SEC-226 < FUNCTION DIAGNOSIS > [SEDAN WITH INTELLIGENT KEY] VEHICLE SECURITY SYSTEM Disarmed Phase • When doors or trunk is open, the vehicle security system is set in the disarmed phase on the assumption that the owner is inside or near the vehicle. • When the vehicle security system is in the disarmed phase, the security indicator lamp blinks every 2.4 sec- onds. Pre-armed Phase and Armed Phase When the following operation 1 or 2 is performed, the vehicle security system turns into the “pre-armed” phase. (The security indicator lamp illuminates.) are closed. 2. Trunk and all doors are closed after front doors are locked by key or door lock and unlock switch. The security indicator lamp illuminates for 30 seconds. Then, the system automatically shifts into the “armed” phase. CANCELING THE SET VEHICLE SECURITY SYSTEM When one of the following operations is performed, the armed phase is canceled. CANCELING THE ALARM OPERATION OF THE VEHICLE SECURITY SYSTEM When unlocking the door with the key or Intelligent Key the alarm operation is canceled. ACTIVATING THE ALARM OPERATION OF THE VEHICLE SECURITY SYSTEM Check that the system is in the armed phase. (The security indicator lamp blinks every 2.4 seconds.) When the following operation 1 or 2 is performed, the system sounds the horns and flashes the headlamps for about 50 seconds. PANIC ALARM OPERATION Intelligent Key system will not operate horn and headlamps if the ignition switch is in the ACC or ON position. When the Intelligent Key system is triggered, ground is supplied intermittently to both headlamp relay and horn relay. When headlamp relay and horn relay are energized, then power is supplied to headlamps (LH and RH) and horns (HIGH and LOW). The headlamp flashes and the horn sounds intermittently. The alarm automatically turns off after 50 seconds or when BCM receives any signal from Intelligent Key. |
