Nissan Silvia. Manual - part 298

Commercial Service Tools

NMMT0002

Tool name

Description

Slide hammer puller

SMT054E

Removing 6th coupling sleeve & synchronizer hub
assembly
(Use with quick steering puller)

Quick steering puller

SMT055E

Use with slide hammer puller

GI

MA

EM

LC

EC

FE

CL

AT

PD

AX

SU

BR

ST

RS

BT

HA

SC

EL

IDX

PREPARATION

Commercial Service Tools

MT-5

NMMT0023

NVH Troubleshooting Chart

NMMT0023S01

Use the chart below to help you find the cause of the problem. The numbers indicate the order of the inspec-
tion. If necessary, repair or replace these parts.

MANUAL TRANSMISSION

NMMT0023S0101

Reference page

Refer

to

MT

-7,

“Checking

M/T

Oil”.

MT

-15

MT

-15

MT

-15

MT

-15

MT

-15

MT

-31

MT

-31

MT

-31

SUSPECTED PARTS
(Possible cause)

OIL

(Level

low)

OIL

(W

rong)

OIL

(Level

too

high)

GASKET

(Damaged)

OIL

SEAL

(W

orn

or

damaged)

CHECK

PLUG

RETURN

SPRING

AND

CHECK

BALL

(W

orn

or

damaged)

SHIFT

FORK

(W

orn)

GEAR

(W

orn

or

damaged)

BEARING

(W

orn

or

damaged)

BAULK

RING

(W

orn

or

damaged)

INSER

T

SPRING

(Damaged)

Symptom

Noise

1

2

3

3

Oil leakage

3

1

2

2

Hard to shift or will not shift

1

1

2

2

Jumps out of gear

1

2

2

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

MT-6

SMA103

Checking M/T Oil

NMMT0061

Never start engine while checking oil level.
1.

Check manual transmission for leakage.

2.

Check oil level.

Filler plug:

: 27 - 48 N·m (2.7 - 4.9 kg-m, 20 - 35 ft-lb)

SMA255A

Changing M/T Oil

NMMT0062

Oil grade and viscosity:

Refer

to

“RECOMMENDED

FLUIDS

AND

LUBRICANTS”, MA-8.

Oil capacity:

FS6R92A

1.8 liters (3-7/8 US pt, 3-1/8 Imp pt)

Drain plug:

: 27 - 48 N·m (2.7 - 4.9 kg-m, 20 - 35 ft-lb)

GI

MA

EM

LC

EC

FE

CL

AT

PD

AX

SU

BR

ST

RS

BT

HA

SC

EL

IDX

M/T OIL

Checking M/T Oil

MT-7

FMT001

Replacing Rear Oil Seal

NMMT0003

REMOVAL

NMMT0003S01

1.

Remove the propeller shaft.

2.

Using a oil seal puller (SST), remove the oil seal.

FMT002

INSTALLATION

NMMT0003S02

1.

Apply multi-purpose grease to the oil seal lips. Then, drive the
oil seal with a drift (SST) until the oil seal is flush with the end
surface of the case.

CAUTION:

I

Do not reuse the removed oil seal. Always use a new oil
seal.

I

Install the oil seal so that it is fit level without inclination.

2.

Install the propeller shaft.

CAUTION:

If oil has leaked during this operation, check the oil level after
completing the operation.

SMT056E

Position Switch Check

NMMT0004

Switch

Gear position

Continuity

Back-up lamp switch

Reverse

Yes

Except reverse

No

PNP switch

Neutral

Yes

Except neutral

No

ON-VEHICLE SERVICE

Replacing Rear Oil Seal

MT-8
