process

0087

Read Mapping[31]

Read Process

0060

Read Mapping[4]

Read Process

0061

Read Mapping[5]

Read Process

0062

Read Mapping[6]

Read Process

0063

Read Mapping[7]

Read Process

0064

Read Mapping[8]

Read Process

0065

Read Mapping[9]

Read Process

1442

Recent Trip Times

Trips History

1443

Recent Trip Times[0]

Trips History

1444

Recent Trip Times[1]

Trips History

1445

Recent Trip Times[2]

Trips History

1446

Recent Trip Times[3]

Trips History

1447

Recent Trip Times[4]

Trips History

1448

Recent Trip Times[5]

Trips History

1449

Recent Trip Times[6]

Trips History

1450

Recent Trip Times[7]

Trips History

1451

Recent Trip Times[8]

Trips History

1452

Recent Trip Times[9]

Trips History

0895

Recent Trips

Trips History

0896

Recent Trips[0]

Trips History

0897

Recent Trips[1]

Trips History

0898

Recent Trips[2]

Trips History

0899

Recent Trips[3]

Trips History

0900

Recent Trips[4]

Trips History

0901

Recent Trips[5]

Trips History

0902

Recent Trips[6]

Trips History

0903

Recent Trips[7]

Trips History

0904

Recent Trips[8]

Trips History

0905

Recent Trips[9]

Trips History

1265

Ref Max Speed Clamp

Speed Ref

1264

Ref Min Speed Clamp

Speed Ref

1266

Ref Speed Trim

Speed Ref

1267

Ref Trim Local

Speed Ref

0682

Reference

Sequencing

0321

regen hold

Flycatching

0307

Regen Limit Enable

Current Limit

0389

Reset Energy Meter

Energy Meter

1012

reset task timers

Tasks

1000

Reset to Defaults

Device Commands

1827

resolver active resol

Resolver

1826

Resolver Actual Filter

Resolver

1822

Resolver Built-In Gear

Resolver

1812

Resolver Fraction Turns

Resolver

1791

Resolver Frequency

Resolver

1810

Resolver Invert

Resolver

1825

Resolver Max Speed

Resolver

1851

Resolver Min Filter

Resolver

1793

Resolver Poles

Resolver

1824

resolver position

Resolver

1792

Resolver Ratio

Resolver

1819

Resolver Reset Power On

Resolver

1816

Resolver Resolution

Resolver

1814

Resolver Speed %

Resolver

PNO

Name

Path

1815

Resolver Speed Filter

Resolver

1821

Resolver Speed Hz

Resolver

1823

Resolver Speed Ripple

Resolver

1813

Resolver speed RPM

Resolver

1817

Resolver State

Resolver

1820

Resolver Trip Type

Resolver

1811

Resolver Turns

Resolver

1818

Resolver Turns Reset

Resolver

1790

Resolver Voltage

Resolver

0569

Rotor Time Constant

Induction Motor Data

0998

RTA Code

Device State

0999

RTA Data

Device State

1003

RTA Thread Priority

Device State

1187

RTC Trim

General Purpose IO

1140

Run Key Action

Local Control

1006

Run Wizard?

Setup Wizard

1171

sample numbers

Fast Trace Config

1172

sampling number

Fast Trace Config

1001

Save All Parameters

Device Commands

0411

Save is Required

Setup Wizard

1759

SB Digital Input 1

System Board IO

1722

SB Digital Input 2

System Board IO

1723

SB Digital Input 3

System Board IO

0466

scaled setpoint hz

Scale Setpoint

0465

scaled setpoint rpm

Scale Setpoint

1175

scope max length hex

Fast Trace Status

1176

scope offset hex

Fast Trace Status

1174

scope start addr hex

Fast Trace Status

1173

scope status

Fast Trace Status

0315

Search Boost

Flycatching

0313

Search Mode

Flycatching

0316

Search Time

Flycatching

0314

Search Volts

Flycatching

0527

Sel Torq Ctrl Only

Spd Loop Settings

1257

Seq Stop Method SVC

Ramp

0484

Seq Stop Method VHz

Ramp

0678

Sequencing State

Sequencing

1311

Setup

Soft Menus

1008

Setup Application?

Setup Wizard

1011

Setup Base Ethernet?

Setup Wizard

1107

Setup Base Modbus?

Setup Wizard

1786

Setup EtherNet IP?

Setup Wizard

1010

Setup Fieldbus?

Setup Wizard

1009

Setup Input/Output?

Setup Wizard

1007

Setup Motor or AFE?

Setup Wizard

1564

Setup Option IO?

Setup Wizard

1749

Setup Successful

Configure

1312

Setup[0]

Soft Menus

1313

Setup[1]

Soft Menus

1322

Setup[10]

Soft Menus

1323

Setup[11]

Soft Menus

1324

Setup[12]

Soft Menus

1325

Setup[13]

Soft Menus

1326

Setup[14]

Soft Menus

1327

Setup[15]

Soft Menus

PNO

Name

Path

1328

Setup[16]

Soft Menus

1329

Setup[17]

Soft Menus

1330

Setup[18]

Soft Menus

1331

Setup[19]

Soft Menus

1314

Setup[2]

Soft Menus

1315

Setup[3]

Soft Menus

1316

Setup[4]

Soft Menus

1317

Setup[5]

Soft Menus

1318

Setup[6]

Soft Menus

1319

Setup[7]

Soft Menus

1320

Setup[8]

Soft Menus

1321

Setup[9]

Soft Menus

0346

Short Overload Level

Stack Inv Time

0347

Short Overload Time

Stack Inv Time

1752

Slave Encoder

Configure

1744

Slave Position Src

Configure

0320

slew delta

Flycatching

0361

Slew Rate Accel Limit

Slew Rate

0362

Slew Rate Decel Limit

Slew Rate

0360

Slew Rate Enable

Slew Rate

0363

slew rate setpoint

Slew Rate

0355

slip compensation trim

Slip Compensation

0354

Slip Compensatn Enable

Slip Compensation

0358

slp filter tc

Slip Compensation

0356

SLP Motoring Limit

Slip Compensation

0357

SLP Regen Limit

Slip Compensation

0359

slp setpoint

Slip Compensation

1794

Soft Key 2 Mode

Graphical Keypad

1795

Soft Key 2 Value

Graphical Keypad

0522

spd aux torq filt tc

Spd Loop Settings

0526

Spd Demand Neg Lim

Spd Loop Settings

0525

Spd Demand Pos Lim

Spd Loop Settings

1780

Spd Limiter Torq Ctrl

Spd Loop Settings

0524

Spd Loop Adapt Pgain

Spd Loop Settings

0523

Spd Loop Adapt Thres

Spd Loop Settings

0521

Spd Loop Aux Torq Dmd

Spd Loop Settings

0519

Spd Loop Dmd Filt TC

Spd Loop Settings

1753

Spd Loop Encoder

Configure

0520

Spd Loop Fbk Filt TC

Spd Loop Settings

1525

speed at int range =0

Tr Adaptation

1747

Speed Error Threshold

Speed Error Trip

1748

Speed Error Trip Delay

Speed Error Trip

1746

Speed Error Trip Enable

Speed Error Trip

1781

Speed Limiter Active

Spd Loop Diagnostics

1246

Speed Loop Auto Set

Spd Loop Settings

1248

Speed Loop Bandwidth

Spd Loop Settings

0535

Speed Loop Error

Spd Loop Diagnostics

0516

Speed Loop I Time

Spd Loop Settings

0517

Speed Loop Int Defeat

Spd Loop Settings

0518

Speed Loop Int Preset

Spd Loop Settings

0515

Speed Loop Pgain

Spd Loop Settings

0536

Speed PI Output

Spd Loop Diagnostics

0491

Sramp Acceleration

Ramp

0490

Sramp Continuous

Ramp

0492

Sramp Deceleration

Ramp

Parameter Reference

D-247

PNO

Name

Path

0493

Sramp Jerk 1

Ramp

0494

Sramp Jerk 2

Ramp

0495

Sramp Jerk 3

Ramp

0496

Sramp Jerk 4

Ramp

0364

Stabilisation Enable

Stabilisation

0404

Stack Current (%)

Feedbacks

0412

Stack Frequency

Pattern Generator

0984

stack id

Drive info

1109

Stack Pcode

Drive info

1258

Stack Serial No

Drive info

0985

stack voltage

Drive info

0910

Stall Current Active

Stall Trip

0906

Stall Limit Type

Stall Trip

0911

Stall Speed Feedback

Stall Trip

0907

Stall Time

Stall Trip

0909

Stall Torque Active

Stall Trip

1634

Start Delay

Motor Sequencer

1560

Start Delay Enable

Motor Sequencer

0982

Startup Page

Graphical Keypad

0571

Stator Resistance

Induction Motor Data

0661

Status Word

Sequencing

0367

stb filter tc

Stabilisation

0366

stb gain

Stabilisation

0369

stb setpoint

Stabilisation

0365

stb slew rate limit

Stabilisation

0370

stb trim

Stabilisation

0368

stb trim limit

Stabilisation

1242

stimulus cur ampltude

Stimulus

1243

stimulus cur offset

Stimulus

1245

stimulus cur output

Stimulus

1244

stimulus cur period

Stimulus

0550

stimulus spd ampltude

Stimulus

0547

stimulus spd enable

Stimulus

0552

stimulus spd freq

Stimulus

0551

stimulus spd offset

Stimulus

0554

stimulus spd output

Stimulus

0549

stimulus spd type

Stimulus

0553

stimulus test angle

Stimulus

0504

Stop Ramp Time

Ramp

0927

Subnet Mask

Ethernet

1638

svc start adjustment

Current Loop

1639

svc start freq limit

Current Loop

0679

Switch On Timeout

Sequencing

0250

switching level

Braking

1701

Switchover Enable

MRAS

1700

switchover speed level

MRAS

0488

Symmetric Mode

Ramp

0489

Symmetric Time

Ramp

0419

Symmetric Torque Lim

Torque Limit

1702

Synth Encoder Invert

System Board IO

1696

Synth Encoder Lines

System Board IO

1698

Synth Encoder Speed

System Board IO

1742

System Board FE State

Device State

1740

System Board Fitted

System Board Option

1739

System Board Required

System Board Option

1741

System Board Status

System Board Option

PNO

Name

Path

0988

Target State

Device State

1099

Technician Password

Graphical Keypad

1519

term v integral range

Tr Adaptation

0371

Terminal Voltage Mode

Voltage Control

1529

Terminal Volts

Tr Adaptation

1185

Thermistor Resistance

Thermistor

1004

Thermistor Trip Level

Thermistor

1184

Thermistor Type

Thermistor

1762

Thermistor Warn Delta

Thermistor

1186

Time and Date

Real Time Clock

1733

Time Since Power-On

Runtime Statistics

1170

time tick

Fast Trace Config

0590

total inertia

Induction Motor Data

0534

Total Spd Demand %

Spd Loop Diagnostics

0533

Total Spd Demand RPM

Spd Loop Diagnostics

1521

Tr Adaptation Output

Tr Adaptation

1662

transferring

Fast Trace Config

1167

trigger direction

Fast Trace Config

1168

trigger level

Fast Trace Config

1169

trigger offset

Fast Trace Config

1166

trigger source

Fast Trace Config

1660

underlap comp off

Pattern Generator

1002

Update Firmware

Device Commands

0935

User Gateway Address

Ethernet

0933

User IP Address

Ethernet

0934

User Subnet Mask

Ethernet

0311

VC Flying Start Enable

Flycatching

1643

VDC Lim Active

DC Link Volts Limit

1641

VDC Lim Enable

DC Link Volts Limit

1642

VDC Lim Level

DC Link Volts Limit

1644

VDC Lim Output

DC Link Volts Limit

0912

VDC Ripple Filter TC

VDC Ripple

0917

VDC Ripple Level

VDC Ripple

0916

VDC Ripple Sample

VDC Ripple

0914

VDC Ripple Trip Delay

VDC Ripple

0915

VDC Ripple Trip Hyst

VDC Ripple

1143

Version

Graphical Keypad

0310

VHz Flying Start Enable

Flycatching

0422

VHz Shape

Fluxing VHz

0423

VHz User Freq

Fluxing VHz

0424

VHz User Freq[0]

Fluxing VHz

0425

VHz User Freq[1]

Fluxing VHz

0434

VHz User Freq[10]

Fluxing VHz

0426

VHz User Freq[2]

Fluxing VHz

0427

VHz User Freq[3]

Fluxing VHz

0428

VHz User Freq[4]

Fluxing VHz

0429

VHz User Freq[5]

Fluxing VHz

0430

VHz User Freq[6]

Fluxing VHz

0431

VHz User Freq[7]

Fluxing VHz

0432

VHz User Freq[8]

Fluxing VHz

0433

VHz User Freq[9]

Fluxing VHz

0435

VHz User Volts

Fluxing VHz

0436

VHz User Volts[0]

Fluxing VHz

0437

VHz User Volts[1]

Fluxing VHz

0446

VHz User Volts[10]

Fluxing VHz

0438

VHz User Volts[2]

Fluxing VHz

PNO

Name

Path

0439

VHz User Volts[3]

Fluxing VHz

0440

VHz User Volts[4]

Fluxing VHz

0441

VHz User Volts[5]

Fluxing VHz

0442

VHz User Volts[6]

Fluxing VHz

0443

VHz User Volts[7]

Fluxing VHz

0444

VHz User Volts[8]

Fluxing VHz

0445

VHz User Volts[9]

Fluxing VHz

1141

View Level

Graphical Keypad

0452

volt boost i limit

Fluxing VHz

0372

voltage control enable

Voltage Control

0378

voltage control vsd

Voltage Control

0377

voltage control vsq

Voltage Control

0453

Vsd Demand

Fluxing VHz

0545

Vsd Demand

Current Loop

0454

Vsq Demand

Fluxing VHz

0544

Vsq Demand

Current Loop

0829

Warnings 1 - 32

Trips Status

0514

Warnings 33 - 64

Trips Status

0972

Warranty Trip Time

Trips History

0973

Warranty Trip Time[0]

Trips History

0974

Warranty Trip Time[1]

Trips History

0975

Warranty Trip Time[2]

Trips History

0968

Warranty Trips

Trips History

1408

Warranty Trips Record

Trips History

0969

Warranty Trips[0]

Trips History

0970

Warranty Trips[1]

Trips History

0971

Warranty Trips[2]

Trips History

0944

Web Access

Web Server

0204

Web Parameters Enable

Option Ethernet

0946

Web Password

Web Server

0945

Web View Level

Web Server

0120

Write Mapping

Write Process

0121

Write Mapping[0]

Write Process

0122

Write Mapping[1]

Write Process

0131

Write Mapping[10]

Write Process

0132

Write Mapping[11]

Write Process

0133

Write Mapping[12]

Write Process

0134

Write Mapping[13]

Write Process

0135

Write Mapping[14]

Write Process

0136

Write Mapping[15]

Write Process

0137

Write Mapping[16]

Write Process

0138

Write Mapping[17]

Write Process

0139

Write Mapping[18]

Write Process

0140

Write Mapping[19]

Write Process

0123

Write Mapping[2]

Write Process

0141

Write Mapping[20]

Write Process

0142

Write Mapping[21]

Write Process

0143

Write Mapping[22]

Write Process

0144

Write Mapping[23]

Write Process

0145

Write Mapping[24]

Write Process

0146

Write Mapping[25]

Write Process

0147

Write Mapping[26]

Write Process

0148

Write Mapping[27]

Write Process

0149

Write Mapping[28]

Write Process

0150

Write Mapping[29]

Write Process

0124

Write Mapping[3]

Write Process

Parameter Reference

D-249

Power Dependent Parameter Defaults

The tables below shows the parameters whose default value is dependent on the Power Stack.

PNO NONE

3.5 A 400 V 4.5 A 400 V 5.5 A 400 V 7.5 A 400 V 10.0 A 400 V 12.0 A 400 V 16.0 A 400 V 23.0 A 400 V 32.0 A 400 V 38.0 A 400 V 45.0 A 400 V R1

45.0 A 400 V

Brake Resistance

Ohm 251

100

Brake Rated Power

252

0.1

0.11

0.15

0.22

0.3

0.4

0.55

0.75

1.1

1.5

1.8

2.2

Autotune Ramp Time

274

mras coupling kc

278

14.9874 14.9874

11.5288

6.2448

2.9363

1.7128

2.6526

1.314

0.9592

0.7105

mras coupling ti

279

0.45

mras adaptive kc

280

4.3851

2.6283

1.5279

0.7514

0.5727

0.6854

0.3198

0.3484

0.1792

mras adaptive ti

281

0.112

mras adaptive td

282

0.1094

0.1367

0.276

0.3036

0.3795

0.506

mras ls low threshold

294

1.5

mras ls high threshold

295

2.5

mras adaptive loop bwdt Hz

300

i lim vhz p gain

308

i lim vhz i gain

309

0.5

0.3

Search Volts

314

Search Boost

315

Search Time

316

Flying Reflux Time

318

error scaler

322

200

175

150

DC Inj Deflux Time

324

0.5

1.5

DC Inj Frequency

325

DC Pulse Time

327

Final DC Pulse Time

328

DC Current Level

329

2.5

1.75

1.25

DC Inj Base Volts

331

100

stb gain

366

0.1

stb trim limit

368

0.75

0.5

Stack Frequency

kHz

412

Deflux Delay

414

Fixed Boost

447

auto boost tc

449

0.25

0.3

Rated Motor Current

455

1.56

2.88

4.9

6.5

8.4

9.04

14.6

26.4

Base Voltage

456

400

Base Frequency

457

Nameplate Speed

RPM 459

1400

1420

1445

1450

1460

1470

1460

Motor Power

460

1.1

1.5

2.2

5.5

7.5

Power Factor

461

0.71

0.7

0.78

0.8

0.83

0.86

0.87

0.88

100% Speed in RPM

RPM 464

1500

Acceleration Time

486

Deceleration Time

487

Symmetric Time

489

total inertia

kgm² 590

0.0014

0.0035

0.05

0.0112

0.0176

0.0236

0.0603

0.0754

Stall Time

907

Max VDC Ripple

913

VDC Ripple Trip Delay

914

stack voltage

985

frame size

986

mras motor inertia

kgm² 1249 0.0014

0.0014

0.0035

0.05

0.0112

0.0176

0.0236

0.0603

0.0754

Nameplate Mag Current A

1550 0.88

0.88

1.65

2.45

3.12

4.03

4.34

6.51

8.16

10.65

10.03

14.44

D-250

Parameter Reference

PNO 60.0 A 400 V R1

60.0 A 400 V

73.0 A 400 V R1
73.0 A 400 V

87.0 A 400 V 105 A 400 V 145 A 400 V 180 A 400 V 205 A 400 V 260 A 400 V 315 A 400 V 380 A 400 V 440 A 400 V

Brake Resistance

Ohm 251

Brake Rated Power

252

3.7

4.5

5.5

7.5

13.2

Autotune Ramp Time

274

mras coupling kc

278

0.5048

0.3553

0.2907

0.2428

0.1798

0.1453

0.127

0.1043

0.0888

0.0783

0.0648

mras coupling ti

279

0.45

mras adaptive kc

280

0.305

0.2823

0.2974

0.2472

0.2226

0.1427

0.1343

0.1228

0.1021

0.0895

0.0692

mras adaptive ti

281

0.112

mras adaptive td

282

0.3795

0.506

0.6073

0.7591

1.5182

2.0243

mras ls low threshold

294

1.5

mras ls high threshold

295

2.5

mras adaptive loop bwdt Hz

300

i lim vhz p gain

308

i lim vhz i gain

309

0.3

0.2

Search Volts

314

Search Boost

315

Search Time

316

Flying Reflux Time

318

error scaler

322

150

DC Inj Deflux Time

324

1.5

DC Inj Frequency

325

DC Pulse Time

327

Final DC Pulse Time

328

DC Current Level

329

1.25

DC Inj Base Volts

331

stb gain

366

0.1

stb trim limit

368

0.5

Stack Frequency

kHz

412

2.5

Deflux Delay

414

3.5

Fixed Boost

447

auto boost tc

449

0.3

0.5

Rated Motor Current

455

132

164

186

236

287

346

401

Base Voltage

456

400

Base Frequency

457

Nameplate Speed

RPM 459

1470

1475

1480

1485

Motor Power

460

110

132

160

200

250

Power Factor

461

0.86

0.85

0.87

0.86

0.87

0.9

0.91

0.92

0.93

100% Speed in RPM

RPM 464

1500

Acceleration Time

486

Deceleration Time

487

Symmetric Time

489

total inertia

kgm² 590

0.1906

0.475

0.7476

0.8904

1.45

1.722

2.65

3.6

5.5

6.2

Stall Time

907

Max VDC Ripple

913

VDC Ripple Trip Delay

914

stack voltage

985

frame size

986

mras motor inertia

kgm² 1249 0.1906

0.475

0.7476

0.8904

1.45

1.722

2.65

3.6

5.5

6.2

Nameplate Mag Current A

1550 22.04

27.81

31.16

39.6

52.07

110

131

152

Technical Specifications

F-2

Typical example: 710-4D004-BF-0S-0000 (as shown in the “Order example” above).
This shows the product is an AC30 series AC line fed Frame D drive, IP21 standard, rated at 400-480 volts supply, 1.1kW (normal duty), with brake
switch fitted, Category C2 EMC filter, no Graphical Keypad fitted, standard 3C3 conformal coating and no special options.

Note: This product code is for the power stack only. The control module must be ordered in addition to this (see previous page).

AC30 Series Power Stack Product Order Code

710

0004

0000

710

AC Power stack only (no control module)

Without brake switch

740

DC Power stack only (no control module)

Brake switch fitted (standard)

400 V nominal supply system (AC line)

No filter fitted

Category C3 filter fitted (standard)

(normal / heavy duty)

Category C2 filter fitted

D0004

1.1 kW / 0.75 kW

D0005

1.5 kW / 1.1 kW

No keypad fitted

D0006

2.2 kW / 1.5 kW

D0008

3 kW / 2.2 kW

Standard 3C3 coating

D0010

4 kW / 3 kW

Enhanced coating

D0012

5.5 kW / 4 kW

E0016

7.5 kW / 5.5 kW

0000

No special options

E0023

11 kW / 7.5 kW

F0032

15 kW / 11 kW

(1)

Frame size K products are available in AC line fed options only (710 family).

F0038

18.5 kW / 15 kW

(2)

1. Only EMC filter option N is valid on DC fed stacks (740 family).

F0045

22 kW / 18.5 kW

(3)

2. Only EMC filter option E is valid on Frame size K products.

G0045

22 kW / 18.5 kW

(3)

3. EMC filter option F is not valid on Frame size J products.

G0060

30 kW / 22 kW

G0073

37 kW / 30 kW

H0087

45 kW / 37 kW

H0105

55 kW / 45 kW

H0145

75 kW / 55 kW

J0180

90 kW / 75 kW

J0205

110 kW / 90 kW

J0260

132 kW / 110 kW

K0300

160 kW / 132 kW

K0380

200 kW / 160 kW

K0440

250 kW / 200 kW

Environmental Coating

Special Options

Frame Size and Current Rating

Graphical Keypad

Order example

Brake Switch

EMC Filter

(2)

Device Family

(1)

Voltage

F-3

Technical Specifications

Typical example: 31V-4D004-BF-2S-0000 (as shown in the “Order example” above).
This shows the product is an AC30V Frame D drive, IP21 standard suitable for fan and pump industry, rated at 400-480 volts supply, 1.1kW (normal
duty), with brake switch fitted, Category C2 EMC filter, with Graphical Keypad fitted, standard 3C3 conformal coating and no special options.

Note: This product code is for a complete AC30V series drive (includes both control module and power stack).

AC30V Series Configured Product Order Code

31V

0004

0000

31V

AC30V series complete line fed drive

Without brake switch

Brake switch fitted (standard)

400 V nominal supply system (AC line)

No filter fitted

(normal / heavy duty)

Category C3 filter fitted (standard)

D0004

1.1 kW / 0.75 kW

Category C2 filter fitted

D0005

1.5 kW / 1.1 kW

D0006

2.2 kW / 1.5 kW

No keypad fitted

D0008

3 kW / 2.2 kW

Blanking cover fitted

D0010

4 kW / 3 kW

Graphical keypad fitted

D0012

5.5 kW / 4 kW

E0016

7.5 kW / 5.5 kW

Standard 3C3 coating

E0023

11 kW / 7.5 kW

Enhanced coating

F0032

15 kW / 11 kW

F0038

18.5 kW / 15 kW

0000

No special options

F0045

22 kW / 18.5 kW

G0045

22 kW / 18.5 kW

(1)

1. Only EMC filter option E is valid on Frame size K products.

G0060

30 kW / 22 kW

(2)

2. EMC filter option F is not valid on Frame size J products.

G0073

37 kW / 30 kW

H0087

45 kW / 37 kW

H0105

55 kW / 45 kW

H0145

75 kW / 55 kW

J0180

90 kW / 75 kW

J0205

110 kW / 90 kW

J0260

132 kW / 110 kW

K0300

160 kW / 132 kW

K0380

200 kW / 160 kW

K0440

250 kW / 200 kW

Voltage

Device Family

Special Options

Order example

Brake Switch

EMC Filter

(1)

Graphical Keypad

Environmental Coating

Frame Size and Current Rating

Parker Variable Speed Drive AC30 series. User’s Manual (2017) - page 34
