VTL-4

< PRECAUTION >

PRECAUTIONS

If the battery is disconnected or discharged, the steering wheel will lock and cannot be turned.

If turning the steering wheel is required with the battery disconnected or discharged, follow the procedure

below before starting the repair operation.

OPERATION PROCEDURE

1. Connect both battery cables.

NOTE:

Supply power using jumper cables if battery is discharged.

2. Carry the Intelligent Key or insert it to the key slot and turn the push-button ignition switch to ACC position.

(At this time, the steering lock will be released.)

3. Disconnect both battery cables. The steering lock will remain released with both battery cables discon-

nected and the steering wheel can be turned.

4. Perform the necessary repair operation.
5. When the repair work is completed, re-connect both battery cables. With the brake pedal released, turn

the push-button ignition switch from ACC position to ON position, then to LOCK position. (The steering

wheel will lock when the push-button ignition switch is turned to LOCK position.)

6. Perform self-diagnosis check of all control units using CONSULT-III.

Precaution for Procedure without Cowl Top Cover

INFOID:0000000004205410

When performing the procedure after removing cowl top cover, cover

the lower end of windshield with urethane, etc.

PIIB3706J

PREPARATION

VTL-5

< PREPARATION >

C

D

E

F

G

H

J

K

L

M

A

B

VTL

N

O

P

PREPARATION

PREPARATION

Commercial Service Tool

INFOID:0000000004205411

Tool number
Tool name

Description

Power tool

Removing bolts, screws and nuts

PIIB1407E

VTL-6

< FUNCTION DIAGNOSIS >

IN-CABIN MICROFILTER

FUNCTION DIAGNOSIS

IN-CABIN MICROFILTER

Description

INFOID:0000000004205412

FUNCTION

The fresh air (A) and the recirculated air (B) drawn inside the pas-

senger compartment by the blower fan (1) is kept clean (C) on either

mode by the air conditioner filter (2), located before the evaporator

(3), in the A/C unit assembly.

WJIA2253E

IN-CABIN MICROFILTER

VTL-7

< ON-VEHICLE MAINTENANCE >

C

D

E

F

G

H

J

K

L

M

A

B

VTL

N

O

P

ON-VEHICLE MAINTENANCE

IN-CABIN MICROFILTER

Removal and Installation

INFOID:0000000004205413

REMOVAL

1. Remove the glove box assembly. Refer to

IP-12, "Removal and Installation"

.

2. Disengage the filter cover tab (1) to remove the filter cover.
3. Remove the in-cabin microfilter from the blower unit by using the

pull tab on the bottom of the filter.

INSTALLATION

Installation is in the reverse order of removal.

ALIIA0016ZZ
