HOW TO USE THIS MANUAL GI-3 < HOW TO USE THIS MANUAL > C D E F G H I J K L M B GI N O P HOW TO USE THIS MANUAL HOW TO USE THIS MANUAL Description INFOID:0000000004205728 This volume explains “Removal, Disassembly, Installation, Inspection and Adjustment” and “Trouble Diag- noses”. Terms INFOID:0000000004205729 • The captions WARNING and CAUTION warn you of steps that must be followed to prevent personal injury and/or damage to some part of the vehicle. WARNING indicates the possibility of personal injury if instructions are not followed. CAUTION indicates the possibility of component damage if instructions are not followed. BOLD TYPED STATEMENTS except WARNING and CAUTION give you helpful information. Standard value: Tolerance at inspection and adjustment. Limit value: The maximum or minimum limit value that should not be exceeded at inspection and adjust- ment. Units INFOID:0000000004205730 • The UNITS given in this manual are primarily expressed as the SI UNIT (International System of Unit), and alternatively expressed in the metric system and in the yard/pound system. Also with regard to tightening torque of bolts and nuts, there are descriptions both about range and about the standard tightening torque. “Example” Range Standard Contents INFOID:0000000004205731 • ALPHABETICAL INDEX is provided at the end of this manual so that you can rapidly find the item and page you are searching for. • A QUICK REFERENCE INDEX, a black tab (e.g. ) is provided on the first page. You can quickly find the first page of each section by matching it to the section's black tab. • THE CONTENTS are listed on the first page of each section. • THE TITLE is indicated on the upper portion of each page and shows the part or system. • THE PAGE NUMBER of each section consists of two or three letters which designate the particular section and a number (e.g. “BR-5”). • THE SMALL ILLUSTRATIONS show the important steps such as inspection, use of special tools, knacks of work and hidden or tricky steps which are not shown in the previous large illustrations. Assembly, inspection and adjustment procedures for the complicated units such as the automatic transaxle or transmission, etc. are presented in a step-by-step format where necessary. Outer Socket Lock Nut : 59 - 78 N·m (6.0 - 8.0 kg-m, 43 - 58 ft-lb) Drive Shaft Installation Bolt : 44.3 N·m (4.5 kg-m, 33 ft-lb) |
