VTL-8

< ON-VEHICLE REPAIR >

CONTROL UNIT

ON-VEHICLE REPAIR

CONTROL UNIT

Removal and Installation

INFOID:0000000004205414

FRONT AIR CONTROL

Removal

1. Remove cluster lid D. Refer to

IP-12, "Removal and Installation"

.

2. Remove the two brackets (1) and remove the front air control.

Installation

Installation is in the reverse order of removal.

ALIIA0011ZZ

IN-VEHICLE SENSOR

VTL-9

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

J

K

L

M

A

B

VTL

N

O

P

IN-VEHICLE SENSOR

Removal and Installation

INFOID:0000000004205415

REMOVAL

1. Remove the instrument lower cover LH. Refer to

IP-12, "Removal and Installation"

.

2. Remove the in-vehicle sensor screw and remove the in-vehicle

sensor.

INSTALLATION

Installation is in the reverse order of removal.

• Make sure that the aspirator hose is securely attached to the in-vehicle sensor when installing the instrument

lower cover LH.

WJIA0098E

VTL-10

< ON-VEHICLE REPAIR >

SUNLOAD SENSOR

SUNLOAD SENSOR

Removal and Installation

INFOID:0000000004205416

REMOVAL

1. Remove the front RH speaker grille (1). Refer to

AV-73,

"Removal and Installation"

.

2. Disconnect the connector.
3. Release the sunload sensor tabs (A) to remove it from the front

RH speaker grille (1).

INSTALLATION

Installation is in the reverse order of removal.

ALIIA0012ZZ

INTAKE SENSOR

VTL-11

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

J

K

L

M

A

B

VTL

N

O

P

INTAKE SENSOR

Removal and Installation

INFOID:0000000004205417

REMOVAL

1. Remove the evaporator. Refer to

VTL-20, "Removal and Instal-

lation"

.

2. Release the intake sensor clip and then remove the intake sen-

sor.

CAUTION:

• Mark the mounting position of the intake sensor.

• Do not damage the evaporator core.

INSTALLATION

Installation is in the reverse order of removal.

WJIA0100E
