AV-432 < SYMPTOM DIAGNOSIS > [BOSE AUDIO WITH NAVIGATION] NORMAL OPERATING CONDITION Location Correction by Map-Matching is Slow • The map-matching function needs to refer to the data of the surrounding area. It is necessary to drive some distance for the function to work. • Because map-matching operates on this principle, when there are many roads running in similar directions in the surrounding area, no matching determination may be made. The location may not be corrected until some special feature is found. Name of Road is Not Displayed The current road name may not be displayed if there are no road names displayed on the map screen. Contents of Display Differ for Birdview™ and the (Flat) Map Screen Difference of the BIRDVIEW™ screen from the flat map screen are as follows. • The current place name displays names which are primarily in the direction of vehicle travel. • The amount of time before the vehicle travel or turn angle is updated on the screen is longer than for the (flat) map display. • The conditions for display of place names, roads, and other data are different for nearby areas and for more distant areas. • Some thinning of the character data is done to prevent the display becoming too complex. In some cases and in some locations, the display contents may differ. • The same place name, street name, etc. may be displayed multiple times. Vehicle Mark Shows a Position Which is Completely Wrong In the following cases, the vehicle mark may appear on completely different position in the map depending on the GPS satellite signal receiving conditions. In this case, perform location correction and direction correction. • When location correction has not been done - If the receiving conditions of the GPS satellite signal is poor, if the vehicle mark becomes out of place, it may move to a completely different location and not come back if location correction is not done. The position will be corrected if the GPS signal can be received. • When the vehicle has traveled by ferry, or when the vehicle has been being towed Precautions Just after the engine is started If the vehicle is driven just after the engine Wait for a short while before Continuous driving without stopping When driving long distances without stop- Stop and adjust the orientation. Abusive driving Spinning the wheels or engaging in other If after travelling about 10 km (6 How to cor- Position correction accuracy If the accuracy of location settings is poor, Enter in the road displayed on Direction when location is corrected If the accuracy of location settings during Perform direction correction. Cause (condition) –: While driving ooo: Display Driving condition Remarks (correction, etc.) SEL701V SEL702V |
