DLK-182

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

DOOR SWITCH

DOOR SWITCH

Exploded View

INFOID:0000000009268884

Removal and Installation

INFOID:0000000009268885

REMOVAL

1. Remove the door switch bolt (A).

2. Disconnect the harness connector and remove door switch (1).

INSTALLATION

Installation is in the reverse order of removal.

1.

Door switch

2.

Door switch bolt

AWKIA1893ZZ

JMKIA2173ZZ

TRUNK LID OPENER SWITCH

DLK-183

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

TRUNK LID OPENER SWITCH

Removal and Installation

INFOID:0000000009268886

REMOVAL

1. Remove the trunk lid finisher. Refer to

EXT-30, "Removal and Installation"

.

2. Disconnect harness connector from the trunk lid opener switch.
3. Remove the trunk lid opener switch.

INSTALLATION

Installation is in the reverse order of removal.

DLK-184

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

INSIDE KEY ANTENNA

INSIDE KEY ANTENNA

INSTRUMENT CENTER
INSTRUMENT CENTER : Removal and Installation

INFOID:0000000009268887

REMOVAL

1. Remove the instrument lower center panel. Refer to

IP-20, "Removal and Installation"

.

2. Remove screws (A) and the inside key antenna (instrument cen-

ter) (1).

INSTALLATION

Installation is in the reverse order of removal.

CONSOLE
CONSOLE : Removal and Installation

INFOID:0000000009268888

REMOVAL

1. Remove the center console assembly. Refer to

IP-23, "Removal and Installation"

.

2. Remove clips (A) and the inside key antenna (console) (1).

INSTALLATION

Installation is in the reverse order of removal.

TRUNK ROOM
TRUNK ROOM : Removal and Installation

INFOID:0000000009268889

REMOVAL

Remove clips (A) and the inside key antenna (trunk room) (1).

JMKIA7948ZZ

JMKIA7950ZZ

JMKIA7951ZZ

INSIDE KEY ANTENNA

DLK-185

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

INSTALLATION

Installation is in the reverse order of removal.
