Dacia SuperNova (engine E7J). Manual - part 128

82B

HORN - ENGINE IMMOBILISER

82B -  45

Volumetric protection checking.

Perform the following checking steps after locking using the RF remote control, the doors, the

engine hood and the hatchback. The operations must be performed in no more than 40 seconds
since the anti intrusion system has been activated with the RF remote control; if operating after
these 40 seconds, the siren will start and the turning lights will blink.

Close the door. The sound signal (buzzer)
will stop.

The proper operation of the anti intrusion system on different situations must be according to

those shown in Table 01.

For detecting the causes of possible incidents of the anti intrusion system, perform the checking

steps presented in Table 02.

Lower the rear windows with about 10
cm. Close the doors, the engine hood
and the hatchback.
Check out if there is any movement in
the cockpit.
Activate the system pressing the button
of the RF remote control.

Introduce a hand through the window,
inside the cockpit and move it.
The LED indicator will blink quickly,
showing there has been a volumetric
detection and that volumetric sensors are
functioning correctly.

Deactivate the system using the RF
remote  control,  then close all the
vehicle windows.

Reactivate the system and then hit by
ha nd the  window s surfa c e  of the
vehicle. The LED indicator should
continue to normally blink and the siren
starting shall not occur.

Functional checking of the peripheral
protection.

Close the doors, the engine hood and the
hatchback.
Activate the system pressing the button
of the RF remote.
The doors will lock and the LED indicator
will blink.

Open a door with the vehicle key.
The LED indicator will continuously be

 on,

and a sound signal (buzzer) will be heard.

Deactivate  and reactivate  the system
with the RF remote control.

Deactivate the system by pressing the
button of the RF remote control.
The doors will unlock and the  LED
indicator will go off.

Repeat a.m. operations for both front
doors, engine hood and hatchback.

FUNCTIONAL CHECKING OF THE SYSTEM

82B

HORN - ENGINE IMMOBILISER

82B -  46

ATTENTION
Checking the wiring continuity between the components of the anti intrusion

system shall be performed only after disconnecting the anti intrusion ECU and the
siren.

CHARACTERISTICS

- nominal supply tension ……………………………………… 12 V after contact
- operation tension …………………………………………..9 –16 V after contact
- consumption at 12 V after contact:
- on deactivated state ………………………………………….< 8mA
- on activated state ……………………………………………...< 13mA
- operation temperature anti intrusion ECU …………………- 40          +85º  C
- operation temperature of siren ………………………………- 40          +85º  C

acoustic power …………………………………………………> 118 dB (A) from a distance

of 1 meter

FUNCTIONAL CHECKING OF THE SYSTEM

82B

HORN - ENGINE IMMOBILISER

82B -  47

TABLE 1

82B

HORN - ENGINE IMMOBILISER

82B -  48

TABLE 1
