15-35
Note: When the cylinder head is installed - Fill 3 mm holes in cylinder head gasket with sealing compound - Install cylinder head, insert new cylinder head bolts and tighten by
Note: The longer cylinder head bolts must - Tighten cylinder head bolts in tightening sequence as follows: - Pretighten all bolts to 30 Nm. - Then tighten all bolts to 50 Nm. - Then tighten all bolts 1 / 4 turn (90 ) further with a rigid wrench. - Then tighten all bolts again 1 / 4
turn (90 ) further. Cylinder head, servicing |
