SERVICE DATA AND SPECIFICATIONS (SDS) EM-127 < SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE] C D E F G H I J K L M A EM N P O *: Always check with the Parts Department for the latest parts information. Undersize Unit: mm (in) Bearing Oil Clearance Unit: mm (in) 12 UPR 1.501 - 1.504 (0.0591 - 0.0592) Brown Grade and color are different LWR 1.504 - 1.507 (0.0592 - 0.0593) Green 23 UPR 1.504 - 1.507 (0.0592 - 0.0593) Green LWR 1.507 - 1.510 (0.0593 - 0.0594) Yellow 34 UPR 1.507 - 1.510 (0.0593 - 0.0594) Yellow LWR 1.510 - 1.513 (0.0594 - 0.0596) Blue 56 UPR 1.513 - 1.516 (0.0596 - 0.0597) Pink LWR 1.516 - 1.519 (0.0597 - 0.0598) Purple Items Thickness Crankshaft pin journal diameter US 0.25 (0.0098) 1.627 - 1.635 (0.0640 - 0.0644) Grind so that bearing clearance is the specified value. Connecting rod bearing oil clearance Standard 0.020 - 0.030 (0.0008 - 0.0012) Limit 0.10 (0.0039) |
