Nissan Qashqai J11. Manual - part 1502

GW-18

< REMOVAL AND INSTALLATION >

SIDE WINDOW GLASS

Removal and Installation

INFOID:0000000010478438

REMOVAL

1.

Remove luggage side upper finisher. Refer to

INT-29, "Luggage side trim"

.

2.

Remove harness connector.

3.

Apply protective tape (A) around side window glass to protect
painted surface from damage.

4.

Remove the side window glass using piano wire or power cutting tool and unflatable pump bag.

WARNING:

When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent
glass splinters from entering your eyes or cutting your hands.

CAUTION:

• When a window glass is reused, never use a cutting knife or power cutting tool.
• Never scratch the glass when removing.
• Never set or stand the glass on its edge. Small chips may develop into cracks.

INSTALLATION

Installation is in the reverse order of removal.
• Install the side glass from outside the vehicle to ensure that it is even around the top, bottom and sides of the

opening.

• Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions fur-

nished with it.

• While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out

by passenger compartment air pressure when a door is closed.

• Check gap along bottom to confirm that glass does not contact sheet metal.
• Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely

cured (preferably 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid

contact with the skin and eyes.

• Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled.

If affected by vapor inhalation, immediately move to an area with fresh air.

• Driving the vehicle before the urethane adhesive has completely cured may affect the performance

of the glass in case of an accident.

K.

12 mm (0.47 in)

Refer to

GI-4, "Components"

 for symbols in the figure.

JMKIB3125ZZ

JMKIB3126ZZ

SIDE WINDOW GLASS

GW-19

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

CAUTION:

• Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six

months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed
on the box.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Do not leave primers or adhesive cartridge unattended with their caps open or off.
• The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely

cured. Curing time varies depending on temperature and humidity. The curing time will increase
under lower temperatures and lower humidity.

Inspection

INFOID:0000000010478439

REPAIRING WATER LEAKAGE FOR SIDE WINDOW GLASS

Leakage can be repaired without removing glass.
Determine the extent of leakage if water is leaking between the urethane adhesive material and body or glass.
This can be done by applying water to the side window glass area while pushing glass outward.
Apply primer (if necessary) and then urethane adhesive to the leakage point to stop the leakage.

GW-20

< REMOVAL AND INSTALLATION >

BACK DOOR WINDOW GLASS

BACK DOOR WINDOW GLASS

Exploded View

INFOID:0000000010478440

Removal and Installation

INFOID:0000000010478441

REMOVAL

1.

Remove back door finisher. Refer to

INT-31, "Removal and Installation"

.

2.

Remove back door lock. Refer to

DLK-190, "Removal and Installation"

 (With Intelligent Key and super

lock) or

DLK-372, "Removal and Installation"

 (With Intelligent Key without super lock) or

DLK-503,

"Removal and Installation"

 (Without Intelligent Key with super lock) or

DLK-642, "Removal and Installa-

tion"

 (Without Intelligent Key and super lock).

3.

Remove rear wiper arm and motor. Refer to

WW-82, "Exploded View"

.

4.

Disconnect harness connectors from back door window defogger.

5.

Remove glass using piano wire or power cutting tool and an inflatable pump bag after removing molding
using pliers.

NOTE:
Mark the body and glass with a matching marks if the back door window is reused.

1.

Back door window glass

2.

Clip

3.

Back door window lower molding

Refer to

GI-4, "Components"

 for symbols in the figure.

E1KIA0137ZZ

PIIB5779E

BACK DOOR WINDOW GLASS

GW-21

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

WARNING:

Always wear safety glasses and heavy gloves to help prevent injuries.

CAUTION:

• Be careful not to scratch the glass when removing.
• Never set or stand glass on its edge. Small chips may develop into cracks.
• Never use a cutting knife or power cutting tool when the back door window glass is reused.

INSTALLATION

• The dam sealant rubber should be installed in position.
• Use a Genuine Nissan Urethane Adhesive Kit (if available) or an equivalent and follow the instructions pro-

vided with it.

• Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by

passenger compartment air pressure when all door windows are closed.

• The molding must be installed securely so that it is in position and leaves no clearance.
• Inform the customer that the vehicle should remain stationary until the urethane adhesive is completely

cured (approximately 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never

let them come in contact with the skin and eyes.

• Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.

Move immediately to an area with fresh air if affected by vapor inhalation.

• Driving the vehicle before the urethane adhesive is completely cured may affect the performance

of the back door window in an accident.

CAUTION:

• Perform adjustment of rear wiper arm stop location. Refer to

WW-83, "WIPER ARM : Adjustment"

.

• Never use an adhesive that is past its usable term. Shelf life of this product is limited to six months

after the date of manufacture. Adhere carefully to the expiration or manufacture date printed on the
box.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Never leave primers or adhesive cartridge unattended with their caps open or off.
• The vehicle should not be driven for 24 hours or more or until the urethane adhesive is completely

cured. Curing time varies depending on temperature and humidity. The curing time increases
under lower temperature and lower humidity.
