BRM-28

< REMOVAL AND INSTALLATION >

REPLACEMENT OPERATIONS

REINFORCEMENT

Work after front pillar outer has been removed.

Replacement parts

z

Front pillar section of body side outer

Recommended sectioning location

Front

AWKIA2539ZZ

REPLACEMENT OPERATIONS

BRM-29

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

INNER

Work after front pillar reinforcement has been removed.

Replacement parts

z

Front pillar reinforcement

Front

AWKIA2540ZZ

BRM-30

< REMOVAL AND INSTALLATION >

REPLACEMENT OPERATIONS

Dash Side

INFOID:0000000009345086

Work with front pillar reinforcement removed.

Replacement parts

z

Front pillar inner reinforcement

A. Mig welds

Front

ALKIA3156ZZ

REPLACEMENT OPERATIONS

BRM-31

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

Center Pillar

INFOID:0000000009345087

OUTER

Replacement parts
z

Dash side

Front

AWKIA2541ZZ
