AV-76

< ON-VEHICLE REPAIR >

[BASE AUDIO]

SATELLITE RADIO TUNER

SATELLITE RADIO TUNER

Removal and Installation - Coupe

INFOID:0000000004496844

REMOVAL

1. Disconnect the battery negative terminal.
2. Remove the trunk floor carpet and spare tire cover. Refer to

INT-23, "Removal and Installation"

.

3. Remove the LH trunk floor spacer.
4. Remove the satellite radio tuner assembly nuts (B), and satellite

radio tuner screw (C), disconnect the satellite radio tuner har-

ness connectors and remove the satellite radio tuner and

bracket assembly (1 and 2), then remove the satellite radio tuner

screws (A) and remove satellite radio tuner (1) from the bracket

(2).

INSTALLATION

Installation is in the reverse order of removal.

Removal and Installation - Sedan

INFOID:0000000004496845

REMOVAL

1. Disconnect the battery negative terminal.
2. Remove the rear parcel shelf finisher. Refer to

INT-38, "Removal and Installation"

.

3. Remove the satellite radio tuner unit screws (A), disconnect the

satellite tuner harness connectors and remove the satellite radio

tuner (1).

INSTALLATION

Installation is in the reverse order of removal.

AWNIA1819ZZ

AWNIA1820ZZ

AV

SATELLITE RADIO ANTENNA

AV-77

< ON-VEHICLE REPAIR >

[BASE AUDIO]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

SATELLITE RADIO ANTENNA

Removal and Installation

INFOID:0000000004496846

REMOVAL

1. Lower the headliner at the rear. Refer to

INT-20, "Removal and Installation"

 (coupe) and

INT-42,

"Removal and Installation"

 (sedan).

2. Remove the satellite radio antenna nut (A), then disconnect the

satellite radio antenna connector (B) and remove the satellite

radio antenna (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0056ZZ

AV-78

< ON-VEHICLE REPAIR >

[BASE AUDIO]

STEERING SWITCH

STEERING SWITCH

Removal and Installation

INFOID:0000000004206407

REMOVAL

1. Remove the driver airbag module. Refer to

SR-5, "Removal and Installation"

.

2. Remove the steering wheel switch assembly screws (A), then

remove the steering wheel switches (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0045ZZ

AV

ANTENNA AMP.

AV-79

< ON-VEHICLE REPAIR >

[BASE AUDIO]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

ANTENNA AMP.

Removal and Installation - Coupe

INFOID:0000000004206408

REMOVAL

1. Remove the rear pillar finisher RH. Refer to

INT-15, "Removal and Installation"

.

2. Detach the antenna amp harness clip (B), disconnect the

antenna amp connectors (A), remove the antenna amp screw

(C) and remove the antenna amp (1).

INSTALLATION

Installation is in the reverse order of removal.

Removal and Installation - Sedan

INFOID:0000000004206409

REMOVAL

1. Remove the rear pillar finisher RH. Refer to

INT-20, "Removal and Installation"

.

2. Partially remove the side curtain air bag module RH to gain access to the antenna amp. Refer to

SR-12,

"Removal and Installation"

.

3. Detach the antenna amp harness clip (A), disconnect the

antenna amp connectors (B), remove the antenna amp screw

(C) and remove the antenna amp (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0917ZZ

ALNIA0043ZZ
