19 19 - 5 COOLING - EXHAUST - TANK Radiator SPECIAL TOOLS MOT 1202 - 01 Pliers for elastic clips MOT 453 Hoses clamp DISMOUNTING Drain the air conditioning unit – for the ve- hicles with air conditioning (see chapter 62” Fill- Disconnect the battery screen. Detach from clips the oil reservoir from the battery screen, for the vehicles equipped with Clamp the hoses from radiator by means of MOT 453 device. Dismount the hoses from radiator by means of the pliers for elastic clips MOT 1202-01 and Disconnect the engine fan connector (1). the vehicles with air conditioning. Carefully release the engine fan from the four attachment clips (5) on the radiator- for the The vehicles without air conditioning. Carefully remove the engine fan from the sustaining points (7). Dismount the radiator off the side attachment supports on the radiator upper Disconnect the two pipes from condenser. supporting buffers together with the Dismount the condenser attachment screws on the cooling radiator (for vehicles For vehicles with air conditioning. REMOUNTING Mount the condenser on the new cooling radiator (for vehicles with air conditioning). Mount the radiator-condenser assembly on the vehicle, by supporting it in the lower Mount the engine fan assembly on the sustaining supports (7) and attach it in the four 5 4 3 1 5 2 |
