Dacia Solenza (engine E7J). Manual - part 145
82
ACCOUSTIC WARNING - ANTI STARTING
82 - 37
Diagnostic
11. Remote control signal reception.
11G = activate the RF remote ACTIVE for 3 seconds
control.
if the decoder
Received signal indication
receives the
remote control signal.
12. Remote control signal validation
11D = activate the RF remote ACTIVE for 3 sec.
control.
if the signal received
Good signal indication
at the decoder
is good.
13. Communication doors locking
14G = blocking/unlocking
ACTIVE when the E.C.U.
switch - E.C.U. decoder.
decoder receives
control from the
doors’ locking switch.
14. Communication E.C.U .decoder -
14D =activation of the doors
ACTIVE when the
doors actuators
actuators
E.C.U. decoder
sends the command
blocking/unlocking to
the actuators of t
he door
s.
15. The condition of the doors contact
16G = doors contact
ACTIVE when the
front doors are opened.
16. Remote controls synchronisation
17G = programming
ACTIVE when the
in process
or resynchronisation TIR/ TRF remote control
resynchronisation
procedure is in proce
ss.
17. RF remote controls synchronisation 17D = not performed
ACTIVE when the
not performed
TIR programming
remote control
synchronisation is not
performed.
18. Not performed key code programming 19G = unperformed key
ACTIVE when the
programming
key programming is
not performed.
19. Validated key code programming
19D = unblocked key
ACTIVE when the
programming
validation of the key
programming is not
performed.
20. The programming of the first key.
18G = the memorising of the
ACTIVE when the
first key
programming of the
first key is in process.
